Utility of line probe assay in detecting drug resistance and the associated mutations in patients with extrapulmonary tuberculosis in Addis Ababa,Ethiopia

Abstract

Introduction:

Molecular tests allow rapid detection of Mycobacterium tuberculosis and drug resistance in a few days. Identifying the mutations in genes associated with drug resistance may contribute to the development of appropriate interventions to improve tuberculosis control. So far, there is little information in Ethiopia about the diagnostic performance of line probe assay (LPA) and the M. tuberculosis common gene mutations associated with drug resistance in extrapulmonary tuberculosis. Thus, this study aimed to assess the frequency of drug resistance-associated mutations in patients with extrapulmonary tuberculosis (EPTB) and to compare the agreement and determine the utility of the genotypic in the detection of drug resistance in Addis Ababa, Ethiopia.

Methods:

A cross-sectional study was conducted on stored M. tuberculosis isolates. The genotypic and phenotypic drug susceptibility tests were performed using LPA and BACTEC-MGIT-960, respectively. The common mutations were noted, and the agreement and the utility of the LPA were determined using the BACTEC-MGIT-960 as a gold standard.

Results:

Of the 151 isolates, the sensitivity and specificity of MTBDRplus in detecting isoniazid resistance were 90.9% and 100%, respectively. While for rifampicin, it was 100% and 99.3% for sensitivity and specificity, respectively. The katG S315Tl was the most common mutation observed in 85.7% of the isoniazid-resistant isolates. In the case of rifampicin, the most common mutation (61.9%) was observed at position rpoB S531L. Mutations in the gyrA promoter region were strongly associated with Levofloxacin and Moxifloxacin resistance.

Conclusion:

Line probe assay has high test performance in detecting resistance to anti-TB drugs in EPTB isolates. The MTBDRplus test was slightly less sensitive for the detection of isoniazid resistance as compared to the detection of rifampicin. The most prevalent mutations associated with isoniazid and rifampicin resistance were observed at katG S315Tl and rpoB S531L respectively. Besides, all the fluoroquinolone-resistant cases were associated with gyrA gene. Finally, a validation study with DNA sequencing is recommended.

Keywords

Extrapulmonary tuberculosis mutation performance characteristics

Introduction

Tuberculosis (TB) is one of the most serious public health issues, generating significant morbidity and mortality, especially in low- and middle-income countries.¹ It is the top 10 cause of death worldwide and the second cause of death from a single infectious agent next to COVID-19. Currently, according to the 2020 global TB report, an estimated 10.0 million people developed TB and 1.4 million died due to TB in 2019.² The prevalence of extrapulmonary tuberculosis (EPTB) among notified TB cases in the African region in 2019 was 16%,² which is the second highest next to the Eastern Mediterranean region (24%), which is more than the global EPTB prevalence (16%).³ In Ethiopia, EPTB represented 30% of all notified TB cases which is greater than the global average.²

Drug-resistant TB is a public health problem and a threat to global TB control programs.² Drug-resistant TB is developed when someone is infected with Mycobacterium tuberculosis strains that are resistant to at least one anti-TB drug. It can be multi-drug resistant TB (MDR-TB) or extensively drug-resistant TB (XDR-TB). MDR-TB is caused by Mycobacterium tuberculosis strains resistant to rifampicin and isoniazid, while XDR-TB is identified as MDR-TB that is resistant to at least one Group A medication and any fluoroquinolone. The Group A drugs are currently levofloxacin or moxifloxacin, bedaquiline, and linezolid.⁴ According to the 2020 global TB report, an estimated 3.3% of new TB cases and 18% of previously treated cases develop MDR/RR-TB globally. The prevalence of MDR-TB among new and retreatment cases in Ethiopia is estimated to be 0.7% and 16%, respectively.² In Ethiopia, pre-XDR TB was reported by previous studies with 5% to 5.7%.^5,6

Conventional drug-susceptibility test (DST) is laborious, time-consuming, and requires the growth of mycobacteria.⁷ Therefore, the World Health Organization (WHO) has recommended the use of molecular line probe assay for detecting drug-resistant M. tuberculosis directly from smear-positive specimens and cultures-positive isolates. This diagnostic test is based on polymerase chain reaction (PCR) followed by a DNA strip reverse hybridization assay.⁸ Drug-resistant mutations in numerous genes have been related to M. tuberculosis. Mutations in the rpoB gene can explain M. tuberculosis resistance to rifampicin (RIF), whereas mutations in the katG, and inhA, genes are linked to Isoniazid (INH) resistance. Resistance to RIF is mainly associated with mutations in the codon 507 to codon 533 region of the rpoB gene (97 %). INH resistance is acquired through mutations in the katG and inhA. The most frequent katG mutations (50%–90%) are found at codon 315.⁹ Fluoroquinolone resistance is caused by mutations in the gyrA and gyrB genes. The gyrA mutations account for 60% to 70% of all mutations, but gyrB mutations are not common.¹⁰ Resistance to second-line injectable drugs (SLID), including amikacin (AMK), kanamycin (KAN), and capreomycin (CAP), is mainly associated with rrs gene mutations. Approximately 70% to 80% of CAP resistance and 60% of KAN resistance are caused by the rrs A1401G mutation.¹¹

For biological and epidemiological reasons, identifying drug resistance-conferring mutations in M. tuberculosis in a particular geographical setting is essential. Several studies in Ethiopia investigated drug resistance profiles in M. tuberculosis isolates from PTB patients. However, only a few studies have assessed the mutation patterns of M. tuberculosis isolates from EPTB samples.^12–14 A pooled estimate conducted in Ethiopia, revealed that 89.2% of the katG mutation was at position S315T1% and 77.5% of the inhA mutation was at position C15T. Moreover, 74.2% of rpoB gene mutations was observed at position S531L.¹⁵ In another study, all FQs resistance mutations were associated with gyrA gene at position D94Y/N.¹⁶ However, the information is very limited. Besides, less is known about the diagnostic performance of line probe assay (LPA) in detecting drug resistance in EPTB isolates in Ethiopia. Hence, this study aimed to assess the frequency of drug resistance-conferring mutations in patients with EPTB and to compare the agreement and determine the utility of the genotypic (LPA) in the detection of drug resistance using the phenotypic (BACTEC-MGIT 960) test as a gold standard.

Method

Study setting, design, and period

This study was conducted among Mycobacterial isolates collected from 151 patients with EPTB in Addis Ababa, Ethiopia (Figure 1). The isolates were based on the samples collected from EPTB patients in the selected eight public hospitals found in Addis Ababa such as St Paul Hospital, ALERT Hospital, Armed Force Hospital, Black Lion Hospital, Ras Desta Hospital, Zewiditu Hospital, St Peter Hospital, and Yekatit 12 Hospital. A laboratory-based, cross-sectional study was conducted between October 2019 and April 2020 (Figure 2).

Figure 1.

Flowchart to show the confirmed Mycobacterium tuberculosis isolate from the Extrapulmonary Tuberculosis patients.

Figure 2.

Map of study area.

Inclusion and exclusion criteria

All culture-positive isolates presented with a correct patient identification number and having demographic data were included in this study. NTM and contaminated EPTB isolates were excluded from this study.

Laboratory analysis

Subculturing of stored isolates collection

The sample collection was conducted from January to August 2017. Isolates were stored in the national TB reference laboratory, Ethiopian Public Health Institute in a deep freeze at a temperature of −80°C with the 7H9 broth base and kept until needed for this study. All stored isolates were sub-cultured in liquid culture media for detection of M. tuberculosis.

Phenotypic drug susceptibility testing

Phenotypic DST was performed using Mycobacterium growth indicator tubes (MGIT) (BACTECTM MGITTM 960 System). Each MGIT tube was inoculated with 0.8 mL of SIRE supplement. Then, 0.1 mL of the drug solution and 0.5 mL of strain suspension were added. For the drug-free growth control tube, the organism suspension was diluted at 1:100 with sterile saline, and then 0.5 mL was inoculated into the tube and incubated for a maximum of 13 days for all drugs except the PZA drug. The maximum incubation period of the PZA drug is 21 days. The final concentrations of each drugs in liquid media was; INH 0.1 μg/mL, RIF 1.0 μg/mL, ethambutol 5 μg/mL, STM 1.0 μg/mL, PZA 100 μg/mL, ofloxacin 2.0 µg/mL, CAP 1.25 µg/mL, AMK 1.0 µg/mL, KAN 2.5 µg/mL, moxifloxacin (MOX) 2.5 µg/mL and ethionamide 2.5 µg/mL.^17,18

Results were interpreted as follows, a known concentration of drug contained the MGIT along with the specimen, and growth was compared with a drug-free control of the same specimen. At the time when the growth unit (GU) of the drug-free control tube was >400, if the GU of the drug-containing tube to be compared was ⩾100, the strain was resistant. If the GU of the drug-containing tube was <100, the strain was susceptible. As a control, the reference strain of M. tuberculosis H37Rv was used as control.^17–19

Geno-Type MTBDRplus and MTBDRsl assay

Line probe assay technology is done in multiple steps. DNA extraction, master mix preparation, PCR, and reverse hybridization were all done in separate rooms during the LPA process. All of the assays (Geno-Type MTBDRplus and MTBDRsl assays) were performed as directed by the manufacturer.^20–23

DNA extraction

The GenoLyse kit was used to extract DNA according to the manufacturer’s instructions (Hain Lifescience, Nehren, Germany). To kill the bacteria, a 1 ml liquid culture was transferred directly to a conical vial tube. The isolate was then centrifuged at 10,000 g for 5 min. After discarding the supernatant it was resuspended in the pellet in 100 μL lysis Buffer and vortexed. Then it was incubated for 5 min at 95°C in a heat block. After that, 100 μl Neutralization Buffer was added to the lysate and vortexed for 30 s before centrifuging it at 13,000 g for 5 min. For further examination and long storage, the DNA-containing supernatant was transferred to a separate tube.^20,23,24 The 5 μL extracted DNA sample was then added to the master mix in another room. The PCR on DNA from culture isolates was performed using the following parameters: 95°C for 15 min, 95°C for 30 s, 58°C for 2 min (10 cycles), 95°C for 25 s, 53°C for 40 s, 70°C for 40 s (20 cycles).^21–24

Reverse hybridization

According to the manufacturer’s instructions, hybridization and detection of the amplified product were carried out in an automated TwinCubator. Denaturation of the amplification products was accomplished by mixing 20 μL of amplified products with 20 μL of denaturing reagent (supplied in the kit) for 5 min. After that, 1 mL of pre-warmed hybridization buffer was added, and the operation was carried out at 45°C for 30 min, followed by two washing steps.²³ For colorimetric detection of hybridized amplicons, streptavidin conjugated with alkaline phosphatase and substrate buffer was added. Washing was done well, and all strips were air-dried. To ensure that the test was free of cross-contamination, DNA from H37RV (positive control) and negative control was examined. Only when bands were obtained on MTB complex controls, conjugate controls, and amplification controls in conjunction with the target genes locus controls were the results considered valid.^20,21,23

Results analysis and interpretation

GenoScan^® (Hain Lifescience, Nehren, Germany) was used to scan the dried strips and create an automated read-out of the band patterns. The strips were attached to the assessment papers that came with the kit. The read-final out results were manually checked with the naked eye.²³

Data quality assurance

Internal quality control was analyzed along with the study’s clinical isolates. A known susceptible M. tuberculosis (H37Rv) control and resistant isolates were tested by including them in each test run of DST. Data entry was performed 2 times independently to check inconsistencies. Data cleaning was performed before the final analysis.

Statistical analysis

Descriptive statistics such as frequencies and proportions were used to explain drug resistance patterns and associated mutations. The agreement, sensitivity, specificity, positive, and negative predictive values of LPA compared to the BACTEC MGIT 960 system were calculated for drug resistance. The strength of agreement between the different test results was assessed by using the kappa static. All data were analyzed by SPSS version 28 (SPSS Inc, Chicago, IL, USA).

Results

Demographic profile and clinical data of study participants

Out of 151 culture-positive confirmed cases of EPTB isolates, more than half (54.3%) were isolated from males. The mean age of the study participants was 32.3 years ranging from 4 to 78 years. The majority of participants were in the age groups 15 to 64 years. More than half (51.0%) of the study participants attended primary school. About 45% were married and 30.5% were daily laborers. Most (90.7%) of the patients had no previous TB treatment history. About 22.5% and 9.3% of the participants were HIV sero-reactive and had diabetes, respectively (Table 1).

Table 1.

Demographic and clinical symptoms of EPTB patients in Addis Ababa Ethiopia (n = 151), 2020.

Characteristics		Frequency	Percentage
Age in years	<15	17	11.3
	15–64	124	82.1
	>64	10	6.6
Gender	Female	69	45.7
	Male	82	54.3
HIV status	Nonreactive	96	63.6
	Reactive	34	22.5
	Unknown	21	13.9
Marital status	Married	98	64.9
	Single	44	29.1
	Separated	9	6.0
Educational status	Illiterate	42	27.8
	Primary school	77	51.0
	Secondary school	24	15.9
	Higher education	8	5.3
Occupation	Housewife	13	8.6
	Daily laborer	46	30.5
	Government employee	12	7.9
	Unemployed	38	25.2
	Other	42	27.8
Diabetes mellitus	Yes	14	9.3
	No	137	90.7
MDR-TB contact	Yes	7	4.6
	No	144	95.4
TB category	New cases	137	90.7
	Re-treatment	14	9.3

TB: tuberculosis; MDR-TB: multidrug-resistant tuberculosis; HIV: human immunodeficiency virus.

Characteristics of the Mycobacterial isolates

In this study, 151 stored mycobacterial isolates from patients with EPTB were characterized using LPA to identify the mutations associated with drug resistance. Phenotypic DST was used as a gold standard to determine the diagnostic performance of MTBDRplus and MTBDRsl LPA (Figure 2). The majority (99, 65.6%) of the isolates were from lymph node aspirates, followed by pleural fluid (32, 12.2%), peritoneal fluid (8, 5.3%), ascitic fluid (5, 3.3%), cerebrospinal fluid (CSF) (3, 2.0%), pus (2, 1.3%), pericardium fluid (1, 0.7%), and abscess (1, 0.7%) (Figure 3).

Figure 3.

Frequency of different types of specimen for EPTB.

Performance of MTBDRplus in detecting RIF and INH resistance

This study analyzed the DST pattern of Mycobacterial isolates by the Geno-Type MTBDRplus assay and the phenotypic DST (MGIT) methods. To test the diagnostic performance of the MTBDRplus in diagnosing RIF and INH resistance, it was compared to the MGIT (gold standard) method. The sensitivity, specificity, positive predictive value, and negative predictive value of the MTBDRplus assay for INH were 90.9%, 100%, 100%, and 98.5%, respectively, while the respective values for RIF were 100%, 99.3%, 93.3%, and 100%, respectively. The kappa agreement for INH between genotypic DST and phenotypic DST was 0.95, while it was 0.96 for RIF. Fifteen and 14 M. tuberculosis isolates were resistant to RIF by the MTBDRplus assay and the phenotypic DST, respectively. Twenty and 22 isolates were resistant to INH in the MTBDRplus assay and the phenotypic DST, respectively. Among the 151 Mycobacterial isolates, 3 (2.0%) M. tuberculosis isolates had discordant results. Of these, two isolates were susceptible to INH in the MTBDRplus assay and became resistant in the phenotypic DST. One isolate was resistant to RIF in the genotyping DST analysis and became susceptible to the phenotype DST. The concordances of the MTBDRplus assay and the MGIT DST for the detection of INH and RIF resistance were 90.9% (20/22) and 100% (14/14), respectively (Table 2).

Table 2.

The diagnostic performance of MTBDRplus against phenotypic DST in extrapulmonary specimens (n = 151).

Geno-Type MTBDRplus assay		Phenotypic MGIT DST result					NPV	Kappa agreement
Geno-Type MTBDRplus assay		Susceptible	Resistance	Sensitivity	Specificity	PPV
INH	Susceptible	129 (85.4%)	2 (1.3%)	90.9%	100%	100%	98.5%	0.95
	Resistance	–	20 (13.2%)
RIF	Susceptible	136 (90.1%)	–	100%	99.3%	93.3%	100%	0.96
	Resistance	1 (0.4%)	14 (9.3%)

RIF: rifampicin; INH: isoniazid; DST: drug susceptibility test; PPV: positive predictive value; NPV: negative predictive value; MGIT: Mycobacterium Growth Indicator Tube; MTBDR: Mycobacterium Tuberculosis Drug Resistance.

For all 14 MDR cases, we performed second-line DST using both the Geno-Type MTBDRsl assay and the phenotypic (MGIT) DST method. Accordingly, three isolates were resistant to second-line drugs in the Geno-Type MTBDRsl assay where two isolates were resistant to LEV and MOX, while one isolate was resistant to AMK, CAP, and KAN. All these results agreed with the phenotypic DST result.

Mutations associated with drug-resistance

Based on the MTBDRplus assay, among the 151 isolates, 21 were found to be either RIF or INH resistant. Of the 21 resistant isolates, the rpoB mutation indicated that 15 (71.4%) isolates were resistant to RIF. The RIF-resistant isolates showed mutations at different amino acid positions. In 13 (61.9%) Mycobacterial isolates, the rpoB mutation was at position S531L, and one (4.7%) isolate had a mutation at the H526Y position. Two (9.5%) isolates had mutations in codon 526 to 529 that indicated the absence of wild-type band (WT7), and 13 (61.9%) isolates had mutations in codon 530 to 533 which showed the absence of wild-type band (WT8). Mutations in katG and inhA genes lead to INH resistance. Eighteen (85.7%) isolates had a katG mutation at the S315T1 position, and one (4.7%) had a mutation at the C15T position. Of the INH resistant isolates, a missed wild-type probe was observed only in one isolate at inhA WT1 (Table 3).

Table 3.

Frequency of gene mutations associated with rifampicin and isoniazid resistance (n = 151).

Gene	Band	Mutant probe	Number of strains (n)	Percentage
rpoB	WT1	506–509	–	–
	WT2	510–513	–	–
	WT3	513–517	–	–
	WT4	516–519	–	–
	WT5	518–522	–	–
	WT6	521–525	–	–
	WT7	526–529	2	1.3
	WT8	530–533	13	8.6
	MUT1	D516V	–	–
	MUT2A	H526Y	1	0.7
	MUT2B	H52D	–	–
	MUT3	S531L	13	8.6
katG	WT	315	18	11.9
	MUT1	S315T1	18	11.9
	MUT2A	S315T2	–	–
inhA	WT1	−15	1	0.7
	WT2	−8	–	–
	MUT1	C15T	1	0.7
	MUT2	A16G	–	–
	MUT3A	T8C	–	–
	MUT3B	T8A	–	–

MUT: mutant; WT: wild type.

For all 14 MDR-TB cases, we performed genotypic DST using the MTBDRsl assay. Of the 14 mycobacterial isolates, 3 became resistant to any of the second-line anti-TB drugs. Two isolates showed mutations in the gyrA region with the missing WT3, one with MUT3C addition and one with MUT3D addition. These mutations correspond to LEV and MOX resistance. Besides, one Mycobacterial isolate had a mutation in the rrs region with WT1 missing and a MUT1 insertion, which corresponds to resistance to AMK, CAP, and KAN (Table 4).

Table 4.

Gene mutations associated with resistance to second-line anti-TB drugs in extrapulmonary specimens (n = 3).

Strain number	WT		Mutation		Drug resistance
Strain number	WT missed	Gene region or mutation	Mutation type	Gene region or mutation	Drug resistance
570	gyrAWT3	92–96	gyrMUT3 C	D94G	Levofloxacin and Moxifloxacin
075	gyrAWT3	92–96	gyrMUT3D	D94 H	Levofloxacin and Moxifloxacin
126	rrsWT1	1400	rrsMUT1	A1401G	Amikacin, Capreomycin, and kanamycin

MUT: mutant; WT: wild type.

Discussion

In this study, we assessed the diagnostic performance of the Geno-Type MTBDRplus against the MGIT 960 system for first-line anti-TB drugs. The Geno-Type MTBDRplus assay showed high sensitivity and specificity to RIF (sensitivity 100% and specificity 99.3%). Relatively lower sensitivity and specificity for RIF were observed in studies done in India.^25,26 The specificity of rifampicin resistance in this study was 99.3%, which is comparable to two previous studies conducted in Ethiopia and another study done in India.^21,27,28

In this study, the sensitivity and specificity of LPA for detecting INH resistance were 90.9% and 100%, respectively, which is greater than investigations in India, which had a sensitivity and specificity of 93% and 97%, respectively.²⁴ In this study, INH sensitivity was lower than that reported by previous studies in Ethiopia,^21,28 Uganda,²⁹ and Pakistan.³⁰ According to this study findings, the MTBDRplus assay was unable to detect INH resistance in the two isolates that were detected by the MGIT system. This might be due to an undiscovered mutation in a genomic area that is not targeted by this assay (such as ahpc, kasA, or furA),³¹ However, the whole genome sequencing is appropriate in this scenario. The MTBDRplus assay had high specificity in detecting INH resistance and RIF resistant isolates in this study, which is consistent with the previous findings.^21,28,29

In this study, we compared the performance of the line probe assay with that of the MGIT 960 system to assess the DST pattern of M. tuberculosis in EPTB. The BACTEC MGIT 960 method was considered the “gold standard.” Two (1.3%) isolates gave discordant results for INH between molecular and phenotypic methods. Of these isolates, phenotypic DST revealed resistance to INH, while the genotypic method provided susceptible results. Discordant results between phenotypic and genotypic DST may be due to the fact that not all mutations conferring resistance to anti-TB drugs are included in the LPA assay.²⁴

One (0.7%) isolate was shown to be resistant to RIF in the genotype DST but susceptible in the phenotype DST. The discordant results of DSTs for RIF between the genotypic MTBDRplus test and the phenotypic test results were similar to findings reported from Bangladesh and Congo Kinshasa.^32,33 The MTBDRplus assay detected RIF resistance in one isolate while not detected in MGIT. Being sensitive by phenotypic technique but resistant by genotypic technique might be linked to false RIF resistance, which is caused by a silent mutation that causes the probe to fail to hybridize on a strip and is misinterpreted as RIF resistant.³⁴

This study observed the RIF resistance of rpoB gene mutations. The most frequently observed mutations on S531L and H526Y were 61.9% and 4.7%, respectively. This finding was lower than the previous studies reported from Iran, India, and China.^27,35,36 However, our finding was similar to the previous study reported from Ethiopia and Sudan in S531L and H526Y mutations.^37,38

In this study, of all the INH-resistant strains, 85.7% had the S315T1 mutation in the katG region. A relatively similar finding was reported by a study conducted in Ethiopia and India, which found 88.0% and 82.94%, respectively.^39,40 However, this study finding was smaller than the results found in Northern India, where 94.5% of INH resistance isolates had a mutation in the katG gene.⁴¹ In addition, previous studies conducted in Ethiopia and India found that mutations in katG codons S315T1 had a greater recorded correlation with INH resistance.^12,27 Moreover, the study reported from Malawi indicated that the S315T1 mutation and the mutation in the inhA gene that occurred in C15T are associated with INH resistance.³⁷ However, a study in India showed a higher proportion of C15T mutations.²⁷ Similarly, a study reported from Sudan found a C15T mutation that resulted in INH resistance.³⁷

In this study, a mutation in the gyrA codon was found in 14.3% of FQs resistant isolates. This mutation confers resistance to LEV and is associated with low-level resistance to MOX.⁴² In this study, gyrA mutations were predominantly found to occur in codons 92–96. These most common mutations largely corroborate the findings of the previous study.⁴³ The predominant rrs gene mutation was A1401G (7.1%). This is a common mutation reported in previous studies to be associated with high-level resistance to Amikacin, Capreomycin, and kanamycin.⁴⁴ In our study, the gyrB and eis genes were found to be mutation-free in MDR strains. The mutations in the gyrB gene are usually associated with low-level resistance to FLQs and are not as common as those in the gyrA gene.⁴⁵ This could be due to the limited number of resistant isolates to second-line drugs.

In the end, this study has some limitations. First, the sample size is relatively small. However, we have got an opportunity to show the performance of the line probe assay. Since the study used stored isolates, the sample size was not calculated for this study which might affect the results. Finally, this study did not perform DNA sequencing of gene mutations related to drug resistance to confirm the resistance and to identify specific mutations and causes of discordance. However, the study provides an extensive description and characterization of drug-resistance discordant strains in EPTB.

Conclusion

The diagnostic performance of the Geno-Type MTBDRplus assay has been confirmed to be highly sensitive and specific for the early detection of MDR-TB. The sensitivity of the MTBDRplus assay for the detection of RIF resistance was high, but the sensitivity was relatively lower for INH resistance detection. However, the kappa agreement between genotypic DST and phenotypic DST was acceptable. Two percent of M. tuberculosis isolates had discordant results between the genotypic MTBDRplus test and the phenotypic DST. In INH-resistant strains, 85.7% of strains had katG S315T1 mutation in the katG region, while the most common mutation associated with rifampicin resistance was found at position rpoB S531L. Besides, all the fluoroquinolone-resistant cases were associated with gyrA gene. The authors recommend a validation study with DNA sequencing.

Footnotes

Acknowledgements

The authors would like to thank Ethiopian Public Health Institute and Department of Medical Laboratory Science, College of Health Sciences, Addis Ababa University, Ethiopia.

Author contributions

Conceptualization: Getu Diriba, Abebaw Kebede, Habteyes Hailu Tola, Ayinalem Alemu, Dessie Abera, Kassu Desta.

Data curation: Getu Diriba, Abebaw Kebede, Habteyes Hailu Tola, Bazezew Yenew, Shewki Moga, Desalegn Addise, Ayinalem Alemu, Zemedu Mohammed, Muluwork Getahun, Mengistu Fantahun, Mengistu Tadesse, Biniyam Dagne, Misikir Amare, Gebeyehu Assefa, Dessie Abera, Kassu Desta.

Formal analysis: Getu Diriba, Bazezew Yenew, Shewki Moga, Desalegn Addise, Ayinalem Alemu, Zemedu Mohammed, Mengistu Tadesse, Biniyam Dagne, Misikir Amare.

Funding acquisition: Getu Diriba, Abebaw Kebede, Muluwork Getahun.

Investigation: Getu Diriba.

Methodology: Getu Diriba, Abebaw Kebede, Habteyes Hailu Tola, Zemedu Mohammed, Ayinalem Alemu, Dessie Abera, Kassu Desta.

Project administration: Getu Diriba, Bazezew Yenew.

Resources: Getu Diriba.

Software: Getu Diriba, Zemedu Mohammed.

Supervision: Getu Diriba.

Validation: Getu Diriba, Abebaw Kebede, Habteyes Hailu Tola.

Visualization: Getu Diriba.

Writing—original draft: Getu Diriba.

Writing—review & editing: Getu Diriba, Abebaw Kebede, Habteyes Hailu Tola, Ayinalem Alemu, Kassu Desta.

Declaration of conflicting interests

The author(s) declared no potential conflicts of interest with respect to the research, authorship, and/or publication of this article.

Ethics approval

The study obtained institutional ethical clearance from the ethical review committee of the Medical Laboratory Sciences, College of Health Sciences, Addis Ababa University (Protocol Number: DRERC/449/19/MLS). Since the study was conducted using stored clinical isolates, obtaining written informed consent from the study participants was not applicable and it was waived by the ethical committee. The study used a unique study identification number where any of the patients’ identifiers were not used in the entire process. Confidentiality of the results was assured by keeping the documents in a locked area.

Funding

The author(s) disclosed receipt of the following financial support for the research, authorship, and/or publication of this article: Shewki Moga is supported by a fellowship from the National Institute of Health (NIH) Fogarty International Center grant D43TW009127.

Informed consent

Consent being waived off by the ethical review committee.
