Abstract
Case summary
An 8-year-old neutered male domestic shorthair cat was presented for further investigation of anorexia, vomiting and lethargy. Abdominal ultrasonography and contrast-enhanced CT revealed choledocholithiasis with suspected bacterial peritonitis and non-visualisation of the gallbladder. During surgery, the common bile duct was noted to be perforated, and a cholelith was found in the abdominal cavity. No gallbladder was confirmed during surgery. Three months postoperatively, the cat underwent CT cholangiography and absence of the gallbladder with a vestigial duplicated gallbladder was diagnosed.
Relevance and novel information
Gallbladder agenesis is extremely rare in cats, with only one previous report, but several dogs have been diagnosed based on CT cholangiography and laparoscopy. This report describes gallbladder agenesis concurrent with choledocholithiasis in an adult cat and represents the first report of CT cholangiography in a cat with gallbladder agenesis.
Introduction
Gallbladder agenesis is a rare congenital anomaly of the biliary tract known in humans as congenital absence of the gallbladder. 1 In animal species, this pathology has been most frequently reported in dogs.2–5 In cats, congenital gallbladder anomalies such as duplex gallbladder are relatively common, but gallbladder agenesis is extremely rare, with only one reported case. 6 The diagnosis of gallbladder agenesis can be challenging, and advanced imaging such as CT cholangiography and magnetic resonance cholangiopancreatography (MRCP) are needed to diagnose gallbladder agenesis in humans.7–10 In veterinary medicine, CT cholangiography is a useful diagnostic tool for detecting absence of the gallbladder in dogs. 2 To the best of our knowledge, this is the first case report to describe the clinical and surgical findings and postoperative CT cholangiography findings from a cat showing bile duct perforation secondary to choledocholithiasis with gallbladder agenesis.
Case description
An 8-year-old neutered male domestic shorthair cat was presented with a 1-week history of anorexia, vomiting and lethargy. On presentation, the cat weighed 5.7 kg with a body condition score of 7/9; rectal temperature was 39.2°C (102.5°F). The cat had no history of surgical procedures other than castration. Physical examination was unremarkable and it showed no signs of icterus. Mild leukocytosis was noted in the complete blood count, and mild hypoalbuminemia and elevated serum amyloid A were observed on serum biochemistry (Table 1).
Complete blood count (CBC) and serum biochemistry values at the primary veterinary clinic (3 days before referral) and initial presentation (day 0)
Abnormal value
RI = reference interval; RBC = red blood cells; HCT = haematocrit; ALT = alanine transaminase; WBCs = white blood cells; ALP = alkaline phosphatase; BUN = blood urea nitrogen; SAA = serum amyloid A
Abdominal ultrasonography revealed ascites, and a hyperechoic structure that was suspicious for cholelith. No gallbladder could be identified. Ascites was collected by ultrasound-guided abdominocentesis from the caudal abdomen and identified as exudative with degenerate neutrophils, macrophages and intracellular bacteria (cell count 71,890/µl). Bilirubin concentration was normal (0.1 mg/dl). Bacterial culture of ascites was positive for Enterococcus faecalis with scant growth and sensitivity to ampicillin and enrofloxacin.
Sixteen-slice contrast-enhanced CT (Aquilion; Canon Medical Systems) revealed two choleliths in the common bile duct (CBD) and duodenum. The diameters of the choleliths were 8 mm and 6 mm, with attenuation values of 242 Hounsfield units (HU) and 265 HU, respectively. Ascites was seen surrounding the liver, which appeared normal. No gallbladder was apparent in the cranial abdominal region.
On day 1, exploratory laparotomy was performed because bacterial peritonitis was suspected, based on examination findings. General anaesthesia was induced with propofol (7 mg/kg IV [Propoflo; Zoetis]) and maintained with sevoflurane (Sevoflo; Zoetis) in oxygen. Analgesia was provided by robenacoxib (2 mg/kg SC [Onsior; Novartis Animal Health]) and a continuous rate infusion of fentanyl (20 µg/kg/h [Fentanyl; Terumo]) and ketamine (0.6 mg/kg/h [KETALAR; Daiichi Sankyo]) intraoperatively and buprenorphine (0.02 mg/kg IV q12h [Lepetan; Otsuka Pharmaceutical]) postoperatively. During surgery, a perforation of the CBD approximately 5 mm in diameter was identified, and a 6 mm yellow cholelith was found in the peritoneal cavity. Bile ascites (bilirubin; 3.1 mg/dl) was detected in the perihepatic space, and the distal part of the CBD from the rupture site was dilated and tortuous. No gallbladder structures or ectopic gallbladder were visualised around the gallbladder fossa (Figure 1).
Intraoperative photograph: note the absence of the gallbladder around the gallbladder fossa (circle)
Catheter insertion was attempted from the rupture in the CBD, but passage into the duodenum proved impossible, so choledochotomy of the dilated part was performed to insert a 6 F catheter; duct patency was confirmed by antegrade flushing of the CBD with saline. The rupture site and the incision in the dilated CBD were closed in a simple interrupted suture pattern with 4-0 polydioxanone (Monodiox; Alfresa Pharma) and 7-0 polydioxanone (PDSII; Ethicon) (Figure 2).
Rupture site (arrow) and dilated region (arrowhead) of the common bile duct (CBD). The duodenum is indicated by the asterisk. The incision at the dilated CBD had already been closed with a simple interrupted suture pattern using 7-0 polydioxanone
The liver appeared normal, but a liver biopsy was not performed. The cat recovered uneventfully and was eating well on day 2. The cat was discharged 6 days postoperatively and was treated with ampicillin (20 mg/kg IV q12h [Viccillin; Meiji Seika Pharma]), enrofloxacin (5 mg/kg SC q24h [Baytril; Bayer]) and prednisolone (0.5 mg/kg SC q24h [Prednisolone KS; Kyoritsu Seiyaku]), to reduce the postoperative inflammatory response from day 2. Orbifloxacin (3.5 mg/kg PO q24h [VICTAS SS; Sumitomo Pharma Animal Health]), prednisolone (0.2 mg/kg PO q24h [Predonine; Shionogi Pharma]) and ursodeoxycholic acid (8.9 mg/kg PO q24h [URSO; Mitsubishi Tanabe Pharma]) were continued for 7 days after discharge. Cholelith analysis showed a composition of 55% cholesterol, 10% calcium carbonate and 35% other material.
Three months postoperatively, CT cholangiography was performed without anaesthesia to confirm gallbladder agenesis and evaluate bile duct patency. Meglumine iotroxate (100 mgI/kg [Biliscopin DIC 50; Bayer]) was administered over a 30 min period, as described by Tanaka et al. 11 CT was performed 45 and 60 mins after the start of contrast medium injection and analysed using DICOM imaging software (Osirix version 3.9.2 64-bit open-source DICOM viewer; Osirix Imaging Software). The biliary ducts were well visualised at 45 mins after contrast injection, revealing intrahepatic ducts, three hepatic ducts and the CBD, but no gallbladder was visualised in the gallbladder fossa (Figure 3).
(a) Three-dimensional volume-rendered CT images from CT cholangiography 45 mins after contrast injection. Note that the gallbladder was absent. (b) Enlarged view of the white square area. The common bile duct (white arrow), two cystic dilations at the ends of the cystic ducts (arrowheads), and hepatic ducts (yellow arrows) were well visualised
In addition, two cystic dilations were found at the ends of the cystic ducts, with diameters of 5.45 mm and 3.64 mm, respectively. These were considered to represent vestigial remnants of a hypoplastic duplicated gallbladder. No ectopic gallbladder was identified in the abdominal cavity. A diagram of the biliary tree of the case is shown in Figure 4.
Diagram of the biliary tree in this cat. CBD = common bile duct; HD = hepatic duct; DUO = duodenum
The CBD was not dilated (2.1 mm) or obstructed, and contrast medium entered into the duodenum at 45 mins. At 60 mins, more contrast medium was excreted into the duodenum, resulting in insufficient contrast enhancement in the intrahepatic bile ducts (Figure 5).
Transverse CT from CT cholangiography at (a) 45 mins and (b) 60 mins. Note the difference of contrast enhancement in intrahepatic bile ducts at 45 mins (blue arrows) vs 60 mins after contrast injection (yellow arrows)
No adverse reactions to meglumine iotroxate were observed, and no recurrence of choleliths was confirmed. The cat remained alive and asymptomatic 13 months postoperatively.
Discussion
In this case, the cat initially showed mild, non-specific clinical signs associated with bacterial peritonitis, but choledocholithiasis and absence of the gallbladder was detected on ultrasonography and contrast-enhanced CT. Exploratory laparotomy showed perforation of the CBD due to choledocholithiasis and no gallbladder was apparent in the abdominal cavity. We therefore performed CT cholangiography postoperatively to investigate the biliary tree. Based on surgical and postoperative CT cholangiography findings, we confirmed the diagnosis of gallbladder agenesis in the cat.
Gallbladder agenesis is a rare anatomical anomaly, even in humans 1 and dogs, 2 and is extremely rare in cats. 6 In humans, most patients are asymptomatic, but some show clinical signs, including abdominal pain, nausea and jaundice that is sometimes associated with intra- and/or extrahepatic cholelithiasis.1,12–17 Dogs with gallbladder agenesis have often been reported in the absence of clinical signs; half of canine cases are asymptomatic and a common clinical finding is increased liver enzyme activity.2–5 In cats, one previous case report documented a cat with gallbladder agenesis diagnosed from ultrasonography and exploratory laparotomy showing clinical signs in association with inflammatory bowel disease, cholangiohepatitis and pancreatitis. 6 In our case, the cat presented with mild clinical signs associated with choledocholithiasis and septic bile peritonitis. These clinical signs may have been secondary to concurrent choledocholithiasis rather than the gallbladder agenesis itself, similar to human cases.
Choledocholithiasis is uncommon in cats and is sometimes confirmed as the underlying cause of extrahepatic bile duct obstruction.18–20 Previous studies have reported that 25–50% of human gallbladder agenesis presented with clinical symptoms related to choledocholithiasis.1,12–17 In cats, congenital anomalies of the biliary tract may be a risk factor for the formation of choleliths, and clinical case reports have described cholelithiasis with congenital duplex gallbladder.21,22 Some congenital malformations with ductal plate malformation have been considered a risk factors for bacterial infection and cholelithiasis. 23 In the present case, we speculate that similar to human cases, gallbladder agenesis may have contributed to the formation of choleliths.
Choledochotomy for cats with obstructive choledocholithiasis or pancreatitis has been reported to offer variable prognosis.18,24,25 In our case, we performed choledochotomy to confirm CBD patency because a catheter was unable to be inserted through the rupture due to the tortuous CBD. We did not place a choledochal stent in this case because the CBD was markedly dilated and the risk of CBD stricture following choledochotomy was considered low.
The diagnosis of gallbladder agenesis is difficult based on ultrasound imaging alone, so imaging modalities such as endoscopic retrograde cholangiopancreatography, CT cholangiography and MRCP have been used to diagnose gallbladder agenesis in humans.7,13,26–30 A previous study in dogs recommended CT cholangiography for biliary tract imaging. 2 In our case, CT cholangiography with meglumine iotroxate was performed without anaesthesia, and the biliary tract was well visualised, confirming gallbladder agenesis and ruling out an ectopic gallbladder. CT cholangiography is useful to highlight the gallbladder and we found two cystic dilations at the ends of the cystic ducts. These were considered to represent a hypoplastic duplicated gallbladder because the two small cysts and cystic ducts joined the CBD. CT cholangiography findings in this case were similar to findings reported from previous human13,14,16,31 and canine 2 cases of gallbladder agenesis, such as vestigial remnant, dysmorphic cystic duct and partially developed cystic duct. Adverse reactions to meglumine iotroxate in cats were not reported in a previous report, 11 and our case did not show any adverse effects. In humans, MRCP has been considered less invasive than CT cholangiography because MRCP can be performed without contrast medium, 32 although most adverse reactions to meglumine iotroxate were minor and their incidence was low. 33 In veterinary practice, general anaesthesia is required for MRI/MRCP, whereas CT may be performed without sedation. In this case, CT cholangiography was safely performed without any side effects and may represent a feasible, less invasive technique for cats with suspected gallbladder agenesis.
The optimal scan time in CT cholangiography for cats with absence of the gallbladder is unknown. CT cholangiography has been reported for dogs with gallbladder agenesis and for cats with extrahepatic biliary obstructions,2,11 both performing CT at 60 mins after contrast injection. In our case, CT was performed at 45 and 60 mins after injection, and images at 45 mins provided better visualisation of the intra- and extrahepatic bile ducts. In humans, CT cholangiography has been used to detect the presence of bile leaks. 34 Although we performed CT cholangiography postoperatively and not at the time of CBD rupture, CT cholangiography may facilitate preoperative diagnosis of bile duct perforation in cats with specific clinical signs of septic bile peritonitis, as in this case.
Conclusions
To the best of our knowledge, this is the first report of septic bile peritonitis caused by choledocholithiasis in a cat with gallbladder agenesis, a rare congenital abnormality in cats. The formation of choleliths may be associated with gallbladder agenesis, similar to human cases. CT cholangiography should be considered to diagnose gallbladder agenesis, and meglumine iotroxate appears safe in cats with gallbladder agenesis.
