Epithelioid Inflammatory Myofibroblastic Sarcoma With Poor Response to Crizotinib: A Case Report

Abstract

Introduction:

Epithelioid type inflammatory myofibroblastic sarcoma (EIMS) is a subtype of inflammatory myofibroblastic tumor (IMT). It consists of round or epithelioid cells, and almost all types of EIMS contain rearrangements of the anaplastic lymphoma kinase (ALK) gene.

Case presentation:

We describe a 20-year-old female presenting with abdominal pain and a rapidly growing intraabdominal mass who underwent surgical tumor resection. She was diagnosed with EIMS. ALK and ki-67 expressions were detected in immunohistochemistry assessment. She was started with Crizotinib 200 mg twice a day, and chemotherapy was also initiated due to the recurrence of the disease 4 months after the initial treatment. She was unresponsive to all the medical regimens and died in 8 months.

Conclusion:

Approach to patients with EIMS is really challenging in terms of both diagnosis and treatment. Patients with combined surgical and non-surgical treatment regimen were seen to have a more favorable outcome in some EIMS cases. Therefore, it is essential to implement a multidisciplinary approach to diagnose and treat patients suspicious of EIMS.

Introduction

Epithelioid type inflammatory myofibroblastic sarcoma (EIMS) is a subtype of inflammatory myofibroblastic tumor (IMT) which mainly consists of round or epithelioid cells. ¹ The exact data on the disease epidemiology is not available, but it has been reported that the IMT’s annual incidence is 150 to 200 cases in the USA. These neoplasms may happen at any age however, children, adolescents and young adults are more affected. Most common sites of involvement are the abdomen, pelvic region, lungs, mediastinum and the retroperitoneal region. ² Trauma, inflammation, viral infections, gene fusion and chromosomal translocations have been proposed as probable etiologies.^3,4 An abnormal anaplastic lymphoma kinase (ALK) expression is seen in about half of patients affected with IMT and in almost all EIMS patients, making the disease progression more aggressive.^5,6 EIMS is associated with higher local recurrence rate, more inflammatory cell infiltration and poorer prognosis compared to IMT. ⁷

Furthermore, EIMS has a more aggressive behavior and less survival rate. These data suggest the need for clinical trials and consensus on the best treatment options; surgical resection is the management of choice for local EIMS, and systemic therapies are the preferred option in cases of recurrence or metastasis. Targeted therapies with ALK inhibitor (ALKI) agents such as Crizotinib could be implemented in those patients with EIMS with ALK overexpression. ⁸

Diagnosis of EIMS could be challenging due to its atypical tumor morphology and nuclear features. The differential diagnoses of the pathological findings are anaplastic large cell lymphoma, malignant mesothelioma, gastrointestinal stromal tumor and epithelioid leiomyosarcoma.

Reports of ALKI-resistant EIMS are very limited. Therefore, in this manuscript we present the case of a 20-year-old female diagnosed with EIMS who failed to respond to surgical treatment along with chemotherapy and ALKIs.

Case Presentation

A 20-year-old female was admitted at the Firoozgar hospital in Tehran, Iran, on November 2021, with the complaint of abdominal pain and swelling in the last 2 weeks. Upon admission, an abdominal mass was palpated on the right side. A solid heterogeneous, hypo-echoic mass measuring 280 × 100 mm was visualized by ultrasonography originating from the pelvic region extending to the upper abdomen. Computed Tomography (CT) revealed a solid mass, measuring up to 223 mm in the pelvic cavity and rectouterine pouch, which was extended into the right abdominal cavity, root of the mesentery and mesenteric vessels (Figure 1). Correspondingly, Magnetic Resonance Imaging (MRI) revealed a large T2 intense mass in the pelvic cavity, measuring up to 216 × 134 mm with extensions to the right upper quadrant of the abdomen with adhesions to the uterus fundus (Figure 2). Cancer Antigen 125(CA-125) and Human Epididymis Protein 4 (HE4) levels were 134 IU/mL and 34.6 Pmol/L respectively, and the Risk Of Malignancy Algorithm score was 3.55%.

Figure 1.

Axial CT images showing a huge solid mass (red arrow ) in the pelvic cavity extended into the abdominal cavity.

Figure 2.

Sagittal MRI T2-weighted images showing a large T2 intense mass (red arrow ) in the pelvic cavity with extensions to the right upper quadrant of the abdomen and adhesions to the uterus fondus .

With suspicion of ovarian germ cell tumor probably dysgerminoma, the patient underwent a staging laparotomy. Intraoperatively, we found a large hemorrhagic mass originating from the rectouterine pouch, which was supplied by mesenteric vessels, associated with 200cc hemorrhagic ascites in the peritoneal cavity. We resected the mass and performed right salpingo-oophorectomy due to tumoral involvement. Two expert pathologists reviewed the specimens, and the mass was diagnosed to be EIMS. involving the right ovary, uterus and peritoneum (Figure 3). Immunohistochemistry study (IHC) revealed positive staining for ALK (Figure 4). Ki-67 proliferatin index was 30%, while no expression of Cluster of Differentiation (CD)34, Caldesmon, Desmin, Myogenic Differentiation 1 (MyoD1), CD117, cytokeratin, and smooth muscle actin (SMA) was detected (Figure 5).

Figure 3.

Fibrimyxoid area containing fusiform wavy cells admixed with inflammatory cells.

Figure 4.

The anaplastic cells show strongly diffuse positivity for ALK and perinuclear accentuation of staining.

Figure 5.

SMA negative expression in neoplastic cells.

A multidisciplinary team reviewed the case at the hospital’s tumor board. After recovering from surgery, she was started on 200 mg of Crizotinib orally once a day. Four months after surgery, patient presented again with abdominal distension and loss of appetite and tumoral recurrence was confirmed on imaging studies. Crizotinib was discontinued and chemotherapy was initiated with Docetaxel 125 mg on day 8 and Gemcitabine 1000 mg on days 1 and 8 every 3 weeks. She had received 4 doses of this regimen and was a candidate for a repeat possible surgery after 2 more chemotherapy sessions. However, no response was attained after this strict management and she passed away after 8 months.

Discussion

EIMS is a rare mesenchymal tumor that usually occurs in children and young adults. In Table 1, we have collected the characteristics of 45 cases of EIMS that have been discussed in English language literature. The age of the patients ranged from 4 months to 72 years (average 34.3 years), and majority of cases were men (60%). This was similar to the article of Du et al that reported majority of cases affected with EIMS to be male, and intraabdominal region as the main tumoral location. ¹ However, our case was a young female.

Table 1.

Clinical characteristics of 45 cases of Epithelioid Inflammatory Myofibroblastic Sarcoma.

Case	Author	Age	Sex	Size (cm); Greatest dimension	Site	Treatment	Follow up/status	Fusion gene
1-11	Enrıquez 7	59y	M	15	Mesentery of the small bowel	Surgery + CT	12m/DOD	RANBP2-ALK in 3 cases
		41y	M	26	Omentum	Surgery + CT +ALKI	40m/alive
		6y	M	10.5	Omentum	Surgery + CT	13m/alive
		28y	M	NA	Mesentery of the small bowel	NA	NA
		63y	M	25	Mesentery of the small bowel	Surgery + CT	3m/DOD
		42y	M	NA	Intra-abdominal	Surgery + CT	13m/alive
		7m	M	10	Peritoneum	Surgery + CT +RT	36m/DOD
		40y	M	8	Peritoneum	Surgery + CT +RT	28m/DOD
		31y	F	17.5	Mesentery of the small bowel	Surgery + CT	11m/DOD
		6y	M	14	Omentum and mesentery	Surgery	NA
		39y	M	15	Mesentery of the small bowel	Surgery	NA
12	Batool et al 9	4m	F	12	Mesentery of the small bowel	Surgery	6m	NA
13	Halllin 10	NA	M	NA	Intra-abdominal	NA	NA	NA
14	Du et al 1	26y	M	25	Intra-abdominal + abdominal wall	Surgery +CT	DOD	RANBP2-ALK
15	Xu et al 11	35y	F	4	Stomach	Surgery	10m/alive	NA
16	Garg et al 12	2y	F	NA	Omentum+mesentry	Surgery	7m / alive	NA
17	Xu et al 13	28y	M	NA	Intra-abdominal + abdominal wall	ALKI	12m/alive	RANBP2-ALK/chromosomal ALK-G1269A mutation
18	Fu et al 14	21y	M	10	Lung	Surgery + ALKI	4m/DOD	NA
19	Liu et al 15	22y	M	13	Intra-abdominal	Surgery + ALKI	16m/alive	RANBP2-ALK
20	Wan et al 16	14y	M	18	Retroperitoneal	Surgery	3m/DOD	NA
21-25	Yu et al 8	37y	F	5	Rectum	Surgery	8m/alive	NA
		55y	M	NA	Terminal ileum	Surgery +CT	10m/alive
		22y	M	20	Mesentery of colon	Surgery + ALKI	14m/alive
		58y	F	NA	Omentum	Surgery +CT	8m/DOD
		15y	F	12	Transverse colon	Surgery	7m/alive
26	Liu et al 17	NA	F	10.9	Sigmoid	Surgery + ALKI	NA	RANBP2-ALK
27	Wu et al 18	47y	F	7.5	Mesentery of colon	Surgery +CT	4m/DOD	RANBP2-ALK
28	Zhang and Wang 19	46y	F	11	Intra-abdominal	Surgery + ALKI	DOD	NA
29	Singh et al 20	25y	M	6.9	Lung	Surgery + ALKI	4m/alive	NA
30	Azad et al 21	53y	F	NA	Intrapericardial	Surgery +CT	DOD	No fusion genes
31	Collins et al 22	43y	F	NA	Uterine	Surgery * NA	22m/alive	RANBP2-ALK
32	Fang et al 23	15y	F	NA	Ovary	Surgery + CT +ALKI	2y/alive	RANBP2-ALK
33	Sarmiento et al 24	71y	M	12.5	Intrapleural	Surgery +ALKI	1y/alive	NA
34	Kozu et al 25	57y	M	NA	Pleural cavity or chest wall	ALKI	NA	RANBP2-ALK
35	Kimbara et al 26	22y	M	6	Intra-abdominal	Surgery + CT +ALKI	10m/alive	RANBP2-ALK
36	Wang et al 27	42y	F	19	Greater omentum	Surgery +ALKI	alive	PRRC2B-ALK
37	Zhou et al 28	8y	M	18	Intra-abdominal	Surgery	DOD	NA
38	Bai et al 29	65y	M	9.3	Descending colon	Surgery	18m	NA
39-43	Lee et al 30	34y	M	8	Liver	Surgery	DOD	RANBP2-ALK in all cases
		62y	M	25	Omentum	Surgery+CT	DOD
		76y	F	9	Small bowel serosa	Surgery	DOD
		30y	M	10	Intra-abdominal	Surgery	DOD
		16y	F	8	Lung	Surgery+CT+RT+ALKI	alive
44	Chopra et al 31	72y	F	4.7	CNS	Surgery +ALKI	alive	VCL–ALK
45	Aminimoghaddam Current case	20y	F	21	Peritoneum	Surgery+CT+ ALKI	DOD	NA

Abbreviations: ALKI, ALK inhibitor; cm, centimeter,; CNS, central nervous system; CT, chemotherapy; DOD, dead of disease; F, female; M, male,; m, month; NA, not available; RT, radiotherapy; y, year.

Compared to other inflammatory myofibroblastic tumors, the clinical behavior of EIMS is more aggressive and is accompanied by more local recurrence rate and metastasis. ⁷ As shown in Table 1, at least 18 out of 38 patients (47%) with a close follow-up period died of this tumor, of which 11 out of 18 were male. Imaging studies cannot definitely make the diagnosis preoperatively, making the diagnosis a big challenge before surgical intervention. Diagnosis is based on the histopathologic evaluation and IHC studies. Even an intraoperative frozen section could not help. In most cases of EIMS, in addition to ALK, desmin, actin, and CD30 may be expressed. ¹⁰ In our case, CD34, caldesmon, desmin, MyoD1, CD117, cytokeratin, and smooth muscle actin expressions were not detected.

All EIMS contain rearrangements of the anaplastic lymphoma kinase (ALK) gene, giving rise to ALK inhibitors such as Crizotinib to be an optional drug for this condition. However, their effect on the outcome is unclear. ³² Surgical resection is the cornerstone of treatment in these patients, and ALK inhibitors are used as a part of a combination therapy alongside resection, chemotherapy and radiotherapy.

Enríquez et al. also reported that EIMS has a poorer outcome compared to IMT. He added, tumors with a positive ALK staining are associated with a more aggressive behavior. ⁷ Butrynski et al had experienced a partial response to Crizotinib in their affected Alk positive IMT patients. Their study emphasized that Crizotinib, along with surgery, could be a good option for the management of local recurrency, however some tumor resistant cases were present. ³³

Xu et al also reported a case resistant to Crizotinib. They identified a chromosomal ALK-G1269A mutation in addition to RANBP2-ALK fusion. This secondary acquired mutation is a mechanism of crizotinib-resistance. These patients benefit from second generation ALK inhibitors, such as Brigatinib (AP26113). They observed a significant response to this treatment in their patient. ¹³ Same with our experience, their case also experienced recurrence of tumor and disease progression despite surgery and administration of Crizotinib.

In our patient, certain ALK gene fusions could not be identified and we did not conduct any specific molecular cytogenetic tests, but, Yu et al in their study, explained that RAN Binding Protein 2 (RANBP2)-ALK fusion genes could lead to rapid growth, recurrence and more aggressive behavior of EIMS. ⁸ Why does this tumor recur in some population and in another cases responds to the current medical managements making these patient have a longer tumor-free period is a question that needs further investigation? However, the rarity of this potentially lethal tumor is another challenge to face.

Conclusion

The diagnosis and management of EIMS is challenging. A better prognosis has been observed in affected cases who had received a combined approach of surgical and non-surgical management (mainly targeted therapy). Therefore, it is essential to implement a multidisciplinary approach to diagnose and treat patients who are suspicious of EIMS.
