Isolation and Propagation of a Human CD133 - Colon Tumor-Derived Cell Line with Tumorigenic and Angiogenic Properties

Abstract

It has been proposed in human colorectal cancers (CRC) a minority subset of cancer cells within tumors able to initiate tumor growth, defined as cancer stem cells (CSC). Solid human primary colonic and its ovarian metastatic cancer tissues were collected from fresh surgical samples and subsequent xenografts were established in nonobese diabetic/severe combined immunodeficient (NOD/SCID) mice. The resulting tumors were disaggregated into single-cell suspensions and a CD133^- cell line (NANK) was newly established and analyzed by flow cytometry. Surface markers of progenitor cells were immunophenotypically analyzed, and expression of stem cell and cancer-related genes was characterized. Secreted angiogenesis-associated molecules were investigated by proteomic array technology. Finally, different numbers of NANK were implanted and their tumor-initiating properties were investigated in NOD/SCID mice. Intraperitoneal injection of NANK in NOD/SCID mice induced tumors with developing progressive peritoneal dissemination and ascites. NANK cells maintained a differentiated phenotype and reproduced the full morphologic and phenotypic heterogeneity of their parental lesions. Noticeably, NANK lacked the expression of conventional CSC markers CD133 and CD44, self-renewal genes Oct-4 and Nanog, but showed the expression of an important gastrointestinal development marker CDX-2 and BMI-1 that is essential in regulating the proliferative activity of normal and leukemic stem cells. In addition, NANK secreted high amounts of important angiogeneic cytokines. These results provide a novel and extensive model in human CSC for studying the generation and maintenance of phenotypic heterogeneity in CRC.

Keywords

Cell line Cancer Metastasis Intraperitoneal dissemination Gene expression Cytokines Angiogenesis

Introduction

Colon carcinoma is considered to be the third most common form of cancer and the second leading cause of cancer-related death in the Western world, causing 655,000 deaths worldwide each year (18). Although advances have been made in colon cancer therapies, most cancer deaths still result from metastatic disease, being the largest hurdle for successful tumor treatment. Unfortunately, there is a poor understanding of the molecular mechanisms responsible for the local or disseminated metastasis, thus impeding progress on effective therapies.

Colon carcinoma often metastasizes to different locations, among them the ovary where 5–10% of malignant tumors involving this organ are metastatic and are frequently mistaken for the primary ovarian carcinoma (47). Colonic adenocarcinoma accounts for 37–45% of all metastatic ovarian tumors (25) and the distinction of metastatic ovarian carcinoma from the primary malignant ovarian neoplasm is crucial to its subsequent management, because diagnostic misinterpretation may have important adverse consequences for the patient.

Recently, it has been proposed that stem cells play a role in the development and progression of tumors. The concept of cancer stem cells (CSC) has been suggested as cells with the ability to self-renew and to produce the heterogeneous lineages of cancer cells that comprise tumors (24, 35). More importantly, CSC may not only be associated with tumor initiation and growth but may also play a crucial role in tumor metastasis (14). The prognosis of patients with metastatic colorectal carcinoma is poor despite recent advances in diagnostic and therapeutic techniques (9, 21, 42). An understanding of the biological nature of this neoplasm is needed to improve the prognosis of patients. In vitro stable growing human CRC cell lines can be the most suitable tool for this purpose, because such cells are applicable to a variety of experiments to understand tumor biology and the role of CSC.

We have established a tumor-initiating cell line NANK that does not share characteristics with the previously reported CSC. In the present study, we described the cell phenotype of NANK, including the in vitro and in vivo growth characteristics and the gene expression profile.

Utilization of NANK could contribute to the development of CSC research by providing a novel biological feature of CSC, which may lead to finding future therapeutic targets on colon cancer-initiating cells.

Materials and Methods

Tumor Tissues and Xenograft Preparation

Tumor tissues were obtained from colorectal primary and metastasis to the ovary from a 41-year-old Japanese female, with a T4 N4 M1 Stage IV advanced colon cancer. The Ethics Committee of Okayama University Hospital approved this study and the subject gave her informed consent for participation in the present study.

Briefly, the colonic and ovarian tissue specimens were minced with scissors into small (2 mm³) fragments and implanted intraperitoneally through a small incision on the animal's abdominal cavity into 6–8-week-old NOD/SCID mice (Charles River Laboratories). The tissue fragments were implanted separately in different mice.

Isolation and In Vitro Expansion of Tumor Cells From a Xenograft Derived From Colon Metastasis to the Ovary

A solid tissue collected from mouse xenograft was mechanically and enzymatically disaggregated into single-cell suspension and incubated with 200 U/ml of collagenase type IV (Sigma) and DNase I (Roche) for 1 h at 37°C to obtain enzymatic dissociation. Cells were then resuspended by pipetting and serially filtered by using sterile gauze and, 100- and 40-μm nylon meshes. After filtration, cells were plated at 10,000 cells/ml in a T25 flask on DMEM (GibcoBRL/Invitrogen, Co.) supplemented with 10% FBS (Cansera International, Inc, Ontario, Canada) and 120 μg/ml penicillin, 100 μg/ml streptomycin, at 37°C in a humidified atmosphere with 5% carbon dioxide. The medium was routinely changed every 2–3 days. Cells derived from this ovarian tissue were designated as NANK.

Immunofluorescence Study

NANK, human colon adenocarcinoma cell line Colo320 (ATCC), and human ovarian mucinous adenocarcinoma cell line JHOS-2 (purchased from Summit Pharmaceuticals Intl. Corp., Japan) were grown in eight-chamber culture slides and then fixed with 4% paraformaldehyde. The slides were subjected to double immunofluorescence using anti-CDX 2 mAb and anti-actin mAb (Millipore Japan, Tokyo, Japan). Cy3-labeled goat anti-rabbit IgG and FITC-labeled goat anti-mouse IgG (Jackson ImunoResearch Laboratories, Inc., West Grove, PA) were used as secondary antibodies. Hoechst33258 (Sigma Aldrich Japan, Japan) was used for nuclear counterstaining. In another set of experiments, NANK, Colo320, and another human colon cancer cell line, WiDr, were stained to evaluate the expression of cytokeratin 7 (CK 7) and cytokeratin 20 (CK 20) using anti-human CK 7 mAb (Abcam, clone Ks20.8, Tokyo, Japan) and anti-human CK 20 mAb (Abcam, clone OV-TL 12/30, Tokyo, Japan). Cy3-labeled goat anti-mouse IgG (Jackson ImunoResearch Laboratories, Inc.) was used as secondary antibody.

Reverse Transcriptase-Polymerase Chain Reaction (RT-PCR) Analysis

Total RNA was extracted from NANK cells using TRIzol (Invitrogen) reagent according to the manufacturer's instructions. Reverse transcription (RT) was performed at 22°C for 10 min, followed by 42°C for 20 min, using specific primers with 2.0 μg of RNA per reaction. The following primers were used: Oct-4, sense 5′-GAGCAAAACCCGGAGGAGT-3′ and antisense 5′-TTCTCTTTCGGGCCTGCAC-3′; nanog, sense 5′-GC TTGCCTTGCTTTGAAGCA-3′ and antisense 5′-TTC TTGACTGGGACCTTGTC-3′; BMI-1, sense 5′-GGA GACCAGCAAGTATTGTCCTTTTG-3′ and antisense 5′-CATTGCGCTGGGCATCGTAAG-3′; P53, sense 5′-CTGAGGTTGGCTCTGACTGTACCACCATCC-3′ and antisense 5′-CTCATTCAGCTCTCGGAACATCTCGA AGCG-3′; APC, sense 5′-TCATGATAAGGATGAT ATGTCGC-3′ and antisense 5′-AATTCTGCAATGGC CTGTAGTC-3′; Bcl-xL, sense 5′-GGAAAGCGTAGA CAAGGAGATGC-3′ and antisense 5′- GGTGGGAGG GTAGAGTGGATGGT-3′; caspase 3, sense 5′-TGAT GATGTGGAAGAACTTAGG-3′ and antisense 5′-AC GGCTCCGCACCTGCTGAGGC-3′; CD133, sense 5′-ACATGAAAAGACCTGGGGG-3′ and antisense 5′-GA TCTGGTGTCCCAGCATG-3′; CD44, sense 5′-CCAA GATGATCAGCCATTCTGG-3′ and antisense 5′-AA GACATCTACCCCAGCAAC-3′; and GAPDH, sense 5′-TCCCCATCACCATCTTCCAG-3′ and antisense 5′-GAGTCCTTCCACGATACCAA-3′.

PCR products were resolved on 1% agarose gels and visualized by ethidium bromide staining. Human glyceraldehyde-3-phosphate dehydrogenase (GAPDH) served as an internal control for cDNA synthesis. mRNA expression levels were normalized relative to GAPDH and expressed as folds of relative intensity.

Irradiation Experiments, MTS and FACS Analyses

NANK and SW620 were cultured at a density of 3 × 10⁴ cells per well in flat-bottomed 96-well plates. After 24 h cells were irradiated with 4 Gy. Forty-eight hours after irradiation, the cell viability was determined MTS assay, according to the manufacturer's instructions, and the absorbance was measured at 492 nm.

To determine the percentage of CD133 and CD44 cells after irradiation in NANK, 1 × 10⁶ cells were plated in T75 flasks in DMEM supplemented with 10% FBS. Twenty-four hours later, cells were subjected to irradiation at 4 Gy. The cells were collected 48 h after irradiation, stained with anti-CD133 and anti-CD44 antibodies, and analyzed by FACS. As an isotype control, CD133-APC and IgG2b-APC (Miltenyi Biotec) and IOTest CD44-FITC and IgG1-FITC (Miltenyi Biotec) were used for CD133 and CD44 staining, respectively.

Protein and Cytokine Assays

NANK was maintained in DMEM, supplemented with 10% FBS and 100 U/ml penicillin, 0.1 mg/ml streptomycin. When confluent (>90% of the surface is covered) in T25 flasks, the cells were shifted to serum-free DMEM medium and cultured 24 h, at 37°C and 5% CO₂. Conditioned medium (CM) was then collected and passed through a 0.45-μm filter membrane (Sartorius, Hannover, Germany). The composition of NANK-derived conditioned medium was analyzed using a high-density protein array according to the manufacturer's instructions. Serum-free DMEM was used as a control.

Flow Cytometry and Cell Sorting Experiments

NANK was magnetically labeled and separated by double passage using a human CD133 cell isolation kit (Miltenyi Biotec). Before separation, samples were assessed using a FACSCalibur flow cytometer, mouse IgG2b conjugated to APC was used as isotype control (Miltenyi Biotec). CD133 expression was assessed using human anti-CD133/1(AC133)-Biotin (Miltenyi Biotec). At least 10,000 events were acquired for each sample and all cells positive for propidium iodide were gated out. After magnetic bead separation, samples were assessed by flow cytometry to define purity.

Transplantation of NANK Cells in NOD/SCID Mice

Six- to 8-week-old NOD/SCID mice (Charles River Laboratories) were used as recipients. All animal procedures were approved by the Okayama University Institutional Animal Care and Use Committee, and thus within the guidelines for human care of laboratory animals.

CD133^- NANK at a density of 1 × 10⁴, 5 × 10⁴, and 1 × 10⁵ were diluted in 500 μl of Matrigel and transplanted into the peritoneal cavity of the mice (n = 3) for each dilution. All mice were sacrificed when tumors were palpable measured 10 mm, or at the first sign of suffering, between 8 and 12 weeks posttransplantation.

Histological and Immunohistochemical Analyses

At the time of sacrifice, tumors were removed and fixed in 20% formalin, and embedded in paraffin. Serial tissue sections were cut and stained with hematoxylin and eosin. Fixed, paraffin-embedded tissue sections were then examined immunohistochemically using the mouse monoclonal antibody to human CK 7, CK 20 (DakoCytomation, Carpinteria, CA), p53, p21 (Santa Cruz Biotechnology, Inc., Santa Cruz, CA), PCNA (NOVOCASTRA Laboratories, UK) rabbit antibody to human CDX-2 (BioGenex, San Ramon, CA). Tissue sections were stained with an automated immunostainer (Ventana XT system BENCHMARK, Ventana, Japan) using heat-induced epitope retrieval and standard DAB detection kit (Ventana). For detection of each signal, endogenous peroxidase activity was quenched by immersion in 3% hydrogen peroxide for 10 min, before the process by automated imunohistochemistry. Tissue sections were also stained with CD133/1 (AC133 Miltenyi Biotec) or with anti-human CD44 (G44-26, BD Pharmingen™) by employing the automated immunostainer. Samples were examined under a confocal laser scanning microscope (LSM510, Carl Zeiss, Germany). Primary colon, metastatic ovarian tissue samples obtained from the patient, as well as colon and ovarian xenograft tissues were also prepared for staining.

Statistical Analyses

Mean values are presented with SDs. Significance was determined by t-test using p < 0.05 as significant.

Results

Patient Characteristics

We obtained colon and ovary tumor specimens from a 41-year-old female with advanced colon cancer Stage IV. Before surgery her CEA serum levels were 741 μg/L [normal range is 0–2.5 μg/L (less than 3 ng/ml)], CA19-9 levels were 1607 U/ml (normal levels less than 40 U/ml), and the serum marker CA125 for ovarian carcinoma was 33.1 U/ml (normal values range from 0 to 35 U/ml).

The Xenograft Tissues Recapitulated the Histological Characteristics of the Parental Tumors

The colon primary tumor and its metastatic foci to the ovary as well as the xenografts in NOD/SCID mice shared similar characteristics (Fig. 1). On microscopic examination, both the colon primary tumor and its metastatic foci to the ovary showed predominantly moderately differentiated adenocarcinoma with fused glands, and mucin production, which was mixed with poorly differentiated adenocarcinoma at deeper site of invasion (Fig. 1A, B). Noticeably, both the colon and the ovary xenografted tumors were as well moderately differentiated adenocarcinoma in combination with multiple poorly differentiated adenocarcinoma foci, some parts of which showed mucin production and they histologically were partially similar to those in primary lesion from the patient (Fig. 1C, D).

Figure 1.

Immunohistological characterization of the primary and xenograft tumor tissues. H&E for morphological appearance of the tumor and immunohistochemistry for CK 20, CK 7, and CDX-2 of human and xenograft cancer tissues. The expression of CK 20, CK 7, and CDX-2 is indicated by brown signal. (A) Primary tissue of colon cancer, (B) colon metastatic tumor tissue to the ovary, (C) primary colon cancer xenograft, and (D) metastatic ovarian xenograft formed intraperitoneally in NOD/SCID mice. Scale bar: 200 μm.

The primary colon and metastatic ovarian tumors were positive for CK 20 and CDX-2 (Fig. 1A, B), an important nuclear transcription factor involved in intestinal-type differentiation, and they showed absence of CK 7 (Fig. 1A, B). This combination of markers has been useful to distinguish between primary and metastatic tumors from colon origin (41). Xenograft tissues showed a very similar pattern, with positivity for CK 20 and CDX-2 and absence of CK 7 (Fig. 1C, D).

Establishment and Long-Term Culture of NANK

An intraperitoneal xenograft model was used in an attempt to establish a cell line derived from a metastatic ovarian tumor of a patient with primary colon cancer. After 6–8 weeks, the xenograft tissue was explanted and isolation of the cells was performed. We successfully established a new cell line from the ovarian tumor specimen and it was designated NANK. The NANK cells grew as an adherent monolayer, showing spindle-like morphology when subconfluent, whereas when confluent the cells showed cobblestone-like shape (Fig. 2A). NANK maintained the consistent morphology from the primary culture to the following passages. After cryopreservation, thawed NANK was able to propagate in culture without noticeable change in growth and morphology (Fig. 2B). NANK has grown continuously in vitro for more than 18 months.

Figure 2.

In vitro morphological and immunohistochemical characteristics of NANK cells. (A) Morphological appearance of NANK in vitro. No change in morphology (cobblestone like shape) when the cells reach confluency. (B) Morphological appearance of NANK in vitro after cryopreservation. NANK maintained the same features even after crypreservation. Scale bar: 50 μm. (C) Representative immunofluorescent images of actin and CDX-2 in NANK. (D) JHOS-2, used as a negative control. (E) Colo320, used as a positive control. Green signal in the cytoplasm was for actin, and red signal in the nuclei was for CDX-2. Hoechst was used for nuclear counterstaining. Scale bar: 50 μm.

Characterization of NANK

The expression of CDX-2, an intestine-specific transcription factor that regulates both proliferation and differentiation in intestinal epithelial cells, was evaluated in NANK. NANK revealed nuclear-positive staining of CDX-2 (Fig. 2C), but the human ovarian adenocarcinoma cell line JHOS-2, used as a negative control, was almost negative for CDX-2 expression (Fig. 2D). On the other hand, CDX-2 was clearly expressed in Colo320 (Fig. 2E). To further confirm whether NANK is of colonic origin, we examined the expression of CK7 and CK20 in NANK on the basis of the previously accumulated surveys (9, 18). Typically, most of the colonic adenocarcinomas are CK 7^-/CK 20⁺, whereas ovarian adenocarcinomas are usually CK 7⁺/CK 20^-. In accordance with the staining pattern of CK 7 and CK 20 observed in the primary colon and metastatic ovarian tumors, the expressional pattern of these two markers in NANK was completely consistent with those of the parental colon tumor (CDX-2⁺/CK 20⁺/CK 7^-) (Fig. 3A). Examining the two representative human colon cancer cell lines Colo320 and WiDr as comparative examples for NANK, CK 7 expression was almost negative in Colo320, whereas in WiDr faintly expressed it (Fig. 3A).

Figure 3.

Protein and gene expression profiles of NANK. (A) Representative immunofluorescent images of CK 7 and CK 20 in NANK, Colo320, and WiDr. Red signal in the cytoplasm was for CK 7 and CK 20, and Dapi was used for nuclear counterstaining. Scale bar: 25 μm. (B) Gene expression profile of Oct-4, Nanog, BMI-1, p53, APC, Bcl-xL, caspase 3, CD133, and CD44 were analyzed in NANK by RT-PCR. hESC served as a positive control and no RT products served as negative controls. GAPDH was used as an internal control. (C) mRNA expression levels were normalized by relative to the internal control GAPDH. The data are representative of at least three independent experiments with similar results.

To further characterize NANK, a genetic expression analysis was performed and shown in Figure 3B. NANK lacked the expression of the putative stem cell markers Oct-4 and Nanog. However, it had a very intense expression of the proto-oncogene BMI-1 (Fig. 3B, C). Both of the tumor suppressor genes p53 and APC were present in NANK cells, two markers well known for being mutated in most cancer cell lines (28, 40). The antiapoptotic gene Bcl-xL was expressed in NANK, whereas the pro-apoptotic gene caspase-3 was absent. As for the surface markers, CD133 and CD44, both were absent in NANK cells (Fig. 3B, C). Taking these data together, NANK cells display specific tumor properties. Reactivation of cytoprotective pathways may provide NANK with the ability to escape conventional anticancer treatments.

CSC Markers (CD133/CD44) Did Not Emerge in NANK After Irradiation

It has been reported that CSC, specifically CD133 and CD44 populations, can be enriched after irradiation (3, 33). To evaluate whether irradiation could enhance CD133 or CD44 subsets in our cell line, NANK cells were exposed to 4 Gy of irradiation. Forty-eight hours after irradiation, CD133 and CD44 populations were evaluated in NANK and we found no significant increase in these two populations (for CD133 expression of NANK: before = 0.1%, after = 0.095%, isotype control = 0.83%; for CD44 expression of NANK: before = 0.16%, after = 0.19%, isotype control = 0.22%) (Fig. 4A, B). At least three independent experiments were performed in different passages of NANK. Next we investigated a biological difference in irradiation sensitivity between NANK and SW620, which contains high percentage of conventional CSC markers CD133 and CD44 (unpublished data), by exposing the cells to 4 Gy of irradiation. NANK was more sensitive to irradiation than SW620, showing a nonsignificant decrease in the cell survival (Fig. 4C). The finding is in accordance with the previous reports in which CD133⁺ cells have shown to be more resistance to irradiation than CD133^- cells (5, 49).

Figure 4.

Expression of CD133 and CD44 in NANK after irradiation. (A) The expression of CD133 was assessed in NANK before and 48 h after irraditation (4 Gy) by FACS analysis. No positivity for CD133 was found in NANK. (B) The expression of CD44 was assessed in NANK before and 48 h after irradiation (4 Gy) by FACS analysis. No positivity for CD44 was detected in NANK. Mouse IgG2b conjugated to APC (CD133) and mouse IgG1 conjugated to FITC (CD44) were used as an isotype control and cells without staining served as a negative control. (C) Percentage of cell death quantification by MTS assay in NANK and SW620 48 h after irradiation.

Production of Cytokines and Growth Factors in NANK

We analyzed the conditioned medium of NANK to know whether NANK produced any cytokine responsible for the tumorigenic potential. NANK secreted many cytokines involved in angiogenesis, one of the conditions necessary for cancer metastasis and to sustain tumor growth, such as angiogenin, epidermal growth factor (EGF), granulocyte colony-stimulation factor (GCSF), tumor necrosis factor-α (TNF-α), vascular endothelial growth factor (VEGF), angiopoietin, and ENA-78. NANK cells also produced considerable amounts of IL-1a and IL-1b, which have also been shown to promote tumor invasiveness and angiogenesis (44).

In Vivo Tumor-Initiating Ability of NANK

In order to identify the presence of cancer stem cells in NANK, by means of the surface marker CD133, which has been demonstrated to be present in several normal and malignant stem cells of different tissues (14, 31, 34), and have been considered to be tumor-initiating cells, NANK cells were labeled with CD133 antibodies and analyzed by FACS. FACS analysis revealed the absence of CD133⁺ cells in NANK (Fig. 5A). In order to test whether this CD133^- population was capable of initiating tumor formation, as was previously reported (36), NANK cells at a density of 1 × 10⁴, 5 × 10⁴, and 1 × 10⁵ were intraperitoneally transplanted in NOD/SCID mice. When 1 × 10⁴ CD133^- cells were transplanted, two out of three mice developed tumors, whereas in mice transplanted with 5 × 10⁴ and 1 × 10⁵ cells, tumors were developed in all of them and in a shorter period of time (Fig. 5B). The animals showed peritoneal dissemination with ascities (Fig. 5C). Evaluation of the ascitic fluid revealed high levels of CEA and CA-19–9 (Fig. 5D).

Figure 5.

Intraperitoneal transplantation of NANK in NOD/SCID mice. (A) NANK showed no significant CD133 expression by FACS. (B) Different cell numbers of NANK were injected intraperitoneally in NOD/SCID mice. ^aNumber of tumors formed from the total mice injected. ^bAverage in days of the tumor formation. (C) Representative images of the tumors formed by NANK in NOD/SCID mice. The arrowhead indicates the presence of ascities and arrows depict the peritoneal dissemination. (D) CEA and CA-19-9 levels in the ascites in mice (n = 3).

Analysis of Tumors Developed After NANK Cells Transplanted in Mice

H&E staining of tumors grown in mice after injection of CD133^- NANK revealed the formation of tumors producing mucin, with glandular formation, thus sharing some of the characteristics from the xenograft tumors. These tumors were predominantly poorly differentiated adenocarcinomas. When stained for CDX-2, only focal expression was found in very few areas, mainly with no reactivity for this marker (Fig. 6A). In contrast, a diffuse immunoreactivity for both CK 7 and CK 20 was positively observed in NANK-initiating tumors (Fig. 6A). The tumors derived from NANK cell injection demonstrated a positive and diffuse immunoreactivity for p53, indicating the presence of a mutated form of p53 protein, whereas p21, which is a downstream of p53, was almost absent in the tumor tissues (Fig. 6A). We found a very clear and diffuse immunoreactivity for PCNA, a marker of cell cycle, in the tumors. NANK-derived tumors were immunohistologically compared with those derived from the xenograft tissues developed after the implantation of the primary colon and ovary metastatic tumors. While the colon and ovarian xenograft tissues maintained a very similar immunohistological characterization with exception of p21, which was not analyzed in these tumors (Fig. 6B, C), tumors derived from NANK showed two main immunohistological alterations: the loss of CDX-2 and the acquisition of CK 7 (Fig. 6A).

Figure 6.

Immunohistological characterization of the tumors formed by NANK in comparison with the xenograft tumor tissues. (A, B, C) Images of H&E staining and immunohistochemistry for CDX-2, CK 20, CK 7, p53, PCNA, and p21 of NANK-forming tumors in NOD/SCID mice (A), primary colon xenograft (B), and metastatic ovarian xenograft (C) formed intraperitoneally in NOD/SCID mice. Scale bar: 200 μm. (D) Images for CD133 and CD44. Scale bar: 200 μm.

Tumors Derived From Transplanted NANK Cells Recapitulated the Phenotype of the Primary Colonic and Metastatic Ovarian Cancers in Terms of CSC Markers

Next, the expression of CD133 and CD44, both of which were previously reported as consensus CSC markers, was examined in the primary colon cancer, its metastatic cancer to the ovary, and tumors derived from NANK cell injection by immunohistochemistry. Both CD133 and CD44 were positive in the primary colon tumor and ovarian metastatic tumor (Fig. 6D). Interestingly, the tumor derived from NANK comprised the mixture of CD133^- (major population) and weakly CD133⁺ cells (very minor population), which was similarly observed as a mixture of CD44^- and weak CD44⁺ cells. These results indicated that NANK, not totally but partially, recapitulated the same immunophenotypes as their primary and metastatic counterparts (Fig. 6D).

Discussion

In the process of tumorigenesis many factors are believed to play an important role. Among them, CSCs are believed to have the tumor-initiating capacity in many cancers. The isolation of these cells have been possible in a variety of tumors (14, 31, 34, 36) through different surface markers, such as CD133 for colon and brain tumors where it is believed that only the CD133⁺ population can initiate tumor development (31, 34, 38). Although it has been recently proposed that not only CD133⁺ cells but also CD133^- cells are endowed with tumorigenic capabilities when derived from metastatic tumors (36).

To date, there is a wide variety of markers used to identify CSCs from other cancers: CD44⁺/CD24^- for breast tumors (1), Sca-1⁺/CD45^-/PECAM^-/CD34⁺ for adenocarcinomas (22), and CD44⁺/α2β1⁺/CD133 for prostate cancers (8), which suggests that there are not perfect markers to represent CSCs. In addition, the ability to form tumors depends not only on properties inherent to cancer cells, but also on the host microenvironment, which plays a major role in tumor initiation and progression (13, 29).

We here demonstrated that a cell line derived from colon metastasis to the ovary, NANK, lacking the surface marker CD133, was able to initiate tumors when transplanted intraperitoneally into NOD/SCID mice.

Moreover, we also analyzed the possibility of NANK to contain a subpopulation positive for the other well-known stem cell marker CD44 and we found no expression of CD44 by RT-PCR and FACS analyses (Figs. 3 and 4). In spite of these findings, NANK cells were capable of developing aggressive peritoneal tumor dissemination in the mice with ascities formation and showing high levels of tumor markers CEA and CA19–9 in the ascitic fluid. The tumors recapitulated the features of the parental colon and its metastatic ovarian tumors.

First, we sought to determine the origin of the metastatic ovarian tumor. Clinically, the expression of CK 20, as well as CK 7 and CDX-2, has been used to discern the primary lesions from metastatic adenocarcinomas in the ovary (41, 46). The expression of CK 20 is restricted to a limited group of adenocarcinomas. It is detectable in almost all colon cancers, about half of gastric and pancreato-biliary carcinomas, and about 30% of transitional cell carcinomas (6). Although several patterns have been reported (6, 15), our findings are in accordance with some reports where metastatic ovarian carcinomas from lower gastrointestinal tract origin are CDX-2⁺/CK 20⁺/CK 7^-. The xenograft tissues from which NANK cells were derived preserved the same pattern of CDX-2⁺/CK 20⁺/CK 7^-.

CDX-2 is a member of the caudal-related homeobox family and is an intestine-specific transcription factor that regulates both proliferation and differentiation in intestinal epithelial cells. It has been shown to be expressed in a high proportion of colon carcinoma (61–100%) (20, 41, 46), or be downregulated in the later stages of human colon carcinogenesis, namely, high-grade dysplasia and invasive carcinoma (10). We found CDX-2 to be expressed in NANK, which might account for the spontaneous differentiation of the cells once they reach confluency (Fig. 2A). In addition, we found the expression of CK 20 and absence of CK 7 in NANK in vitro, similar to the pattern found in the primary colon and its metastatic ovarian cancers as well as in the xenograft tissues (Figs. 2 and 3).

Self-renewing activity and extensive proliferation are some of the hallmarks of stem/progenitor cells in culture, and, to some extent, these capabilities are believed to be conferred by the expression of Nanog and Oct-4 genes (11, 30). NANK cells did not express these self-renewal markers, but instead they had another mechanism to proliferate by expressing the polycomb group gene BMI-1, which is recognized to play an essential role in regulating the proliferative activity of both normal and leukemia stem cells (17, 26, 32). Overexpression of BMI-1 was in fact described in several types of cancers (23, 43), and it is believed to confer a high degree of malignancy when BMI-1 is coexpressed with other proteins from the PcG, such as EZH2 (4). Moreover, NANK expressed p53 and APC, which are well-known markers to be mutated in several cancer cell lines. These markers in combination with the apoptosis inhibitor Bcl-xL conferred NANK cells a mechanism to survive and proliferate malignantly.

Angiogenesis performs a critical role in the development of cancers and influences the dissemination of cancer cells throughout the entire body, eventually leading to metastasis formation. NANK cells produced several proangiogenic factors such as VEGF-D, IL-1α, and IL-1β, which are required for in vivo angiogenesis and have been associated with the promotion of metastatic spread of tumor cells (39, 44). VEGF expressed in tumors is identified as responsible for the formation of tumor vessels that not only allow for progression of the primary tumors, but also facilitate cancer cells to access the tumor vessels (12, 44). In accordance with these findings, we can speculate that the high expression of growth factors related with angiogenesis by NANK could be one of the many factors bestowing them with a metastatic potential.

As previously mentioned, NANK cells did not express CD133 or CD44, expressed in normal and cancer stem cells, nor did they express the self-renewal genes Oct4 and Nanog. However, NANK cells had the potential to initiate tumor formation when a small number of cells were intraperitoneally transplanted, in accordance with the previous reports in which transplantation of a CD133^- population (36) was capable of developing tumors. It is also possible that the presence of a small subset of CSC is contained in NANK. Identification of such a subset that may be responsible for its malignant potential is now under investigation.

The property of resistance to chemotherapy and irradiation is the major clinical criterion to characterize “cancer stem-like cells” (19). The existence of cancer stem-like cells may explain why conventional anticancer therapies are able only to suppress or shrink a tumor but often cannot completely eradicate such cells, resulting in eventual recurrence of tumors (7, 19). NANK cells in vitro were comparably sensitive to irradiation (to slightly higher extent) when compared with SW620 that possess a high percentage of CD133⁺ and CD44⁺ cells (unpublished data). The finding may indicate that NANK is not endowed with neither of the well-known CSC markers CD133 and CD44, thus leading to be irradiation sensitive in vitro. Interestingly, when NANK was transplanted in NOD/SCID mice, CD133- and CD44-expressing cells were emerged in the resultant tumors in vivo. Detailed mechanism of this phenomenon still remain unclear at this moment; however, similar findings have been reported by previous studies using in vivo brain tumor models (45).

The tumors derived from NANK cells were able to recapitulate the morphological characteristics from the primary colon, metastatic ovarian, and xenograft tumors. While the expression of CK 20 was preserved, the tumors acquired CK 7 expression, which was absent in the parental tumors (Figs. 1A–D and 6A–C). Although it is well recognized that the majority of tumors derived from the gastrointestinal tract lack the expression of CK 7, there have been other reports showing its presence but in a quite low frequency (48). In addition, CK 7 expression is associated in combination with CK 20 expression in advance colorectal cancers. Therefore, the acquisition of CK 7 expression may correlate with the progression of the clinical staging (15). On the other hand, tumors derived from NANK dramatically lost CDX-2 expression (Fig. 6A), which remains a possible consequence of the dysregulation that accompanies tumor progression. The decreased expression in CDX-1 and /or CDX-2 is associated with progression to the more advanced stages of colorectal tumorigenesis (16, 27). The decreased CDX-2 expression in NANK-derived tumors is correlated with the histological status of poorly differentiated adenocarcinomas. When CDX-2 was diffusely expressed in the tumors, they were diagnosed as moderately differentiated adenocarcinomas. The histological findings of NANK-derived tumor are in accordance with previous studies suggesting the critical role of CDX-2 in the maintenance of the intestinal phenotype (37). CDX-2 is also suggested as a proliferation inhibitor through the upregulation of the p21 gene, considered to be a transcriptional target of CDX-2 (2).

The absence or almost no expression of CDX-2 in NANK-derived tumors resulted in the downregulation of p21. In addition, the status of p53 was mutated in NANK tumors, leading to the loss of the effect in p21. Therefore, cell cycle inhibition was not accomplished in the tumor cells, which was supported by the wide expression of PCNA (Fig. 6A).

In conclusion, we have shown that our newly established human colon cancer cell line NANK lacks the important conventional CSC markers such as CD133 and CD44, Nanog, and Oct/4, while being capable of initiating tumors and developing aggressive progression with CEA and CA-19-9 synthesis and metastatic potential in NOD/SCID mice. These findings may contribute to provide another novel aspect of CSC biology.
