The creep behavior of 8xxx aluminum conductor alloys with different quantities of Fe-rich particles and solutes was investigated. Creep resistance was significantly improved with large amounts of Fe-rich particles and solutes. At 100 °C, a high Fe solute content (0.023 wt.%) had a stronger effect on creep resistance than FeAl3 particles. However, as the temperature increased to 150 and 200 °C, the effect of a high amount of FeAl3 particles (2.5 vol.%) was stronger. The threshold stress increased with increasing FeAl3 particle and Fe solute contents, with the effect of each factor being independent, but it decreased with increasing temperature. The true stress exponents were calculated to be 3.1, 3.8, and 4.5 at 100, 150 and 200 °C, respectively.
SizyakovV. M., BazhinV. Y. and VlasovA. A.: ‘Status and prospects for growth of the aluminum industry’, Metallurgist, 2010, 54, 409–414. doi: 10.1007/s11015-010-9316-z
2.
PanL., BourassaB. and ChenX. G.: ‘Effect of thermomechanical processing on electrical and mechanical properties of aluminum conductor alloys', Mater. Sci. Forum, 2014, 794–796, 1121–1126. doi: 10.4028/www.scientific.net/MSF.794-796.1121
3.
YuanW. H. and LiangZ. Y.: ‘Effect of Zr addition on properties of Al-Mg-Si aluminum alloy used for all aluminum alloy conductor’, Mater. Des., 2011, 32, 4195–4200. doi: 10.1016/j.matdes.2011.04.034
4.
ZhouW. W., CaiB., LiW. J., LiuZ. X. and YangS.: ‘Heat-resistant Al-0.2Sc-0.04Zr electrical conductor’, Mater. Sci. Eng. A, 2012, 552, 353–358. doi: 10.1016/j.msea.2012.05.051
5.
McqueenH. J., ChiaE. H. and StarkeE. A.: ‘Fe-particle-stabilized aluminum conductors', JOM, 1986, 38, 19–24. doi: 10.1007/BF03257864
6.
ZhangX. Y., ZhangH., KongX. X. and FuD. F.: ‘Microstructure and properties of Al-0.70Fe-0.24Cu alloy conductor prepared by horizontal continuous casting and subsequent continuous extrusion forming’, Trans. Nonferrous Met. Soc. China, 2015, 25, 1763–1769. doi: 10.1016/S1003-6326(15)63781-5
7.
OlinC.: ‘Aluminum alloy conductor’, US Patent 3711339, 1973.
8.
JablonskiM., KnychT. and SmyrakB.: ‘Effect of iron addition to aluminium on the structure and properties of wires used for electrical purposes', Mater. Sci. Forum, 2011, 690, 459–462. doi: 10.4028/www.scientific.net/MSF.690.459
9.
McqueenH. J., ConrodK. and Avramovic-cingaraG.: ‘The hot-working characteristics of eutectic-rod-stabilized conductor alloys', Can. Metall. Quart., 1993, 32, 375–386. doi: 10.1179/cmq.1993.32.4.375
10.
KarneskyR. A., MengL. and DunandD. C.: ‘Strengthening mechanisms in aluminum containing coherent Al3Sc precipitates and incoherent Al2O3 dispersoids', Acta Mater., 2007, 55, 1299–1308. doi: 10.1016/j.actamat.2006.10.004
11.
MarquisE. A., SeidmanD. N. and DunandD. C.: ‘Effect of Mg addition on the creep and yield behavior of an Al-Sc alloy’, Acta Mater., 2003, 51, 4751–4760. doi: 10.1016/S1359-6454(03)00288-X
12.
PanL., LiuK., BretonF. and ChenX.-G.: ‘Effect of Fe on microstructure and properties of 8xxx aluminum conductor alloys', J. Mater. Eng. Perform., 2016. doi:10.1007/s11665-016-2373-0.
13.
SherbyO. D., GoldbergA. and RuanoO. A.: ‘Solute-diffusion-controlled dislocation creep in pure aluminium containing 0.026 at.-% Fe’, Philos. Mag., 2004, 84, 2417–2434. doi: 10.1080/14786430410001690006
14.
BabichevaR. I., DmitrievS. V., ZhangY., KokS. W., SrikanthN., LiuB. and ZhouK.: ‘Effect of grain boundary segregations of Fe, Co, Cu, Ti, Mg and Pb on small plastic deformation of nanocrystalline Al’, Comp. Mater. Sci., 2015, 98, 410–416. doi: 10.1016/j.commatsci.2014.11.038
15.
KazantzisA. V., ChenZ. G. and De HossonJ. T. M.: ‘Deformation mechanism of aluminum-magnesium alloys at elevated temperatures', J. Mater. Sci., 2013, 48, 7399–7408. doi: 10.1007/s10853-013-7555-7
16.
ChaudhuryP. K., ParkK. T. and MohamedF. A.: ‘Effect of Fe on the superplastic deformation of Zn-22 pct Al’, Metall. Mater. Trans. A, 1994, 25, 2391–2401. doi: 10.1007/BF02648859
17.
SherbyO. D. and RuanoO. A.: ‘Rate-controlling processes in creep of subgrain containing aluminum materials', Mater. Sci. Eng. A, 2005, 410, 8–11. doi: 10.1016/j.msea.2005.08.077
18.
MalavaziJ., BaldanR. and Augusto CoutoA.: ‘Microstructure and mechanical behaviour of Al9Si alloy with different Fe contents', Mater. Sci. Technol., 2015, 31, 737–744. doi: 10.1179/1743284714Y.0000000659
19.
ChaudhuryP. K. and MohamedF. A.: ‘Effect of impurity content on superplastic flow in the Zn-22% Al alloy’, Acta Metall., 1988, 36, 1099–1110. doi: 10.1016/0001-6160(88)90163-0
20.
LiY. and LangdonT. G.: ‘A simple procedure for estimating threshold stresses in the creep of metal matrix composites', Scr. Mater., 1997, 36, 1457–1460. doi: 10.1016/S1359-6462(97)00041-9
21.
DeshmukhS. P., MishraR. S. and RobertsonI. M.: ‘Investigation of creep threshold stresses using in situ TEM straining experiment in an Al-5Y2O3-10SiC composite’, Mater. Sci. Eng. A, 2010, 527, 2390–2397. doi: 10.1016/j.msea.2009.12.015
22.
NaghdiF. and MahmudiR.: ‘Impression creep behavior of the extruded Mg-4Zn-0.5Ca and Mg-4Zn-0.5Ca-2RE alloys', Mater. Sci. Eng. A, 2014, 616, 161–170. doi: 10.1016/j.msea.2014.08.031
23.
KassnerM. E. and SmithK.: ‘Low temperature creep plasticity’, J. Mater. Res. Technol., 2014, 3, 280–288. doi: 10.1016/j.jmrt.2014.06.009
24.
GreenwoodG. W.: ‘Reflections on creep: a review of the MST archive’, Mater. Sci. Technol., 2013, 29, 893–899.
25.
LiW. J., CaiB., WangY. C., LiuZ. X. and YangS.: ‘Creep of Al-0.2Sc-0.04Zr alloys after different cold-rolling and ageing combinations', Mater. Sci. Eng. A, 2014, 615, 148–152. doi: 10.1016/j.msea.2014.07.071
26.
BarberK. W. and CallaghanK. J.: ‘Improved overhead line conductors using aluminum alloy 1120’, IEEE Trans. Power Deliv., 1995, 10, 403–409. doi: 10.1109/61.368373
27.
AllenC. M., O'ReillyK. A. Q., CantorB. and EvansP. V.: ‘Intermetallic phase selection in 1XXX Al alloys', Prog. Mater. Sci., 1998, 43, 89–170. doi: 10.1016/S0079-6425(98)00003-6
28.
ShakibaM., ParsonN. and ChenX. G.: ‘Effect of homogenization treatment and silicon content on the microstructure and hot workability of dilute Al-Fe-Si alloys', Mater. Sci. Eng. A, 2014, 619, 180–189. doi: 10.1016/j.msea.2014.09.072
29.
ZhaoQ. L., HolmedalB. and LiY. J.: ‘Influence of dispersoids on microstructure evolution and work hardening of aluminium alloys during tension and cold rolling’, Philos. Mag., 2013, 93, 2995–3011. doi: 10.1080/14786435.2013.794315
30.
MamalaA. and SciezorW.: ‘Evaluation of the effect of selected alloying elements on the mechanical and electrical aluminium properties', Arch. Metall. Mater., 2014, 59, 413–417. doi: 10.2478/amm-2014-0069
31.
DeshmukhS. P., MishraR. S. and KendigK. L.: ‘Creep behavior and threshold stress of an extruded Al-6Mg-2Sc-1Zr alloy’, Mater. Sci. Eng. A, 2004, 381, 381–385. doi: 10.1016/j.msea.2004.05.025
32.
MonazzahA. H., SimchiA. and ReihaniS. M. S.: ‘Creep behavior of hot extruded Al-Al2O3 nanocomposite powder’, Mater. Sci. Eng. A, 2010, 527, 2567–2571. doi: 10.1016/j.msea.2010.01.060
33.
LiY. and LangdonT. G.: ‘An examination of a substructure-invariant model for the creep of metal matrix composites', Mater. Sci. Eng. A, 1999, 265, 276–284. doi: 10.1016/S0921-5093(98)01131-9
34.
IshikawaK., OkudaH. and KobayashiY.: ‘Creep behaviors of highly pure aluminum at lower temperatures', Mater. Sci. Eng. A, 1997, 234, 154–156. doi: 10.1016/S0921-5093(97)00204-9
35.
WatanabeH., MukaiT. and HigashiK.: ‘Influence of temperature and grain size on threshold stress for superplastic flow in a fine-grained magnesium alloy’, Metall. Mater. Trans. A, 2008, 39A, 2351–2362. doi: 10.1007/s11661-008-9596-0
36.
LiY., NuttS. R. and MohamedF. A.: ‘An investigation of creep and substructure formation in 2124 Al’, Acta Mater., 1997, 45, 2607–2620. doi: 10.1016/S1359-6454(96)00367-9
37.
KlocL., SpigarelliS., CerriE., EvangelistaE. and LangdonT. G.: ‘Creep behavior of an aluminum 2024 alloy produced by powder metallurgy’, Acta Mater., 1997, 45, 529–540. doi: 10.1016/S1359-6454(96)00190-5
