Abstract
Background
Chronic rhinosinusitis (CRS) is a complex disease that incorporates many different conditions. Currently, primary CRS is considered a disease of broad airway inflammation, however, the previous classification of CRS with and without nasal polyposis fails to adequately classify patients based upon their etiology of illness. Our aim with this review is discuss the clinical presentation, radiology, endoscopy, histopathology, and treatment algorithm of three different phenotypes of primary CRS: central compartment atopic disease, eosinophilic CRS, and non-eosinophilic CRS.
Methods
A narrative review of a tertiary rhinology center's research themes and how they are applied to clinical protocols and practice was assessed.
Discussion
Diagnosis and treatment of upper and lower airway conditions become increasingly important as phenotypes and endotypes are being described. There are well-described therapies to treat the different phenotypes of CRS, based upon the presumed underlying cause of the inflammatory process. Research continues to shed more light on different endotypes and phenotypes of airway inflammation, however, clinical differentiation of CRS can be applied in clinic practice with three simple phenotypes of CRS. Understanding these different phenotypes and their etiologies allows for further management beyond the ‘maximum medical therapy and then surgery’ approach that has often been used in the management of CRS.
Introduction
Chronic rhinosinusitis is a complex disease that has previously been used to describe conditions ranging from unilateral single sinus disease, odontogenic sinusitis, fungal sinusitis, to widespread airway inflammation. The currently recognized definition of primary CRS is represented by chronic inflammation of the paranasal sinuses. In this discussion, primary CRS refers to a sinus condition in which no obvious secondary pathoetiologic event is occurring (ie fungal ball, neoplasia, odontogenic or immunodeficiency). Classically, primary CRS has been separated into two major subtypes based upon phenotypic appearance; CRS with nasal polyps (CRSwNP) and CRS without nasal polyps (CRSsNP) [1, 2]. The description of these different subtypes relies largely on observable clinical findings and lacks the inclusion of molecular differentiation and potential molecular diversity that exists within a subtype. Additionally, eosinophilic rhinosinusitis, allergic fungal sinusitis (AFS) and aspirin exacerbated respiratory disease (AERD) have been proposed as subtypes of CRS. In our practice, the treatment paradigm for CRS is largely driven by the presumed underlying etiology and molecular endotype of each inflammatory condition. This is also true for inflammatory disease of the lower respiratory tract, as the upper and lower airway are one unified tract and therefore exhibit similar molecular pathophysiology.
Previous studies on the success of different treatment options in the lower respiratory tract have had varied results and it is likely due to vague clinical definitions and use of only phenotypic descriptions driving treatment decisions [3]. ‘Endotyping’ of both asthma and CRS has been the focal point of more recent studies, as well as categorizing endotypes with their associated phenotypic group [3–5]. This initially started in the evaluation of asthma and has been extrapolated and studied in CRS. This differentiation will allow for more efficient and efficacious treatment of these inflammatory conditions as well as allowing for improved analyzation of the outcomes of treatment.
The traditional CRS phenotype of with and without nasal polyps has significant limitations. We describe three major clinically relevant phenotypes of CRS associated airway inflammation that exist: allergic, eosinophilic, and non-eosinophilic. The purpose of this paper is to define the different clinical and pathologic features of these CRS phenotypes, as well as the treatment options and goals.
Methods
The St Vincent's Centre for Applied Medical Research Rhinology and Skull Base Research Group research themes regarding CRS were reviewed. The current clinical protocols at a tertiary rhinologic practice were reviewed for the following criteria: patient selection (presenting symptoms including allergy and/or broader airway involvement, age of onset, smell function, corticosteroid responsiveness), endoscopic evaluation (the location and distribution of polypoid changes, degree of eosinophilic mucin production), radiologic assessment (a central versus diffuse pattern of mucosal changes), histopathology (degree of eosinophilia, evidence of eosinophil activation), atopic or allergen sensitization status (epicutaneous allergen challenge or allergen-specific serum immunocap assessment), and treatment goals (both medical and surgical therapy). The clinical diagnostic and treatment protocols for various working CRS phenotypes are described using the above criteria.
Phenotype
Central compartment atopic disease (CCAD) (allergic (IgE-mediated) airway inflammation)
Defining patient characteristics
Patients with allergic airway inflammation often have an earlier onset (< 20 yo) disease, and although there is eosinophilic T-helper 2 (TH2) cell involvement, it is predominantly IgE driven with other signs of atopic disease [3]. These patients will likely endorse a history of systemic atopy including symptoms of allergic rhinitis (AR), conjunctival symptoms, and dermatitis [3]. They will also have a history of allergic asthma (asthma associated with childhood and not adult-onset) with similar triggers to their other allergic symptoms. Most patients with persistent asthma that had an onset in early childhood suffer from allergic airway inflammation [3].
Local symptoms are more dominated by itch, sneeze, and rhinorrhea. Conjunctival reactivity is common. They will often have retained their sense of smell, despite having been told by other practitioners that they had nasal polyps [6]. The symptoms remain corticosteroid responsive as they are a TH2 inflammatory response, but are simply driven by IgE mediated triggers. While the relationship between CRS and allergy has often been studied, only weak evidence supports a connection between the two [7]. However, there is good evidence that IgE driven allergic patients develop a form of CRS on endoscopy and radiology that is unique [8].
Endoscopy
Atopy in CRS can manifest as middle turbinate edema, which can be viewed on nasal endoscopy (Fig. 1a). The middle turbinate is representative of ethmoid mucosa without the vascularity and fibrous stroma that is seen in the inferior turbinate. In patients with allergic rhinitis (AR), inhaled allergens are deposited on the head of the middle turbinate, which can lead to inflammation and edema of the mucosa. Hamizan et al. [9], found that patients with diffuse or polypoid edema of the middle turbinate had a higher likelihood of presence of inhalant allergy (PPV = 91.7 and 88.9% LR+ = 8.0 and 6.2). In more severe cases, the middle turbinate edema can progress to involve the superior turbinate and posterior nasal septum and potentially cause obstruction to more lateral sinus ostia [10]. However, these patients will not exhibit the thick eosinophilic mucin that is noted in other inflammatory airway conditions. Subsequently, the cycle of infective or acute exacerbations that are seen in diffuse eCRS is less common in this allergic phenotype.
At the time of surgery, polypoid changes are restricted to the turbinates, uncinate and ostiomeatal complex (OMC) [6]. Despite the extent of polypoid change on these structures, there is often near normal ethmoid, sphenoid and maxillary mucosa. Simple trapped mucus is all that can be found in many patients.
Radiology
The hallmark of inhalant/IgE driven CRS is a central thickening of the turbinates and septum with near normal peripheral sinus mucosa. This was originally described by Lund et al. as the “black halo” sign [11]. On computed tomography (CT) these sinus changes will appear as soft-tissue thickening in the central portion of the nasal cavity with sparing of the roof and lateral walls of the sinus cavity [8] (Fig. 2). Secondary obstruction can occur when the central changes began to encroach laterally on the sinus outflow tracts. If sinus changes occur, they are often simply secondarily obstructive in nature with trapped mucus.
Histopathology
Histopathologically, TH2 cytokines dominate this condition. This leads to elevated total and serum specific IgE. These patients will rarely have an elevated serum eosinophil count [3]. Tissue eosinophils are identified on simple hematoxylin and eosin (H&E) stain, and at this stage a further discriminated appearance is not available. However, there is rarely eosinophil aggregates or charcot-leyden crystals on mucin examination, as these are features of activated or degranulating eosinophils.
Allergy testing
Patients who suffer from allergic airway inflammation have higher serum specific IgE when compared to those who are suffering from other subtypes of asthma [3]. These patients will have evidence of atopy on skin prick test or Immunocap/radioallergosorbent test (RAST) and are associated with clinically relevant triggered symptoms. Persistent allergen exposure and inflammation is normally required to produce this phenotype therefore, seasonal allergens are not normally the cause of this type of CRS as chronic activation is usually requires in the authors experience. Dustmite and other perennial allergens are more likely.
Treatment goals
While surgery is still often applied to remove polypoid changes and prevent secondary obstructive phenomena that have occurred, it is the underlying inhalant allergy that needs to be suppressed in order for symptoms to improve. It is not uncommon to see patients post-surgery equally as symptomatic with normal appearance to their sinus cavity and progressive polypoid changes on the residual turbinates. If the polypoid changes have occurred over a long period of time and the underlying allergic process is indolent, then surgery may be the first step to overcome nasal obstruction and other phenomena such as barotrauma [10]. Once polypoid changes have occurred simple corticosteroid sprays are unlikely resolve the remodeling that has already occurred. Allergy directed pharmacotherapy and immunotherapy can occur post-surgery.
However, if the symptoms are dominated by an active allergic process with reactive nasal and conjunctival symptoms, then immunotherapy should be considered first and surgery delayed until a less allergic and more stable airway mucosa is obtained.
Only in those who cannot tolerate immunotherapy, have hyper-IgE states, and/or persistent allergy that has failed immunotherapy/pharmacotherapy, we do consider additional therapies such as Omaluzimab (anti IgE).
Eosinophilic airway inflammation
Defining patient characteristics
Eosinophilic CRS (eCRS) is an inflammatory condition due to a TH2 responses that is driven by eosinophilic inflammation. These patients tend to be older (30-50yo at onset) compared to those with early onset allergic disease (< 20 yrs. and “I've had sinus all my life” patients). Another common presenting pathway is an adult patient who was “completely well” until they had a viral event or cold and then “never recovered”.
Although some of these “adult-onset” eCRS patients may have had a history of allergic disease in their childhood, they often report that it quiesced for many years, with few symptoms in their early adult life only “to come back” in their 30-50 yrs. When there is a history of allergy, there is a strong association bias to believe it is related to their CRS, however 20–30% of the population have some allergic or atopic predisposition. Any adult onset eCRS condition with a history of allergy that had previously become quiescent or burnt-out, is likely to be unrelated to their childhood atopy.
Smell loss is a major feature early in the disease process for eCRS sufferers. Acute exacerbations, likely due to secondary obstructive or infective phenomena are common and these adult onset eCRS often seek antibiotics on multiple occasions prior to presentation [12]. Corticosteroid responsive smell or olfactory recovery is another common feature.
Patients almost always report a history of asthma at around the same time as the onset of their upper airway symptoms. In those patients who do not present with asthma, they will likely become asthmatic. Variants of lower airway disease include unexplained but corticosteroid sensitive cough, and obvious wheeze in a patient who lacks the classic bronchodilator criteria for asthma (GINA criteria).
eCRS patients will often report food induced and alcohol related exacerbations or flares of their condition. This is thought to be related to eosinophilic priming of the mucosa and leukotriene induced trigger. Aspirin exacerbated airway disease, includes non-steroidal anti-inflammatory (NSAIDs) reactivity, is a subtype of adult-onset eCRS.
Corticosteroid responsiveness is major feature of these patients. They often report a dramatic benefit within days of starting therapy and smell often returns quickly. Many patients seek corticosteroid and it is not uncommon to have patients wanting to be on them or self-medicating, although most are familiar with their side-effects. Patients who would report that corticosteroids are a ‘magic pill’ are often eCRS sufferers. This response is due to the penetration of corticosteroid to the sinuses, which occurs systemically via the blood stream in the unoperated sinus cavity. Simple corticosteroid sprays have little effect in most patients [13].
Endoscopy
Endoscopically, these patients will have evidence of thick tenacious eosinophilic mucin. They can also have polypoid edema, many small polyps, or true large polyps in the nasal cavity (Fig. 1b). During surgery, mucinous casts and “chewing gum” like mucin is classically present with diffusely thickened mucosa throughout the sinus cavity. Acute mucosa edema and ‘peau dórange’ appearance is more common in adult eCRS, especially in the early phase of the condition. The polypoid changes arise from within the middle meatus and are simply redundant changes from the turbinates as in allergy based CCAD.
Radiology
These patients have classic pan-sinus opacification with a Lund-Mackay score of 24. They may have evidence of secondary obstruction present on radiographic imaging (Fig. 3a-d). Neo-osteogenesis changes are common even in the un-operated patient.
Histopathology
Histopathologically, these patients will have tissue eosinophilia. Greater than 10 eosinophils/high powered field (hpf) is considered the current definition, however, it doesn't distinguish between CCAD and eCRS. Many patients have sinus biopsies with > 100 eosinophils/hpf (Fig. 4). A recent systemic review has demonstrated that a cut off 55 eosinophils/hpf predicts the likelihood of recurrence following surgical intervention [14].
Sample histopathology report
Systemic eosinophilia is a feature of eCRS. High levels of eosinophils in the blood have a positive likelihood ratio (LR) of 3.28 to predict high tissue eosinophilia [12]. Tissue eosinophilia, however, is not significantly associated with serum allergen specific IgE [12].
Allergy testing
These patients will have either, absolutely negative IgE sensitization or a pan or multi allergen sensitivity. There are mechanisms that induce local mucosal IgE generation that can produce multi-allergen sensitivity [15].
Treatment goals
Therapy should be aimed at treating what is primarily an inflammatory disorder. The goal of therapy is to deliver anti-inflammatory medicine to the site of the disease with the least amount of side effects or systemic exposure. In mild cases, associated with exacerbations and limited burden of disease, intermittent short courses (2–3 weeks) of corticosteroids can be offered 2–3 times per year. If systemic treatment is needed more often than this on an ongoing basis, then the risks of corticosteroid related adverse events in significant [16].
Effectively delivered corticosteroid solution via nasal irrigation is the key to controlling adult onset eCRS long-term. At some point, many patients will need to consider shifting their anti-inflammatory treatment from intermittent systemic delivery to regular local topically delivered corticosteroid. It has been well recognized that the delivery device and the surgical state of the sinus cavity effect the ability of local therapies to access the sinus cavity. Large volume (240 mL) irrigations achieve the best distribution when used in a simple sinus cavity [17, 18]. In a double blind, randomized controlled trial, it was noted that corticosteroid irrigation provided better overall symptom control that corticosteroid nasal spray [18]. Studies have also shown that wide openings in the frontal [19], maxillary [20], and sphenoid [21] sinuses allow for improved irrigant penetration and lavage of the sinus cavity (Fig. 5). Typical corticosteroid solutions include budesonide 1mg [22], mometasone (2 mg) [18], or betamethasone (1 mg) [22, 23] in a 240 mL irrigation once a day.
Widely opened sinus cavity view of
Even with excellent topical therapy via an adequate surgical cavity and large volume corticosteroid irrigations, some patients may not fully suppress their eosinophilic airway inflammation. Just as in asthma management, not all inflammatory airway patients are controlled with inhaled medications alone. Rescue medication with short courses of corticosteroid may still be required, especially with viral induced exacerbations. Mepolizumab is an anti-IL5 monoclonal antibody that is currently used in uncontrolled eosinophilic asthma and most of these patients have uncontrolled eosinophilic sinus disease. These patients’ eCRS condition does very well from the introduction of anti-IL5 therapy to their care. There are other monoclonal antibody treatments, targeting tissue eosinophilic response Benraluzimab (anti-IL5 receptor), Dupilumab (anti-IL4 receptor alpha subunit/IL13), and Reslizumab (anti-IL5) have been used in the treatment of eosinophilic asthma and related eCRS [24]. Prognostic features of patients with eCRS, who are at risk of failing a topical therapy approach, include those that have lower airway disease that is not well controlled on preventative inhaled therapy and/or require systemic corticosteroid therapies to control lower airway symptoms. In these patients, there is a realistic expectation that their upper airway will behave similarly.
Patients who suffer from the AERD subtype undergo the same medical therapy as those with adult-onset eCRS. The use of 5-lipoxygenase antagonist (Zileuton) and/or leukotriene receptor antagonist (Montelukast and Zafirlukast) may assist these patients. It is important to note that the 5-lipoxygenase antagonist and leukotriene receptor antagonist do not prevent symptoms in patients undergoing aspirin desensitization. These patients can take selective COX2 (cyclooxygenase) inhibitors (Meloxicam, Celecoxib) without risk of cross-over inhibition of COX1 [25]. In these patients, as well as patients who are unable to avoid NSAIDs for medical necessity, aspirin desensitization can be considered to the treatment paradigm [25]. Aspirin desensitization can occur in an inpatient or outpatient setting and typically is initiated over 2–3 days. Aspirin challenge dosing is 20-40 mg and increases by 20-40 mg every 3 h. Typical commencement protocol is 1300 mg daily (650 mg twice daily) for one month, if there is improvement in symptoms, then the dosage can be decreased by 350 mg. Maintenance doses should maintain 350 mg once or twice daily [25].
Non-eosinophilic airway inflammation
Defining patient characteristics
Unlike eosinophilic and allergic airway inflammation, patients with non-eosinophilic airway inflammation tend to be middle aged (∼60s), female, obese, and have no significant history of atopic disease. These patients will have a history of broader airway inflammation that is often not completely controlled on inhaled corticosteroids. If they have a history of childhood atopy, they will no longer suffer from classic allergic symptoms.
They will less often have smell loss. However, when they do, corticosteroids will not be the “magic pill” that they are for eCRS patients. Even with adequate treatment and control, their sense of smell will be slower to return. If patients have been treated in the past with corticosteroids, they may report very mild to no improvement. These patients are often on classic preventative inhaled therapy for their lower airways symptoms and still have break through symptoms.
Endoscopy
Nasal polyps or polypoid edema can be seen in these patients. They will not have eosinophilic mucin. However, they will have thick discolored secretions and obstruction of sinus outflow tracts which can lead to post-obstructive infective phenomena and purulence (Fig. 6).
Radiology
The patients are often indistinguishable from the pan-sinus opacification seen in eCRS with high Lund-Mackay scores (Fig. 7a-c). Importantly, this is still an inflammatory disorder and the sinuses are diffusely involved.
CT images of patient suffering from non-eCRS airway inflammation compliant on topical therapy;
Histopathology
Inflammation is driven by neutrophils and tissue eosinophils will be low. Tissue neutrophilia is significantly correlated with the presence of pro-inflammatory cytokines (IL-1β, 6, and 8) [26, 27]. Increasing levels of the non-Th2 cytokines present in the mucus is correlated with higher culture positivity and age [27].
Allergy testing
These patients generally will have negative skin prick and immunocap/RAST testing and lack clinical evidence of allergen driven symptoms.
Treatment goals
Although these patients do benefit from having sinus surgery, to overcome secondary obstructive phenomenon and mucostasis, the delivery of corticosteroids via nasal irrigation rarely controls the disease much like the poor response to systemic corticosteroid. This non-eCRS phenotype does well from long-term low dose macrolide immunomodulation [28, 29]. Macrolide therapy has been shown in previous studies to mediate IL-8 in nasal secretions, inhibit neutrophil chemotaxis and promote neutrophil degradation in a way that corticosteroids cannot [28]. Given this effect on neutrophils and mediators of neutrophils, Oakley et al. [29], described the patients who would best respond to therapy to be those with low serum and tissue eosinophilia and no presence of squamous metaplasia on histopathology. However, clinically, one could surmise that patients with late onset (>60yo) CRS and with limited response to corticosteroids could potentially benefit from a trial of macrolide therapy. Patients can be initiated on low daily dose of a macrolide (Clarithromycin 250 mg) and re-evaluated for benefit after 3 months. Those who receive benefit can be tapered to 3 doses per week and treatment can be ceased after 1 year, with expected lasting benefit (Fig. 6d-f, 7d-f). In our practice, only patients with a biopsy proven phenotype are offered this treatment, and thus only a post-surgical treatment. This is also practical as these patients can also be screened for prolonged QT syndrome [30].
Conclusion
The philosophical approach outlined in this publication represent the working classification of a tertiary center that has moved away from a simple CRSwNP and CRSsNP classification. There is no doubt that this paradigm will change with advances in research and understanding of CRS. However, the profession has been slow to move away from the current dichotomous simple CRS classification despite the wealth of research and data that has evolved in the past decade.
Summary of Key Findings of CRS Phenotypes
