Prediction and follow-up of risk factors for severe SARS-CoV-2 pneumonia and application of CT visual scoring

Abstract

BACKGROUND:

The SARS-CoV-2 pneumonia infection is associated with high rates of hospitalization and mortality and this has placed healthcare systems under strain. Our study provides a novel method for the progress prediction, clinical treatment and prognosis of NCP, and has important clinical value for timely treatment of severe NCP patients.

OBJECTIVE:

To summarize the clinical features and severe illness risk factors of the patients with novel coronavirus pneumonia (NCP), in order to provide support for the progression prediction, clinical treatment and prognosis of NCP patients.

MATERIALS AND METHODS:

A total of 196 NCP patients treated in our hospital from January 25, 2020 to June 21, 2020 were divided into the severe group and the mild group. The clinical features of the two groups were analyzed and compared. The risk factors were explored by using multivariate logistic regression, and the receiver operating characteristic (ROC) curve was obtained. The correlations of the risk factors with the prognosis of NCP were investigated combined with the lung function test.

RESULTS:

The primary clinical symptoms of 196 cases of NCP included fever in 167 cases (85.2%) and cough in 121 cases (61.73%). The chest computed tomography (CT) scans of the 178 cases (90.81%) showed a typical ground-glass opacification. In 149 cases, the lymphocyte count was decreased, while the levels of creatine kinase (CK), lactate dehydrogenase (LDH), c-reactive protein (CRP), erythrocyte sedimentation rate (ESR) and D-dimer (D-D) increased. 44 cases (22.45%) were found to be severely ill. The multivariate logistic regression analysis demonstrated that age, underlying disease, length of hospital stay, body mass index (BMI), LDH, chest CT visual score, absolute lymphocyte count (ALC) and CRP were risk factors for severe

illness. The most valuable indicator for the prediction of severe NCP was the chest CT visual score. With a CT visual score of

<

8.97 as the cut-off, its prediction of severe illness gave a sensitivity of 93.22% and a specificity of 71.53%, and it was negatively correlated with the prognostic diffusing capacity of the lungs for carbon monoxide (DLCO%), with a coefficient of 0.702.

The primary symptoms of NCP were fever and dry cough, followed by a rapid disease progression. The chest CT visual score was found to exhibit a key role in the prediction of severe illness and prognosis, and served as an early warning indicator of severe NCP. The CT visual score opens up a new window for pre-critical research of NCP.

Keywords: Novel coronavirus, COVID-19, pneumonia, CT visual scoring, risk factors, prognosis

1. Introduction

Since a large-scale pneumonia outbreak of unknown etiology in Wuhan, China in December 2019, the Wuhan Institute of Virology, Chinese Academy of Sciences successfully isolated a new type of coronavirus from the culture of secretions of novel coronavirus pneumonia (NCP) patients and identified its genome sequence on January 7, 2020. The sequence of this virus is homologous to the severe acute respiratory syndrome (SARS) and Middle East respiratory syndrome (MERS). The virus has a round or elliptic envelope, often pleomorphic form, with a diameter of 60–140 nm [1, 2, 3]. On February 11, 2020 the World Health Organization (WHO) named it SARS-CoV-2. The virus caused multiple system infections in various animal species, and mainly respiratory infections in humans. The NCP caused by SARS-CoV-2 is highly contagious, and it has spread rapidly to 212 countries including the United States, Brazil, and Italy. Currently, the cumulative number of infections runs above 13.5 million, and the death toll is over 600,000. The SARS-CoV-2 quickly triggered the global public health emergencies and has caused a heavy health and economic burden on the world [4, 5].

There have been more than 300 reports reporting the imaging features, clinical features and treatment options of NCP on PubMed. The literature mostly summarized the imaging diagnosis, disease development and clinical outcomes of NCP, and rarely analyzed its risk factors, thus providing limited guidance to clinical treatment [6, 7]. In this pursuit, the present study explored the imaging and clinical data of 196 cases of NCP, and added the CT visual score to multivariate logistic regression for the first time and obtained encouraging research results. We successfully predicted the risk factors for severe NCP, including the length of hospital stay, body mass index (BMI), and chest CT visual score. Finally, in combination with the receiver operating characteristic (ROC) curve, we obtained the cut-off value for the CT visual score, and confirmed that the CT score was negatively correlated with the lung function indicators like forced vital capacity (FVC)%, total lung capacity (TLC)%, and diffusing capacity of lung for carbon monoxide (DLCO)%. Our study provides a novel method for the progress prediction, clinical treatment and prognosis of NCP, and has important clinical value for timely treatment of severe NCP patients.

2. Materials and methods

2.1 General information

The clinical, serum biochemical tests and imaging data of 196 subjects of laboratory-confirmed NCP with positive SARS-CoV-2 nucleic acid tested by RT-PCR were collected in our hospital from January 25, 2020 to June 21, 2020. There were 137 cases (69.89%) with positive nucleic acid results for the first round of screening, and 59 cases (30.11%) with positive results for the second or further round. The age range of patients was 19 $\sim$ 83, with an average of (51.7 $\pm$ 12.98) years old, including 107 males and 89 females (1.2:1). 117 patients (59.69%) exhibited a contact history with confirmed NPC patients, and 79 cases had no clear epidemiologic links. The incubation period was 1 $\sim$ 20 days, with an average of (8.09 $\pm$ 4.09) days. 80 cases (40.82%) had underlying diseases, such as chronic bronchitis, hypertension, coronary heart disease, diabetes, chronic obstructive pulmonary disease, and hepatitis B.

The clinical diagnosis and classification criteria were made according to the Novel Coronavirus Pneumonia Diagnosis and Treatment Plan (6 ${}^{\text{th}}$ Edition) released by the National Health Commission of the People’s Republic of China. The mild cases showed mild clinical symptoms, but absence of an obvious infection in imaging. The common cases were diagnosed from fever, cough, and local imaging. The severe cases were those, who met one of the following conditions: (1) respiratory distress, with respiratory rate of $\geqq$ 30 times/min; (2) hypoxemia, with oxygen saturation $\leqslant$ 93% on finger pulse oximeter taken at rest; and (3) arterial partial pressure of oxygen (PaO ${}_{2}$ )/fraction of inspired oxygen (FiO ${}_{2}$ ) $\leqslant$ 300 mm Hg (1 mm Hg $=$ 0.133 kPa). The critically ill cases met one of the following conditions: (1) respiratory failure, requiring mechanical ventilation; (2) shock; (3) combined failure of other organs [8, 9]. In the present study, the mild and common cases were grouped as mild, and the severe and critically ill cases were grouped as severe.

2.2 Imaging and lung function test

The CT scans were conducted with a Siemens SOMATOM Force 64-slice spiral CT, and the spiral scans were conducted from the apex to the base of the lung, when the patient was asked to hold breath after maximum inspiration. The tube voltage was 120 kV, the tube current was 200 mA, the slice thickness was 5 mm, and the pitch was of 3.0. The image window width was 1000 $\sim$ 1500 HU, and the window level was $-$ 500 $\sim$ $-$ 800 HU. Referring to the international scoring methods for idiopathic pulmonary fibrosis (IPF) lesions, the residual ground-glass opacification and interstitial shadows in the lungs (including interlobular septal thickening, subpleural curvilinear shadow, and irregular cords) were scored. Each residual lesion of lung lobe was scored from 0 $\sim$ 5 points (Table 1), and the total score for each medical sign was 0 $\sim$ 25 points.

Table 1
System for scoring the ground-glass opacity, interstitial opacity on thin-section CT scans

Score	Definition
0	None
1	$<$ 5% of the lobe
2	5–25% of the lobe
3	26–49% of the lobe
4	50–75% of the lobe
5	$>$ 75% of the lobe

The Minato AS-507 spirometer (Japan) was used to measure the following indicators for 192 recovered patients: the percentage of forced expiratory volume in one second to the predicted volume (FEV1.0%), the percentage of forced vital capacity to the predicted value (FVC%), and the percentage of total lung capacity to the predicted value (TLC%), and the percentage of single-breath diffusing capacity to the predicted value (DLCO%).

2.3 Statistical analysis

The symmetric distributed measurement data was represented by the mean $\pm$ standard deviation (SD), while the skewed distributed measurement data was represented by the median. The comparison of the means between different groups was conducted by the Student’s $t$ -test or the Wilcoxon rank-sum test, and the comparison of the proportions between groups was conducted by the X ${}^{2}$ test or Fisher’s exact probability test. The logistic regression was used to analyze the risk factors of patients with severe illness and the ROC curve was made to analyze the correlation. The statistical software used was SPSS 22.0, and $P<$ 0.05 was considered statistically significantly different.

3. Results

3.1 Primary symptoms

There were 167 cases of fever with a temperature of 37.3–39 ${}^{\circ}$ C (85.2%), 121 cases of cough (61.73%), 24 cases of phlegm (12.24%), 59 cases of fatigue and muscle pain (30.1%), 20 cases of anorexia (10.2%), 15 cases of diarrhea (7.65%), 9 cases of chest pain (4.59%), and 5 cases of headache (2.55%).

Figure 1.

Bilateral ground glass opacities with fuzzy edge in the lower lobes in a 35-year old woman (mild group).

3.2 General clinical data analysis

There were 178 cases (90.81%) with typical multiple patch shadows and ground-glass opacities in the first chest CT scan (Figs 1–3). The NCP laboratory test results were as follows: 30 cases were found to be with reduced white blood cells (WBC) (15.3%), 110 cases with reduced lymphocytes (LY) (55.6%), 80 cases with reduced hemoglobin (40.82%), 51 cases with increased alanine aminotransferase (ALT) (26.02%), 86 cases with increased creatine kinase (CK) (43.88%), 96 cases with increased lactate dehydrogenase (LDH) (48.98%); 141 cases with increased c-reactive protein (CRP) (71.94%), 122 cases with increased erythrocyte sedimentation rate (ESR) (62.24%), and 59 cases with increased procalcitonin (PCT) (30.1%).

Figure 2.

Bilateral patchy infiltrates in the lower lung lobes in a 55-year old man (severe symptom group).

Figure 3.

CT visual score of severe COVID-19 pneumonia.

3.3 Clinical data analysis between the severe symptom group and the mild group

There were 44 cases of severe illness and 152 cases of mild illness. There were significant differences in factors like age, gender, combined underlying disease, features of chest CT, WBC, LY, ESR, CRP, albumin, ALT, CK, LDH, and D-dimer (D-D) between these two groups ( $P<$ 0.05). On the other hand, there were no significant differences in epidemiological history, symptoms, platelet count, total bilirubin, aspartate aminotransferase (AST), creatinine, PCT, prothrombin time (PT), and electrolytes between these two groups ( $P>$ 0.05) (Table 2). All patients in the mild group recovered, while 4 patients in the severe group died of multiple organ failure, with a mortality rate of 2.04%. After 10 $\sim$ 63 days of treatment, 192 patients recovered and were discharged, and further they were followed up for 30–128 days. The primary symptoms shown during the follow-up examinations included 22 cases of chest tightness, 15 cases of shortness of breath, 13 cases of fatigue, and 6 cases of joint pain. The CT re-examination results revealed 13 cases of fibrosis, 12 cases of interlobular septal thickening, and 3 cases of bronchiectasis.

Table 2
Clinical data analysis between the severe symptom group and the mild group

General information	All cases ( $n=$ 196)	Severe group ( $n=$ 44)	Mild group ( $n=$ 152)	t/X ${}^{2}$	$P$ value
Age ${}^{*}$	51.7 $\pm$ 12.98	60.18 $\pm$ 10.13	49.24 $\pm$ 12.70	$t=$ 10.938	$<$ 0.001
Gender ${}^{*}$				5.76	0.0164
Male	107	31	76
Female	89	13	76
BMI ${}^{*}$	22.23 $\pm$ 2.19	23.34 $\pm$ 2.78	21.92 $\pm$ 1.89	3.185	0.002
First nucleic acid test ${}^{*}$				12.81	$<$ 0.001
Positive	127	34	71
Negative	69	10	81
Epidemiology				0.0085	0.926
Yes	117	26	91
No	79	18	61
Smoking history				2.83	0.092
Yes	29	10	19
No	167	34	133
Underlying disease ${}^{*}$				9.916	0.00164
Yes	80	27	53
No	116	17	99
Clinical symptoms
Fever				0.0605	0.80569
Yes	167	38	129
No		6	23
Cough				0.485	0.317
Yes	121	29	92
No	75	15	60
Fatigue and myalgia				0.0794	0.778
Yes	59	14	45
No	137	30	107
Diarrhea				0.0073	0.931
Yes	15	3	12
No	137	41	140
Anorexia				0.0832	0.773
Yes	20	5	15
No	176	39	137
Chest CT findings ${}^{*}$				4.41	0.035
No	18	0	18
Yes	178	44	135
Laboratory examination
WBC ${}^{*}$	6.45 $\pm$ 3.07	7.85 $\pm$ 3.4	6.04 $\pm$ 2.85	3.212	0.002
LC ${}^{*}$	0.72 $\pm$ 0.29	0.49 $\pm$ 0.31	0.78 $=$ 0.25	$-$ 6.526	$<$ 0.001
HB	125.27 $\pm$ 10.486	123.89 $\pm$ 8.224	125.66 $\pm$ 11.047	$-$ 0.99	0.323
PLT	169.56 $\pm$ 43.382	177.7 $\pm$ 45.58	167.71 $\pm$ 42.588	1.418	0.158
ALB ${}^{*}$	37.76 $\pm$ 6.25	35.56 $\pm$ 4.47	38.39 $\pm$ 6.55	$-$ 3.297	0.001
TB	8.85 $\pm$ 3.43	9.43 $\pm$ 2.8	8.68 $\pm$ 3.59	1.271	0.205
ALT ${}^{*}$	30.28 $\pm$ 14.99	39.09 $\pm$ 22.93	27.74 $\pm$ 10.55	3.187	0.03
AST	43.28 $\pm$ 12.09	33.03 $\pm$ 25.13	41.04 $\pm$ 9.45	6.133	0.65
CK ${}^{*}$	299.49 $\pm$ 137.32	344.18 $\pm$ 182.89	297.16 $\pm$ 114.25	2.072	0.04
LDH ${}^{*}$	288.71 $\pm$ 71.75	314.75 $\pm$ 85.28	281.17 $\pm$ 65.74	2.412	0.019
CRP ${}^{*}$	20.54 $\pm$ 14.76	38.01 $\pm$ 18.72	15.48 $\pm$ 8.16	11.563	$<$ 0.001
Creatinine	70.01 $\pm$ 16.87	72.18 $\pm$ 13.23	69.38 $\pm$ 17.77	0.97	0.33
K	3.93 $\pm$ 0.44	3.88 $\pm$ 4.29	3.95 $\pm$ 4.39	$-$ 0.931	0.353
NA	139.38 $\pm$ 6.13	138.06 $\pm$ 7.29	139.77 $\pm$ 5.72	$-$ 1.64	0.103
CL	105.19 $\pm$ 4.19	104.83 $\pm$ 3.36	105.30 $\pm$ 4.4	$-$ 0.646	0.519
HCO3	24.39 $\pm$ 3.0	24.769 $\pm$ 3.21	24.27 $\pm$ 3.03	0.937	0.35
ESR ${}^{*}$	30.03 $\pm$ 13.7	35.45 $\pm$ 19.38	28.45 $\pm$ 11.26	2.287	0.026
PT	10.38 $\pm$ 1.15	10.56 $\pm$ 1.48	10.33 $\pm$ 1.03	1.184	0.238
APTT	30.82 $\pm$ 5.33	31.73 $\pm$ 5.79	30.56 $\pm$ 5.18	1.275	0.204
PCT	0.78 $\pm$ 0.83	0.074 $\pm$ 0.59	0.079 $\pm$ 0.89	$-$ 0.295	0.768
D-D ${}^{*}$	0.62 $\pm$ 0.603	1.03 $\pm$ 0.87	0.50 $\pm$ 0.43	5.445	$<$ 0.001

Note: ${}^{*}$ comparison between the two groups, $P<$ 0.05.

Table 3

Analysis of risk factors in the severe symptom group

Variable quantity	Single-factor regression analysis		Multi-factor regression analysis
	(95% CI)	$P$ value	(95% CI)	$P$ value
Age	0.924 (0.893–0.955)	$<$ 0.001 ${}^{\#}$	0.961 (0.778–0.952)	0.004 ${}^{*}$
Gender	0.419 (0.204–0.863)	0.018 ${}^{\#}$	3.549 (0.453–27.804)	0.228
BMI	0.748 (0.639–0.875)	$<$ 0.001 ${}^{\#}$	0.624 (0.409–0.950)	0.028 ${}^{*}$
First nucleic acid test	0.464 (0.213–1.008)	0.052
Epidemiology	1.033 (0.522–2.045)	0.926
Smoking history	0.486 (0.207–1.140)	0.097
Underlying disease	0.337 (0.169–0.674)	0.002 ${}^{\#}$	4.172 (1.271–13.691)	0.019 ${}^{*}$
Clinical symptoms
Fever	0.886 (0.336–2.333)	0.806
Cough	0.793 (0.939–1.602)	0.518
Fatigue and myalgia	0.901 (0.437–1.858)	0.778
Diarrhea	1.171 (0.315–4.351)	0.813
Anorexia	0.854 (0.292–2.497)	0.773
Hospital stay	1.193 (0.944–1.212)	0.011 ${}^{\#}$	0.893 (0.902–1.302)	0.003 ${}^{*}$
Chest CT findings	2.170 (2.831–3.452)	$<$ 0.001 ${}^{\#}$	1.005 (0.673–1.143)	0.002 ${}^{*}$
Laboratory examination
WBC	0.722 (0.64–0.816)	0.001 ${}^{\#}$	1.25 (0.883–1.770)	0.208
LC	5.739 (43.26–260.18)	$<$ 0.001 ${}^{\#}$	8.901 (2.352–33.693)	0.002 ${}^{*}$
HB	1.018 (0.983–1.053)	0.32
PLT	0.995 (0.987–1.002)	0.159
ALB	1.091 (1.021–1.166)	0.01 ${}^{\#}$	1.017 (0.871–1.1188)	0.828
TB	1.223 (0.928–1.033)	0.189
ALT	0.953 (0.931–0.976)	0.003 ${}^{\#}$	0.984 (0.925–1.047)	0.606
AST	0.986 (0.959–1.013)	0.314
CK	0.997 (0.994–1.000)	0.029 ${}^{\#}$	0.996 (0.987–1.004)	0.298
LDH	0.993 (0.988–0.998)	0.007 ${}^{\#}$	1.007 (0.901–1.018)	0.026 ${}^{*}$
CRP	0.201 (0.111–0.362)	0.001	0.866 (0.790–0.948)	0.002 ${}^{*}$
Creatinine	0.955 (0.782–1.166)	0.651
K	1.441 (0.663–3.11)	0.352
NA	1.043 (0.991–1.098)	0.108
CL	1.026 (0.950–1.107)	0.519
HCO3	0.949 (0.849–1.059)	0.349
ESR	0.967 (0.945–0.990)	0.004	0.974 (0.919–1.032)	0.370
PT	0.847 (0.642–1.117)	0.24
APTT	0.960 (0.901–1.023)	0.204
PCT	1.953 (0.023–166.598)	0.768
D-D	0.979 (0.959–0.999)	0.039	0.536 (0.138–2.081)	0.368
CT visual score	0.997 (0.994–1.000)	0.029	0.996 (0.987–1.004)	0.298 ${}^{*}$
TGGO	0.993 (0.988–0.998)	0.007	1.007 (0.901–1.018)	0.265 ${}^{*}$
IOF	1.043 (0.991–1.098)	0.108

Note: ${}^{*}P<$ 0.05.

3.4 Analysis of risk factors for severe illness

The univariate analysis indicated that age, gender, BMI, combined underlying diseases, chest CT features, CT visual score, WBC, absolute lymphocyte count (ALC), albumin, ALT, CK, LDH, CRP, ESR and D-D were the risk factors of severe illness. The multivariate logistic regression analysis revealed that age, underlying disease, length of hospital stay, BMI, LDH, chest CT visual score, ALC, and CRP were risk factors for severe illness (Table 3). The ROC curve demonstrated that the chest CT visual score was the most valuable indicator for predicting severe illness. With a CT visual score of $<$ 8.97 as the cut-off, the severe illness prediction had a sensitivity of 93.22% and a specificity of 71.53%, and it was negatively correlated with prognostic DLCO% with a coefficient of 0.702, followed by IOF (Table 4 and Fig. 4).

Table 4
Results of ROC curve of clinical imaging parameters in the severe symptom group

Indexes	Area under curve	Critical value	Sensitivity (%)	Specificity (%)
CT visual score	0.912	8.97	93.22	71.53
TGGO	0.892	3.591	86.90	53.10
Chest CT findings	0.772	2.155	85.10	35.60
CRP	0.622	3.625	78.10	38.10
LC	0.552	1.445	50.60	71.20
Underlying disease	0.432	0.745	53.80	64.50

Figure 4.

Results of the ROC curve of the risk factors of the Severe SARS-CoV-2 Pneumonia; The results of this study also show that “CT visual score” is the largest area under the ROC curve of the prognosis of pneumonia, and its diagnostic value of predicting EA fetus is the highest. The sensitivity was 93.22% and the specificity was 71.53%.

3.5 Follow-up of recovered patients

We followed up 192 recovered patients for 1 $\sim$ 4 months. It was found that the degree of pulmonary fibrosis in NCP patients directly affected the lung function indicators. Furthermore, the CT visual score was negatively correlated with FEV1.0%, FVC%, TLC%, and DLCO% (Table 5).

Table 5
Correlation between the CT visual score and FVC%, TLC%, DLCO% (correlation coefficent: r)

	FVC%	TLC%	DLCO%
TGGO	$-$ 0.227	$-$ 0.157	$-$ 0.383
IOF	$-$ 0.502	$-$ 0.458	$-$ 0.697#
CT visual score	$-$ 0.513	$-$ 0.494	$-$ 0.702#

4. Discussion

SARS-CoV-2 is a novel coronavirus of the $\beta$ genus, shaped round or elliptic, with a spike-like structure wrapping around the virus capsid and showing a crown-like appearance under an electron microscope. The homology between SARS-CoV-2 and the bat SARS-like coronavirus (BatCoVRaTG13) is as high as 96.3%, and bats may be its potential natural host [10, 11]. The primary symptoms of NCP are fever, dry cough and fatigue, and 25.2% of patients may have difficulty breathing. The severe case may progress to acute respiratory distress syndrome, septic shock, and multiple organ failure. It has been reported that the SARS-Cov-2 has a strong affinity for human respiratory receptors, implying a potential threat to global public health [12, 13, 14].

Among the 196 cases of NCP in this study, there were 107 males and 89 females (1.2:1). The ratio of male to female, BMI, and age of the severe group were greater than those of the mild group (31 vs. 13, 23.34 $\pm$ 2.78 vs. 21.92 $\pm$ 1.89, and 60.18 $\pm$ 10.13 vs. 49.24 $\pm$ 12.70, respectively), probably related to the weakened immunity of elderly obese patients [15, 16]. In addition, 117 cases of NCP had a history of contact with confirmed patients, and 80 cases had underlying diseases. While, only 137 cases were first-round laboratory tested positive, indicating a low sensitivity of single round nucleic acid test for the NCP diagnosis, probably due to low viral load, non-standard sampling methods, or poor quality of reagents. Therefore, multiple nucleic acid screening tests or supplementary examination with serum antibodies are needed for the effective control of the disease transmission [17, 18]. We also found that the first-round nucleic acid test positive rate of the severe group was much higher than that of the mild group (77.27% vs. 46.71%), confirming the necessity of screening of the severe illness, prevention, and special care of the patients with first-round positive nucleic acid results. The primary symptoms of NCP are fever and dry cough. The fever ratio in NCP patients in this study was 85.2%, mostly wave fever (46.2%) and intermittent fever (25.1%), with only a few high fever cases (13.9%), suggesting needs for increasing screening for patients with wave fever and intermittent fever. There were 14.8% of NCP patients with no fever, higher than the previously reported SARS and MERS infections. Hence, asymptomatic infections cannot be ignored to avoid missed diagnosis [19, 20]. There were 94 cases of NCP with symptoms such as fatigue, muscle pain, and anorexia, probably due to the lower respiratory tract being the target of SARS-Cov-2, and special attention should be paid to such cases.

The CT results of 178 cases (90.82%) of NCP were positive, therefore, the chest CT was highly sensitive to SARS-Cov-2 pneumonia [21, 22]. In addition, we newly introduced a CT visual scoring mechanism to evaluate the progress of disease and obtain good results. At the same time, multivariate analysis confirmed that CT score was an important parameter related to the prognosis of NCP. The CT signs of NCP are ground-glass opacifications and interstitial shadows (including interlobular septal thickening, subpleural curvilinear shadow, and irregular cords). Nevertheless, the lung fiber cord shadows, interlobular septal thickening, subpleural curvilinear shadow generally do not appear alone, but on the top of ground-glass opacifications. The ground-glass opacifications in the mild group were gradually absorbed and became lighter, especially for those with lesions involving less than two lung lobes, lung segments and low-density lesions. While a small portion of the ground-glass consolidations, cord shadows and subpleural curvilinear shadows could be absorbed too in the severe group. However, it was difficult for the dense cord shadows to be absorbed and showing no changes in the lesions even at the 3-month follow-up. The results were good to quantify the difference between the two groups with CT visual score, with significantly bigger scores in the severe group than in the mild group (8.53 $\pm$ 2.36 vs. 5.11 $\pm$ 1.96). In the past, it was difficult to achieve a standard using the CT signs based on human subjective opinions, making it difficult to tell the differences between severe and mild cases as well as the prognosis [23, 24, 25]. CT visual scores perfectly solved this dilemma.

According to reports, lung parenchyma, irregular interface signs, and traction bronchiectasis are the signs of fibrosis, which are related to the patient’s age and gender, i.e. the elderly male patients are more likely to have persistent fibrotic lesions in the lungs [26, 27, 28]. In the present study, it was found that the ground-glass shadows and reticular shadows were common in survivors with severe NCP. The peak value of LDH indicated the degree of tissue damage. The high peak values of LDH were also seen in the patients with higher visual scores of residual lung lesions. The more residual shadows in the lungs, the bigger declines in TLC% and DLCO% in the lung function follow-up examinations. The residual lung lesions were negatively correlated with DLCO%. The CT visual score strikingly quantified the relationship between these two, and the image performance and the recovery of lung function were closely related to the clinical manifestations [29, 30, 31].

5. Conclusions

In the follow-up after NCP recovery, it was shown that the lung CT features were closely related to its clinical manifestations, laboratory tests and lung function. There was a gradual improvement in the residual lung lesions and lung function, but the absorption of the interstitial shadows was slow. CT is able to demonstrate even the minute changes in the lungs, thus is an ideal examination method for monitoring residual lesions in lungs. Pulmonary function test is of great significance in evaluating the prognosis and quality of life of patients. Nevertheless, a longer follow-up is expected to check the recovery of residual lesions in lungs, especially the interstitial shadows in the NCP survivors, and the imaging performance of NCP needs to be further explored and studied.

Footnotes

Acknowledgments

This work was supported by grants from Hubei Province Health and Family Planning Scientific Research Project (No. WJ2019F096 and No. WJ2019F092), the Scientific Research Project of Hubei University of Medicine (Xiangyang No. 1 People’s Hospital): Application of Comparative Imaging Combined with Problem-based Learning (PBL) in Medical Imaging Theory Teaching (Zhibing He); the Study on the Diagnostic Value of Digital Mammography and DCE-MRI Combined with Serum-related Tumor Marker Detection in Clinical Palpation-negative Breast Cancer (Zhibing He); and Comparison of the Composition of Intestinal Microbiota between Patients with Colon Adenoma and Colon Cancer by High-throughput Sequencing (Yingjian Ye).

Conflict of interest

The authors declare no conflict of interest.

Abbreviations
