Abstract
Background:
Animal studies and a few human studies have shown a change in sodium channel (NaCh) expression after inflammatory lesions, and this change is implicated in the generation of pain states. We are using the extracted human tooth as a model system to study peripheral pain mechanisms and here examine the expression of the Nav1.7 NaCh isoform in normal and painful samples. Pulpal sections were labeled with antibodies against: 1) Nav1.7, N52 and PGP9.5, and 2) Nav1.7, caspr (a paranodal protein used to identify nodes of Ranvier), and myelin basic protein (MBP), and a z-series of optically-sectioned images were obtained with the confocal microscope. Nav1.7-immunofluorescence was quantified in N52/PGP9.5-identified nerve fibers with NIH ImageJ software, while Nav1.7 expression in myelinated fibers at caspr-identified nodal sites was evaluated and further characterized as either typical or atypical as based on caspr-relationships.
Results:
Results show a significant increase in nerve area with Nav1.7 expression within coronal and radicular fiber bundles and increased expression at typical and atypical caspr-identified nodal sites in painful samples. Painful samples also showed an augmentation of Nav1.7 within localized areas that lacked MBP, including those associated with atypical caspr-identified sites, thus identifying NaCh remodeling within demyelinating axons as the basis for a possible pulpal pain mechanism.
Conclusion:
This study identifies the increased axonal expression and augmentation of Nav1.7 at intact and remodeling/demyelinating nodes within the painful human dental pulp where these changes may contribute to constant, increased evoked and spontaneous pain responses that characterize the pain associated with toothache.
Background
The activation of voltage-gated sodium channels (NaChs) plays an essential role in neuronal excitability, including the initiation and propagation of action potentials [1]. Experimental animal studies and a few human studies have shown that NaChs change their expression in sensory neurons following inflammatory and nerve lesions and these changes may contribute to the activation of pain pathways leading to the development of increased pain states [2].
The NaChs represent a diverse gene family, with at least nine different isoforms identified within the mammalian nervous system [3]. These different isoforms not only show distinct electrophysiological properties but also select distributions within different regions of the nervous system [4]. Much interest has been placed on the contribution of isoforms preferentially expressed within the peripheral nervous system to pain states. Although there is evidence for the involvement of each of these isoforms in nociception, the Nav1.7 isoform has recently been most critically linked to pain in humans [4].
The human dental pulp is richly innervated by nociceptive primary afferents [5] and represents a common site of pathology and pain [6]. A common treatment modality includes the extraction of the painful tooth, whereas normal wisdom teeth are also routinely extracted. Moreover, pain characteristics can be documented prior to extraction, and together these features distinguish the use of the human dental pulp as a model system to evaluate peripheral pain mechanisms. Here, we use this model system to evaluate the expression of Nav1.7 within normal and painful human pulpal specimens with the use of quantitative methods and demonstrate increased axonal expression of Nav1.7 within axon bundles and at typical and atypical nodal sites that showed alterations in myelin staining relationships within painful samples.
Results
Qualitative description of Nav1.7 expression in N52/PGP9.5-identified nerves
Nav1.7-immunofluorescence was observed in many nerve fibers identified by N52/PGP9.5 staining in all regions of both normal and painful dental pulp samples, including fibers within the pulp horn (Fig. 1) and axon bundles located throughout the pulp (Fig. 2). Fibers with Nav1.7 staining most commonly included those with both N52 and PGP9.5 (Figs. 1A−D and 2A,C). The N52/PGP9.5 staining (and especially the N52 staining) was mostly seen within intact fibers in the normal samples (Fig. 2A), but some normal samples (Fig. 2B) and most painful samples (Fig. 2C) also contained isolated fibers that appeared fragmented. These fragmented fibers were generally intermixed among intact ones located within axon bundles. One painful sample contained only fragmented axons in the coronal pulp (Figs. 1E,F) and these appeared very different than those isolated fragmented axons seen in some normal (Fig. 2B) and most painful samples (Fig. 2C). The expression of Nav1.7 was minimal in fibers with a fragmented appearance (Figs. 1E,F and 2C), while the expression within fibers with an intact appearance was seen in different-sized fibers and included even staining of low intensity and focal accumulations with brighter intensity. Both of these staining patterns appeared more common in painful samples (compare Figs. 2A to 2C). Three of the painful samples contained localized areas within the middle of the coronal pulp with a high density of fibers with prominent Nav1.7 staining, but with a diminished intensity or even lack of N52/PGP9.5 staining within these same fibers (Fig. 2D). The Nav1.7 expression within fibers that lacked N52/PGP9.5 staining would not be evaluated with the quantitative analysis described below. Since increased numbers of accumulations with Nav1.7 were seen in painful samples, adjacent sections of four sample pairs were stained with caspr, a paranodal protein used to identify nodes of Ranvier [7] and myelin basic protein (MBP) antibodies for further characterization.
Quantitative analysis of Nav1.7 expression in N52/PGP9.5-identified nerve area
Quantitative analysis showed no difference in the Nav1.7 expression within N52/PGP9.5-identified nerve area or in the pixel intensity of this expression within axons in the pulp horn of normal samples when compared to painful samples (area − 57.6% ± 5.6 vs. 46.6% ± 11.9; Fig. 3A/intensity − 549.6 ± 26.1 vs. 670.8 ± 204.7; Fig. 3B). In contrast, the nerve area occupied by Nav1.7-immunoreactivity was significantly greater within axon bundles located in the coronal (41.7% ± 4.8 vs. 66.5% ± 5.4; p < 0.01 - Fig. 3C) and the upper radicular (27.2% ± 5.5 vs. 66.0% ± 7.0; p < 0.001 - Fig. 3E) regions of the painful samples, but with no differences in pixel intensity in either of these areas (coronal − 503.8 ± 28.2 vs. 600.2 ± 65.4; Fig. 3D/upper radicular − 489.1 ± 63.4 vs. 564.8 ± 38.2; Fig. 3F).
Nav1.7 expression and characterization at caspr-identified nodal sites
Evaluation of pulpal tissue sections stained with caspr allowed a characterization of Nav1.7 at caspr-identified nodal sites that were classified as either typical or atypical as based on caspr relationships (see Methods for details). This analysis was limited to axon bundles within the coronal and upper radicular regions of four normal and four painful samples, since nodes are commonly seen in these regions. This analysis was performed on images that were thresholded to eliminate low intensity pixels while maintaining those with higher immunofluorescence intensity, since these are the ones typically seen at nodes of Ranvier (Figs. 4A−D). The total number of nodal sites evaluated was 2320 and included more than 500 sites in each region in both normal and painful samples. This analysis showed a dramatic increase in the percentage of nodal sites with Nav1.7 expression in painful samples within coronal and upper radicular regions (Figs. 4E,F). This increased percentage of Nav1.7-positive nodal accumulations within painful samples was seen at both typical (coronal − 2.7% ± 1.5 vs. 35.3% ± 5.5; p < 0.01 - Fig. 4E/upper radicular − 5.9% ± 2.7 vs. 32.7% ± 9.8; p < 0.05 - Fig. 4F) and atypical (coronal − 6.9% ± 4.0 vs. 53.9% ± 11.1; p < 0.01 - Fig. 4E/upper radicular − 9.1% ± 5.5 vs. 59.8% ± 8.4; p < 0.01 - Fig. 4F) nodal sites. In addition, there was a significant increase in the occurrence of atypical nodal forms within painful samples relative to the total number of all caspr-identified sites (coronal − 11.0% ± 3.9 vs. 36.9% ± 7.7; p < 0.05 - Fig. 4G/upper radicular − 9.9% ± 3.7 vs. 24.9% ± 4.6; p < 0.05 - Fig. 4H). Together, these results identify the increased association of Nav1.7 at both typical and atypical nodal sites and an increased occurrence of atypical nodal forms within painful samples.
Myelin basic protein expression
Pulpal tissue sections that were triple-stained with Nav1.7, caspr and MBP antibodies allowed a characterization of Nav1.7 expression at typical and atypical nodal sites in relation to state of myelination as reflected with the use of the MBP antibody (Fig. 5). The expression of Nav1.7 in normal samples was seen evenly distributed within small fibers that lacked caspr and MBP staining and that most likely represent unmyelinated fibers, while expression within myelinated fibers with caspr and MBP stainings was mostly confined to the nodal site of some fibers (Fig. 5A). The expression of MBP within normal samples was prominent on the surface of fibers located within axon bundles and less at nodal regions (Fig. 5A). In contrast, this expression of MBP was altered in painful samples (Fig. 5B,C). Alterations in MBP included generalized (Fig. 5B) and focal (Fig. 5C) decreases in expressions. Generalized loss was seen in some fibers with typical nodes (Fig. 5B), while localized alterations included a loss of MBP in the area adjacent to heminodes (Fig. 5B) and the axonal region between split nodes (Fig. 5C). Typical and atypical nodes that were associated with a generalized loss of MBP staining (Fig. 5B) and the axonal area located between the split nodes (Fig. 5C), both contained prominent Nav1.7-immunofluorescence. These findings are consistent with a remodeling of NaChs in areas of demyelination as identified by a loss of MBP staining.
Discussion
The results of this study demonstrate both the axonal expression of the Nav1.7 sodium channel (NaCh) isoform within the normal human dental pulp and changes in the expression of this isoform seen in painful samples. Quantitative methods showed an increased overall nerve fiber expression of Nav1.7 within axonal bundles but with no difference in expression within fibers located in the pulp horn, while single fiber analysis of caspr-identified nodal sites showed an increased expression of the isoform at typical and atypical nodal sites. Additionally, the atypical nodal sites were more common in painful samples and were associated with areas where MBP staining was lost. This pattern of MBP staining loss is similar to that found in demyelinating diseases [8] and this finding suggests the reorganization of NaChs at demyelinated sites as a pulpal pain mechanism. Together, these findings are consistent with a possible role for Nav1.7 in the constant, increased evoked and spontaneous pain sensations that characterize toothache and suggest the involvement of Nav1.7 as an ion channel involved with human inflammatory pain conditions. Furthermore, these changes are similar to those seen after inflammatory nerve lesions and suggest that pulpal pain mechanisms may include a neuroinflammatory neuropathic pain component.
The activation of voltage-gated NaChs is essential to action potential initiation and propagation and changes in expression may contribute to both inflammatory and neuropathic pain mechanisms [2]. Although evidence implicates the involvement of various NaCh isoforms in this process, recent findings in humans identify a critical role for the Nav1.7 isoform in pain sensation. These findings include mutations that result in nonfunctional channels and the inability to perceive acute painful stimuli [9,10], and point mutations that result in enhanced activation or impaired inactivation of channel current that are found in subjects with two chronic pain conditions that are characterized by burning-type pain [11,12].
The Nav1.7 isoform is prominently expressed within the dorsal root ganglia in humans and experimental animals [13,14] and especially in small diameter neurons that give rise to C-fibers and that respond to nociceptive stimuli [15]. Knockdown [16] and knockout [17] experiments also link the involvement of Nav1.7 to inflammatory hyperalgesia. Although these studies demonstrate a critical role for Nav1.7 in acute and inflammatory human pain, contributions to neuropathic pain mechanisms are less clear [18]. For example, the accumulation of Nav1.7 appeared greater in painful human neuromas when compared to nonpainful ones [19], yet a quantitative evaluation within human lingual nerve neuromas suggests that Nav1.7 expression alone is not correlated with the presence of painful dysesthesia [20]. Even though carious lesions of teeth result in pulpal pain that is most commonly thought to involve inflammatory mechanisms [21], certain aspects of pulpal pain may result from neuropathic pain processes that may contribute to the development of spontaneous pain that is present in some cases of toothache and that is a critical component of neuropathic pain [22]. Therefore, evaluations of Nav1.7 expression within both normal and painful pulpal samples may be useful to further our understanding regarding the role of Nav1.7 to both peripheral human inflammatory and neuropathic pain mechanisms.
The human dental pulp is richly innervated by nociceptors that include significant and differential contributions from both C-fibers and thinly myelinated fibers to discrete regions within the pulp [23,24]. The pain associated with irreversible pulpitis most likely involves contributions from both fiber types [25]. The pulpal expression of Nav1.7 was present within small fibers that lacked caspr (most likely representing C-fibers) and that are important in mediating dull toothache sensations, while the increased expression at nodal sites may be related to sharp, shooting spontaneous pain that was present in our patient population. Interestingly, many pulpal axons expressed N52. This result is surprising given that unmyelinated afferents are common within the pulp and others have shown little or no N52 expression in unmyelinated afferents [26]. The prominent expression of N52 within the pulp is even more intriguing given our finding that demonstrates Nav1.7 expression in presumptive unmyelinated fibers that lack markers (MBP and caspr) for myelinated fibers. One possible explanation for this finding includes an expression of Nav1.7 with N52 within the unmyelinated segments of myelinated afferents as they become free nerve endings. Furthermore, this broad expression of N52 suggests a possible thinning of fibers even before they enter the pulp and if so, this would over-estimate the number of unmyelinated fibers reported within the pulp [5]. Additional studies are needed to further evaluate these staining relationships and the relative contributions of myelinated and unmyelinated fibers to overall pulpal innervation.
The presence of sharp, shooting spontaneous and especially lingering pain responses following sensory stimulation represents an important transition from reversible pulpitis to irreversible pulpitis and an important change from a hyperalgesic state to an acute pain condition. The changes seen within axon bundles in our painful sample population may be associated with this transition to an acute pain state. A noteworthy finding was that the painful samples showed an extensive small cell and most likely inflammatory cell infiltrate within coronal regions of the pulp that often surrounded intact fiber bundles, whereas smaller incipient lesions were not seen (data not shown). Since inclusion criteria for the painful group included the presence of spontaneous and moderate-to-severe pain, this finding suggests a correlation of extent of lesion with the transition to an acute pain state. This finding also suggests that pain severity due to pulpal disease involves either a cumulative effect on many fibers or a more selective effect on fibers deeper within the pulp, rather than the select activation of fibers located at the pulp periphery, such as those found within the odontoblastic layer of the pulp horn. It is possible that smaller lesions that are confined to the highly innervated and more superficial regions of the pulp such as the pulp horn may be more important in hyperalgesic pain responses and even reparative processes rather than the generation of acute and especially severe pulpal pain sensations. The overall pattern and extent of Nav1.7 expression seen in the painful human dental pulp not only supports contributions to this inflammatory pain condition, but also suggests the involvement of specific fibers types to the transition from a hyperalgesic to acute pulpitis pain state.
The increased incidence of atypical nodal forms seen in our painful samples and the association of Nav1.7 with these atypical nodal forms provides evidence for the remodeling of NaChs at demyelinated sites as a pulpal pain mechanism. Changes within myelinated fibers are important since the pain of irreversible pulpitis includes spontaneous and evoked pain responses characterized by a sharp, shooting quality that are most likely mediated by myelinated fibers. Many studies have demonstrated that a disruption of myelin produces profound changes in NaCh expression [27–30] and that heminodes and split nodes result from segmental and paranodal demyelination, respectively [31]. Areas of demyelination are characterized by a loss of myelin staining as identified with antibodies against MBP [8], myelin oligodendrocyte glycoprotein [32] and myelin-associated glycoprotein [31], with a pattern that is similar to that identified in the present study. Together these findings suggest that demyelinating influences exist in the inflamed dental pulp and that the reorganization of ion channels at these sites may contribute to activation of pulpal nociceptors. Although significant demyelination of axons can lead to conduction loss, demyelinating diseases that affect the peripheral and central nervous systems are often times associated with pain [33,34]. It is possible that conduction loss may represent an advanced disease stage, while more subtle and localized regions of demyelination could contribute to the activation of nociceptors and pain due to ion channel remodeling within these sites. Certainly the immune system response and the effect of this response on glia that provide important molecular signals that influence ion channel localization within axons, are all involved [35]. Further studies are needed to more fully understand the complexities of these immune-glial-neuronal interactions and their contributions to the development of an acute pain state.
The physiological implications related to the increased expression of Nav1.7 within the painful human dental pulp are unknown but most likely relate to increased neuronal excitability. Also unknown is the contribution of increased Nav1.7 expression at typical and atypical nodal sites to nerve activity and the pain experience. It is possible that the decreased expression of N52 seen in some fibers is associated with a degenerative response that leaves the fibers incapable of action potential propagation, but even so, more proximal portions of these fibers may remain physiologically active. One of the important findings in our study that may address this issue was the common occurrence of these forms in painful samples. These changes were not limited to areas adjacent to inflammatory lesions but rather were also seen at more distant sites (such as axon bundles in the radicular pulp). Neuronal changes seen within the diseased pulp must be critical to the pain experience since pulp removal or extraction of the tooth is typically highly effective in the rapid elimination of the pain. This finding suggests activation of nociceptors within diseased tissues is of clinical importance in acute pain conditions and strengthens the usefulness of single fiber analysis within peripheral tissues as possibly even more important than changes within other levels of the neuroaxis such as the neuronal cell body or central axon terminals. However, in some cases, endodontic therapy or tooth removal does not eliminate the pain and the pain becomes chronic [36] and in these cases changes at other levels are most certainly important.
Local anesthesia failures represent a major challenge to the practice of painless dentistry. Although these failures occur with the delivery of routine restorative procedures, the incidence increases dramatically when treating painful teeth with a diagnosis of irreversible pulpitis [37]. Since local anesthetics target NaChs, this increased incidence may include a change in NaCh expression. If a change in NaCh expression is responsible for this phenomenon, the change must be widespread along nerve fibers that innervate these teeth since local anesthesia failures are also seen where nerve blocks are performed at sites distant from the site of disease. Even so, local anesthesia failures may involve an increased density of NaChs that possibly includes an increase in isoforms that are more resistant to commonly used local anesthetics such as lidocaine. Although earlier reports suggested that the tetrodotoxin (TTX)-resistant NaCh isoforms may be less sensitive to local anesthetics [38], other evidence suggests the opposite, since TTX-resistant NaCh (including Nav1.8) currents appear to be more sensitive to lidocaine than TTX-sensitive forms such as Nav1.7 [39,40]. The increased expression of Nav1.7 within axon bundles of painful samples and the decreased effectiveness of lidocaine on TTX-sensitive NaCh isoforms, both suggest the possible involvement of Nav1.7 in local anesthesia failures. Although this possibility is appealing, a critical analysis of NaCh expression at more distant sites that correspond to areas where local anesthetics are typically applied would be necessary to more fully test this hypothesis.
Finally, the identification of atypical nodal forms within axons in the painful human tooth with an inflammatory lesion is similar to those seen in an experimental animal model for inflammatory neuropathic pain [41]. This provides evidence for neuroinflammatory influences in the genesis of toothache pain and furthermore suggests similar mechanisms may exist among certain chronic inflammatory and especially those neuropathic pain conditions that often have an inflammatory component [42]. It has even been suggested that a treatment modality for neuropathic pain following peripheral nerve injury may include the excision of the injured nerve, somewhat akin to pulp removal or extraction of the offending tooth [43]. In this regard, additional studies of the painful human dental pulp represent an important target to further our understanding of both inflammatory and neuropathic pain mechanisms.
Conclusion
Our findings identify increased axonal expression of Nav1.7 within the painful human dental pulp that includes an increased expression at intact and remodeling/demyelinating nodal sites. These changes suggest contributions of Nav1.7 to the constant, increased evoked and spontaneous pain sensations that characterize toothache pain and to other acute and chronic inflammatory and neuropathic pain conditions.
Methods
Sample collection and tissue processing
This study was approved by the Human Subjects Institutional Review Board at the University of Texas Health Science Center at San Antonio and informed consent was obtained from all subjects who participated in the study. Teeth were obtained from subjects having an extraction of a normal, nonpainful third molar with fully formed apices (n = 13; 10 females and 3 males with an age range of 19–47), or a painful molar tooth diagnosed with irreversible pulpitis (n = 13; 10 females and 3 males with an age range of 24–49). Painful samples were limited to those that were associated with self-reports of moderate-to-severe levels of pain severity and the presence of spontaneous pain episodes as rated over the 24 hour time-period preceding the extraction. All painful teeth had the presence of a carious lesion that extended into the pulpal tissues, whereas those with large necrotic pulpal lesions were excluded.
Extracted teeth were collected in 0.1 M phosphate buffer (PB) and stored at 4°C. Later the same day, the teeth were split longitudinally and the pulpal tissues were removed and fixed in 4% paraformaldehyde in 0.1 M PB for 20 minutes. The pulpal tissue was rinsed in 0.1 M PB and then placed in 30% sucrose in 0.1 M PB overnight at 4°C. The next day the pulp was placed in Neg-50 (Richard-Allan Scientific; Kalamazoo, MI) and stored at −80°C. Pulpal samples were thawed and embedded in Neg-50, with a normal sample next to a painful sample, and serially sectioned with a cryostat at 30 μms in the longitudinal plane. Sections were placed onto Superfrost Plus slides (Fisher Scientific, Pittsburgh, PA), air dried and then stored at −20°C.
Immunocytochemistry
Primary antibodies: rabbit polyclonal anti-Nav1.7 [13] (produced against a 15 amino acid sequence in the rat that shows 13/15 similarities with the human sequence, 1:100 for caspr analysis and 1:200 for nerve area analysis), mouse monoclonal anti-neurofilament 200 kD (N52, Sigma-Aldrich, St. Louis, MO, catalog #N0142, 1:2000), guinea-pig polyclonal anti-protein gene product 9.5 (PGP9.5, Chemicon, Temecula, CA, catalog # AB5898, 1:300), mouse monoclonal anti-caspr (developed by and/or obtained from the UC Davis/NINDS/NIMH Neuromab Facility, supported by NIH grant U24NS050606 and maintained by the Department of Pharmacology, School of Medicine, University of California, Davis, CA 95616, catalog #75–001, 1:500), rat monoclonal anti-myelin basic protein (MBP; Chemicon, Temecula, CA, catalog #MAB386 1:200). Secondary antibodies: Alexa Fluor® 568 goat anti-rabbit IgG, Alexa Fluor® 488 goat anti-mouse IgG, Alexa Fluor® 633 goat anti-rat IgG and goat anti-guinea-pig IgG (all from Molecular Probes, Eugene, OR). All secondary antibodies were used at 1:100.
Immunostaining was performed as described previously [44]. Briefly, tissue sections were permeabilized and blocked for non-specific protein binding sites with blocking solution consisting of 4% normal goat serum (Sigma), 2% bovine gamma-globulin (Sigma), and 0.3% Triton X-100 (Fisher Scientific) in PBS for 90 minutes prior to the incubation with primary antibodies in blocking solution for 16 hours. One section from each normal/painful pair was stained with Nav1.7/N52/PGP9.5, while the adjacent section from select sample pairs were stained with Nav1.7/caspr/MBP. Sections were rinsed with PBS, incubated in secondary antibody in blocking solution for 90 minutes, rinsed in PBS and ddH2O, dried, and coverslipped with Vectashield (Vector Laboratories, Burlingame, CA). All procedures were performed at room temperature.
Confocal microscopic evaluation and image acquisition
Sections were evaluated with a Nikon Eclipse 90i C1si laser scanning confocal microscope with a 40x/1.30 N.A. oil immersion objective. This evaluation included the selection of a laser gain setting used to image Nav1.7-immunofluorescence to avoid saturated pixels so to allow a full dynamic range of Nav1.7-immunofluorescence pixel intensity and to select laser gain settings used to image all other primary antibodies. A series of optical images at 6 μm increments along the “z” axis of the sections stained with Nav1.7/N52/PGP9.5 antibodies were acquired from the middle 18 μm of each 30 μm thick section in the pulp horn and axon bundles in the coronal and radicular regions when present. Images obtained from the pulp horn in painful samples included only those areas where inflammatory cells were seen nearby to fibers. Care was taken to select fiber bundles that showed N52/PGP9.5 staining within intact fibers, since extensively fragmented fibers may represent degenerating ones. These selection criteria allowed the collection of a z-series of optical images from the pulp horn in 8 normal and 6 painful samples, coronal axon bundles in 12 normal and 8 painful samples, and radicular axon bundles in 8 normal and 8 painful samples. A z-series of optical images were also obtained at 1 μm increments from the middle 20 μm of the 30 μm thick sections of coronal and radicular axon bundles in four normal and four painful samples stained with Nav1.7/caspr/MBP antibodies. All images were captured with identical settings (including laser gain settings) at a 1024 × 1024 resolution (where each pixel is ? 0.3 μm width with an area ? 0.09 μm2) and saved as 12 bit single-channel images with a 0–4095 range of pixel intensities. Images were processed for illustration purposes by using Adobe Photoshop CS2 (Adobe Systems, San Jose, CA) and CorelDRAW 12 (Corel Corporation, Ottawa, Canada). Control tissue specimens were processed as above except the undiluted Nav1.7 antibody was preincubated with peptide antigen (approximately 30:1 peptide to antibody molar concentration ratio) for a minimum of 4 hours before application of the peptide-blocked antibody. Additional control specimens lacked the application of primary antibodies. Control sections lacked specific immunofluorescence.
Quantitative and image analyses
The specimens stained with the Nav1.7/N52/PGP9.5 antibodies were used to evaluate Nav1.7 expression within N52 and PGP9.5 identified nerve fibers. Each individual channel was opened with NIH ImageJ software [45] with the use of the ICS Opener plug-in [46]. The corresponding PGP9.5 and N-52 z-slices were combined by using the “Max Operation” in the Image Calculator. The staining intensities in all images were filtered by applying a threshold value to remove low intensity pixels that represent nonspecific/background values. The threshold value was determined with mean and standard deviation pixel intensity values obtained from a histogram analysis of every Nav1.7 and combined N52/PGP9.5 image slice from normal samples. Average values for mean and standard deviation pixel intensities were then obtained independently for the Nav1.7 and combined N52/PGP9.5 groups, and then a threshold value (mean + 2 times the standard deviation) for each group was applied to remove (filter) background staining. This thresholding process was applied in a consistent manner to all images from the normal and painful sample groups and resulted in images in which N52/PGP9.5 staining was clearly limited to nerve fibers. The thresholded nerve fiber area was recorded by creating a selection in every slice and this was saved as a region of interest (ROI). The nerve area ROI was trans-posed onto the corresponding thresholded Nav1.7 image. The thresholded image was then redirected to the original Nav1.7 image so that when it was analyzed, the actual Nav1.7-immunofluorescence pixel intensities within the ROI were recorded. The particles were then analyzed, and the average intensity and percent area of nerve fiber occupied by Nav1.7 were recorded.
The Nav1.7 expression within single fibers at caspr-identified nodal sites that were classified as either typical or atypical were determined in the z-series of images that were obtained in sections stained with the Nav1.7 and caspr antibodies. The typical nodal sites were identified by extensive caspr staining within two bands that were separated by a nodal gap, while any deviations from this relationship were classified as atypical nodal sites. The most common caspr-identified atypical nodal site included heminodes that were identified as a single band of caspr staining, or two bands of caspr staining separated by a nodal gap but where the area of caspr staining was greatly diminished on one side to less than 50% of that seen on the side with more extensive caspr staining. All caspr-identified sites within single fibers were classified in each z-series image stack with navigation through each stack to clarify relationships, while the Nav1.7 expression at individual nodal sites was performed on maximum intensity collapsed z-projection images generated from each z-series. The Nav1.7-immunofluorescence pixel intensity in each collapsed image was filtered by applying a threshold value to remove low intensity pixels while leaving pixels with higher immunofluorescence intensity like those located within nodal accumulations. A threshold value for Nav1.7 staining was determined with mean and standard deviation pixel intensity values obtained from a histogram analysis of the single-channel Nav1.7-only maximum projection from each of the four normal tooth pulp samples. Mean values were calculated, and a threshold value (mean + six times the standard deviation) was applied to each maximum intensity collapsed z-projection image. All caspr-identified nodal sites were included in the analysis and Nav1.7-positive nodal sites were defined as those accumulations with one or more Nav1.7-positive pixel(s) above threshold that were clearly associated with caspr staining as confirmed with identification of the same nodal site in the appropriate z-series image stack. This analysis was limited to caspr-identified sites located within fibers that were fully represented within the z-series image stack. All nodal accumulations were classified as either typical, or atypical and further classified as associated with Nav1.7 or as lacking this association. This evaluation further allowed the characterization of Nav1.7 at some caspr-identified atypical sites that were classified as split nodes where two distinct Nav1.7 accumulations were separated by a gap in the Nav1.7 staining within the same fiber and with each Nav1.7 accumulation being flanked on only one side by caspr.
Statistical analysis
Statistical analysis to determine significance used the unpaired Student t-test while error bars on all graphs represent the standard error of the mean (SEM). The “n” values used in all instances represented the number of samples evaluated.
List of abbreviations
MBP: myelin basic protein; ROI: region of interest; SEM: standard error of the mean; NaCh(s): sodium channel(s); N52: anti-Neurofilament 200 kD; TTX: tetrodotoxin.
Competing interests
The authors declare that they have no competing interests.
Authors' contributions
SL assisted with tissue preparation and staining, collection of data, data analysis, and helped draft the manuscript. GP assisted with tissue staining, collection of data, and data analysis. SRL helped to conceive the study, participated in its design, produced the Nav1.7 antibodies, guided data analysis, and helped draft the manuscript. MH conceived the study, participated in its design and coordination, assisted with tissue preparation, and drafted the manuscript. All authors read and approved the final manuscript.
Footnotes
Acknowledgements
This study was funded by the National Institute of Dental and Craniofacial Research at the National Institutes of Health by a grant (DE-015576) to MH and SRL. The authors thank Erin Locke for sample collection and Gabriela Helesic for assistance with tissue preparation.
