Pharyngeal dermoid cyst causing partial upper airway obstruction in a cat

Abstract

Case summary

A 2-year-old cat was presented with nasopharyngeal stridor and stertor. Radiographs of the upper neck region showed a mass lesion in the nasopharynx. A nasopharyngeal polyp was suspected, but an attempt at endoscopic removal failed, owing to fragmentation of the mass and excessive haemorrhage. A sample was taken and histology confirmed a dermoid cyst. CT was performed and the lesion was described as most likely to be a dermoid cyst, consistent with the histopathological findings. Surgical exploration and subsequent complete removal of the mass led to a full recovery.

Relevance and novel information

The nasopharyngeal location represents a previously unreported location of a dermoid cyst. This report raises awareness of dermoid cysts as a potential differential diagnosis within the nasopharyngeal region and highlights the importance of pre-interventional diagnostic imaging.

Case description

A 2-year-old female neutered domestic shorthair cat weighing 4.1 kg was presented to the Small Animal Department of the University of Veterinary Medicine Vienna with progressive stridor and stertor exacerbated by exercise. Coughing was noticed occasionally. Other clinical parameters, including exploration of the oral cavity and blood work were unremarkable, and a tentative diagnosis of a nasopharyngeal polyp was made. A two-view radiographic examination of the upper neck was performed and revealed an oval mass lesion about 2.8 cm long and 1.4 cm high with heterogeneous fat and soft tissue opacity in the nasopharynx. The mass extended from the temporomandibular joint to the larynx, completely obliterating the nasopharynx. The lesion had a convex caudal margination and created a mass effect by depressing the soft palate (Figure 1). The tympanic bullae were air filled with a thin intact wall. A nasopharyngeal polyp was considered likely, but differential diagnoses included granuloma, abscess or foreign body reaction, cyst or neoplasia. ¹

Figure 1

Heterogeneous fat and partial soft tissue opacity nasopharyngeal mass lesion depressing the soft palate

The cat underwent endoscopic examination of the upper airway to remove the suspected polyp. Analgesia was provided with buprenorphine (20 µg/kg IV) and meloxicam (0.05 mg/kg IV). The mass was found to be hemispheric, broad-based, located on the right side of the nasopharynx and extending caudally to the soft palate (Figure 2).

Figure 2

Appearance of the mass located in the right nasopharynx during endoscopic examination. Arrow points to the endotracheal tube

Endoscopic removal failed as the mass could not be mobilised efficiently, and it fragmented when attempting to remove it with torqueing. Partial laser ablation of the mass was performed because of bleeding and swelling. After removing a small amount of soft tissue, a hair shaft was found within the cystic lumen. Ablation was performed as far as possible, and the extracted specimens were fixed in 4% neutral buffered formalin and sent to the Institute of Pathology at the Veterinary University of Vienna for histopathological examination. An oesophagostomy tube was placed to provide nutritional support.

Sections of 4 µm thickness were prepared from five 5 × 2 × 2 mm to 3 × 3 × 3 mm, white-to-greyish soft tissue pieces and stained with haematoxylin and eosin (Figure 3). The samples consisted of normal skeletal muscle, adipose and collagenous connective tissue with some degree of heat denaturation due to the surgical technique utilised. The specimens were partially covered by keratinising, flattened squamous epithelium accompanied by abundant luminal accumulation of lamellar, predominantly loosely packed orthokeratin and multiple hair shaft fragments (Figure 3a,b).

Figure 3

Dermoid cyst with a stratified squamous epithelium, skin adnexal structures and keratin and hair shaft congested cavity located in the pharynx. (a,b) Cystic cavity filled with loosely packed orthokeratin and numerous hair shaft fragments (arrowheads). The right side of (a) shows the cystic wall, delimiting the cavity; bar represents 300 μm in (a) and 40 μm in (b). (c) The microscopic examination of the cross-section revealed fibrovascular stroma covered by an epithelial cell lining compatible with pharyngeal mucosa (asterisk) on the right-hand side, whereas on the left-hand side an epidermal-like well-differentiated, stratified, keratinising epithelium (cross) depicting the luminal cover of the cystic wall was seen. Adjacent to the epidermal-like epithelium, focal accumulation of skin adnexal structures (AD) resembling folliculo-sebaceous hair units, as well as oligofocal interspersed groups of adipocytes (A), are presented (bar represents 300 μm). (d) Cystic wall consisting of fibrovascular stroma lined by cornified, stratified, squamous epithelium (cross) compatible to epidermal epithelium with marked hyperkeratosis (K; bar represents 80 μm). (e) Focal area with skin adnexal structures displaying hair follicles (HF), sebaceous glands (SG) and as sweat glands (AG) embedded in a dermal-like stromal compartment (bar represents 80 μm). (f) Pharyngeal cutaneous mucosa showing fibrovascular stroma lined by non-cornified, stratified, squamous epithelium (asterisks; bar represents 80 μm)

As complete surgical removal was not possible, further work-up was initiated. CT examination was performed the next day (Somatom Emotion 16 CT; Siemens) to evaluate the extent of the lesion. CT imaging showed a rounded, well-defined mass approximately 3.7 × 2 × 2 cm on the right side of the pharynx. The lesion showed a heterogeneous structure with mainly fat attenuation and more centrally located linear and rounded soft tissue attenuation areas. Contrast enhancement was not seen. The mass lesion extended from the pterygoid to the level of the craniocervical junction. It was bordered medially by the pharyngeal wall and laterally by the medial pterygoid muscle, the ceratohyoid and stylohyoid bone, the external carotid artery and the medial retropharyngeal lymph node. The mass bulged into the pharynx and caused marked luminal compression. Multiple gas bubbles were present in the surrounding soft tissues extending caudally along the fascial planes, consistent with the previous surgical procedure (Figure 4). Differential diagnoses from the CT included a primary dermoid cyst or, less likely, a lipoma with cystic content.

Figure 4

(a) Sagittal reformatted image showing marked rostrocaudal extension of the mass lesion ventral to the tympanic bulla and inherent rounded ventrally located soft tissue attenuating structure (arrow). There are multiple gas bubbles caudal to the lesion extending into the fascial planes of the neck consistent with emphysema. (b) Transverse image at the rostral level of the tympanic bulla showing a large mixed fat and soft tissue-attenuating mass lesion on the right side of the nasopharynx (arrow). The nasopharyngeal lumen is markedly displaced leftward and compressed (arrowhead)

Surgical excision was performed via the right upper neck region with the tympanic bulla as a landmark. A ventral skin incision was made, and soft tissues were bluntly dissected until a mass with soft tissue strands became visible. Two cysts were found adherent to the lipomatous mass on the medial aspect; one was filled with hair shaft fragments and the other with a yellowish content. Furthermore, laceration of the caudal nasopharynx and approximately 10 cm of the cranial oesophagus became visible. After closing the laceration with a #3/0 absorbable multifilament suture material, resection of the mass was continued.

The tissue was fixed and prepared as described above. Four soft tissue samples were analysed histologically. Large areas consisted of regular adipose tissue interspersed by small parts of skeletal muscle, partially accompanied by fibrinoid necrosis, demarcated by cell-rich, juvenile granulation tissue. One sample was widely confined by a cyst wall covered by keratinising, stratified, well-differentiated epidermal-like epithelium (Figure 3c,d) associated with moderate-to-marked hyperkeratosis (Figure 3d). The subepithelial fibrovascular stroma abutting the cyst wall harboured foci of skin adnexa (Figure 3c), including small hair follicles, sebaceous glands and apocrine sweat glands (Figure 3e). In close proximity to the adnexal structures, there were focally grouped adipocytes in the stromal connective tissue (Figure 3c). In contrast, the sample was lined with stratified squamous epithelium compatible with pharyngeal cutaneous mucosa (Figure 3c,f). These findings were consistent with a dermoid cyst.

The oesophagostomy tube was replaced with a gastrostomy tube to maintain appropriate feeding during the healing process. The cat recovered from anaesthesia without any problems and was sent home 3 days postoperatively. Analgesia was continued with buprenorphine (15 µg/kg IV q6h daily until discharge) and meloxicam (0.05 mg/kg PO for a total of 10 days). Food and water were administered via the tube for a period of 15 days, and weekly revisits were scheduled. Complications during this phase included loosening of the feeding tube plug and of the bandage. After 15 days, oral intake of water and liquid food was initiated. Twenty-two days postoperatively, a contrast media swallow using 10 ml amidotrizoate (Gastrografin; Bayer Vital) and fluoroscopy was performed. It showed no evidence of leakage and therefore the cat was fed orally with moist cat food. As the patient had no problems with the intake of conventional cat food, the gastrostomy tube was removed 29 days after placement.

Discussion

Although dermoid cysts have been reported in cats,^2–9 with a predisposition for the neck and shoulder region, ⁵ to our knowledge, this is the first report of such a cyst located within the nasopharynx.

The most common disease of the nasopharynx in young cats is inflammatory polyps arising from the lining of the middle ear or the Eustachian tube, usually causing stertor of the upper airways.^10–14 Diagnosis is made based on patient history and physical examination and supported by endoscopic evaluation, diagnostic imaging and histopathology.^13,15,16

Based on the signalment and history of this cat, a nasopharyngeal polyp was suspected; therefore, endoscopic evaluation was performed and removal by traction and avulsion was attempted. In this method, the polyp is grasped close to its base and gentle, steady traction is applied until it detaches.^11,13–15 If haemorrhage occurs, it is usually minimal and can be stopped by the application of pressure.^11,14,17 Because easy grasping of the mass was not possible in our case and persistent bleeding occurred, a different disease other than a nasopharyngeal polyp was suspected.

To determine this, a CT or MRI examination would have been helpful prior to any attempt to remove the mass. Although there are only a few reports regarding the appearance of dermoid cysts on CT and MRI, there are remarkable differences to nasopharyngeal polyps.^9,18–22 In one report of a dermoid cyst, including CT imaging findings, a cystic structure with mixed attenuation and a hypoattenuating centre was noted, ²⁰ which is comparable to the findings in our patient. In a study of 13 cats with nasopharyngeal polyps that underwent a CT examination, all masses were hypoattenuating to the adjacent musculature and isoattenuating to soft tissue. ²¹ Furthermore, all had an ill-defined shape, and there was no possibility of delineating them from surrounding structures. Most had a homogenous appearance and ill-defined borders. After administration of contrast medium, all masses had an oval appearance, showed hypoattenuation compared with soft tissue and had well-defined borders and rim enhancement. In some patients, the latter could be followed into the auditory tube.

In a few MRI reports regarding the appearance of dermoid cysts not associated with the spinal cord, they are described as well demarcated and heterogeneously hyperintense in T1 consistent with fat and fluid.^9,19 One report additionally described a thin rim, which took up contrast medium. ¹⁸ In comparison, MRI examination of nasopharyngeal polyps showed a stalk-like structure hyperintense in T2 vs grey matter, hypo- to isointense on T1 and a heterogeneous rim enhancement after the administration of contrast medium in one study. ²²

The treatment of choice for dermoid cysts is surgical removal, which has been reported to have excellent outcomes.^16,23,24 Consistent with our findings, keratinised squamous epithelial lining with keratin fragments, hair shafts and follicles are described in the histopathological examinations of these cysts.

Although it is unclear when the laceration of the oesophagus occurred in our patient, this complication is possible either secondarily to a process compromising the integrity of the oesophageal wall or during placement of an oesophageal feeding tube when the wall is friable, too large instruments are used to penetrate the wall or if there are multiple attempts at proper placement.^14,25 After the second surgery, in which laceration of the oesophagus was detected and addressed, a gastrotomy tube was placed. These tubes are indicated after surgery of the oesophagus, as an oesophagostomy tube can interfere with healing. ¹⁴

Conclusions

Although nasopharyngeal polyps are a very common cause of stertor in young cats, other differentials should be considered. Ideally, CT or MRI should be performed before attempting removal. When addressing a mass located in that region, veterinarians must be aware of the possibility of haemorrhage and equipment for haemostasis, as well as the possibility of converting from an endoscopic to an open approach, must be available.
