Slipped capital femoral epiphysis management and the arthroscope

Abstract

Background

In situ pinning of slipped capital femoral epiphysis (SCFE) results in various degrees of deformity of the femoral head-neck junction. Repetitive trauma from cam-type femoroacetabular impingement (FAI) can lead to labral tears and injury to the articular cartilage causing loss of function. Arthroscopic osteoplasty is an alternative to open procedure and to Southwick/Imhäuser-type osteotomies in symptomatic selected cases.

Surgical technique

The amount of bone to be resected has to be carefully planned pre-operatively. Only gentle traction is applied on a well-padded perineal support. A spherical burr is used to gradually resect the prominence. Intra-operative fluoroscopy is very useful when checking adequate reshaping of the head-neck junction is obtained.

Results

Arthroscopy often reveals acetabular cartilage lesions, labrum hyperhemia and fraying which rarely require repair. Arthroscopic osteoplasty provides satisfactory pain relief and, to a lesser extent, restores hip internal rotation.

Conclusion

Arthroscopic osteoplasty is more technically and time-demanding in post SCFE than idiopathic FAI. It requires strong arthroscopic skills and experience in hip arthroscopy. It stands as a reasonable alternative to open procedure or flexion osteotomies in symptomatic FAI post mild to moderate SCFE. It provides pain relief and to a lesser extent restores internal rotation of the hip.

Introduction

In situ pinning of slipped capital femoral epiphysis (SCFE) results in various degrees of deformity of the femoral head-neck junction. Despite some remodelling over growth, functional loss may result from the residual deformity that impinges with the acetabular rim in hip flexion and internal rotation. Repetitive trauma from cam-type femoroacetabular impingement (FAI) can also lead to labral tears and injury to the articular cartilage. ¹ Arthroscopic osteoplasty after in situ pinning is an alternative to open osteoplasty and to Southwick/Imhäuser-type osteotomies in symptomatic selected cases. Indication for this procedure is based on symptoms and clinical and imaging signs of FAI. Symptoms are represented by loss of function and sudden pain triggered in a given position of the hip (for example, getting on a bicycle). Internal rotation is typically restricted. Impingement test consists of gradual passive adduction and internal rotation on a 90° flexed hip suddenly exacerbating pain. Plain radiographs display post-slip morphology with excessive alpha angle and pistol grip deformity. MRI may demonstrate bone bruise and labral tears. Arthroscopic treatment aims to improve the clearance during movement of the hip and to eliminate the abutment of the prominent femoral head-neck junction and the acetabular rim, therefore relieving pain and to a lesser extent restoring internal rotation.

Surgical technique

Careful planning is necessary and is best based on preoperative three-dimensional (3D) CT scan. The adequate amount of bone to be resected to restore the normal alpha angle is calculated (Fig. 1). The patient is positioned supine on a traction table. A 70° arthroscope and special trocars are helpful although the procedure can be performed using a standard 30° arthroscope. ² An anterolateral portal is established under fluoroscopic guidance with the hip in 40° flexion into the peripheral compartment first. The anterior portal is placed under arthroscopic visualisation with a spinal needle and the guidewire technique, followed by an anterior capsulectomy, then gentle joint distraction. A 5.5 mm spherical burr is used to resect the prominence gradually (Video 1). Complete exposure of the bump may require hip mobilisation. Any retained metalware from previous surgeries is removed, if needed under arthroscopic visualisation. The amount of resection should not exceed 30% of the neck's volume to limit the risk of fracture. ³ Intra-operative fluoroscopy is very useful to check adequate reshaping of the head-neck junction (Fig. 2). Portals are closed and injected with Ropivacaine. Patients are discharged home on the same day and are advised to use crutches and bear weight as tolerated for one month. Sports are usually resumed gradually after three months.

Fig. 1

3D CT scan view of the femoral head and neck. The cone represents the correct amount of bone to be resected.

Fig. 2

Intra-operative fluoroscopic lateral view of the femoral head and neck, before (left) and after (right) arthroscopic osteoplasty.

Results

Ilizaliturri et al first reported on the results of arthroscopic management of FAI post SCFE in eight patients in 2007. ⁴ The age range at the time of the procedure was 24 to 39 years. At two-year minimum follow-up, the pain was relieved and at least neutral internal rotation of the hip was obtained. No complications were reported. Chen at al reported on 34 cases in 2014. ⁵ The initial slip was mild in 21 hips, moderate in 16 and severe in three. The age range at the time of the procedure was 10 to 19 years. Labral damage was seen in all 34 hips and the labral lesions were descriptive only. Acetabular cartilage damage adjacent to the damaged labrum was seen in 26 hips. The damage appeared to be abrasive with roughening of the surface, without the softening or full-thickness flaps that are typically seen in idiopathic cam impingement. Full-thickness cartilage loss noted in two hips was left untreated. At 12-month minimum follow-up, complete pain relief and correction of obligatory external rotation deformity (Drehmann sign) were obtained in 88% of cases. The mean internal rotation had improved from -20° to +10°. The mean alpha angle had improved from 88° to 54°. They reported two complications: one labral injury and one acetabular lesion during initial portal placement. Wylie et al reported on the results of nine patients aged 13.5 to 27 years in 2015 (six mild and three moderate slips). ⁶ All cases demonstrated acetabular cartilage and labral damage at the time of arthroscopy. Osteoplasty was combined with an acetabuloplasty in five cases and a labral repair in four cases. At 12-month minimum follow-up, the mean Harris hip score had improved from 63 to 91 and alpha angle from 75° to 46°. Four complications were reported: one capsular laxity requiring surgical revision, one perineal numbness, one lateral femoral cutaneous nerve numbness and one case of heterotopic calcifications. Our personal experience from the last ten years confirmed frequently associated acetabular cartilage lesions (mostly ICRS grade I and II) and labrum hyperhemia and fraying, none of which required specific treatment. Arthroscopic osteoplasty provided pain relief and restored some internal rotation of the hip without complication.

Discussion

‘Acute’ arthroscopic osteochondroplasty at the time of in situ fixation was first suggested by Leunig et al in 2010. ⁷ The rationale of such management is the prevention of early acetabular cartilage and labral damage and potentially later osteoarthritis of the hip. Three patients aged 11 to 15 years, presenting with a mild and stable SCFE, were included. At six- to 23-month follow-up, they were all asymptomatic and had resumed sporting activities at the previous level. Hip internal rotation was still slightly reduced compared with the contralateral side. Tscholl et al confirmed in 2016 that the normal alpha angle could be restored by systematic arthroscopic osteochondroplasty performed at a mean of three weeks (3 to 14) after in situ fixation of 14 mild to moderate slips. ⁸ One case of post-operative hip arthrofibrosis required arthroscopic revision. We do not perform arthroscopic osteoplasty as a prophylactic procedure in our practice. As acknowledged by the above-quoted authors, mid- and long-term outcomes have to be assessed and compared with controls.

Arthroscopic osteoplasty is more technically and time-demanding in post SCFE than idiopathic FAI. Indeed, the prominence is larger due to the epiphyseal slip, patients are often overweight and the presence of metalwork makes the procedure more difficult. Arthroscopic skills and strong experience in hip arthroscopy are recommended. Only gentle traction should be applied on a well-padded perineal support to prevent complications such as pudendal nerve palsy. It seems reasonable to limit the operative time two hours and 30 minutes. No more than 30% of the neck's volume should be trimmed to prevent subsequent fracture. ³ We believe FAI in severe slips are best managed with Southwick/Imhaüser-type osteotomies which provide satisfactory results. ⁹

Arthroscopic osteoplasty stands as a reasonable alternative to open procedure or flexion osteotomies in symptomatic FAI post mild to moderate SCFE. It provides pain relief and, to a lesser extent, restores internal rotation of the hip. The benefit of a preventive procedure has yet to be demonstrated in a mid- to long-term series with a control group.
