Abstract

Objective:

This study aims to report on the early results of the twin branch as part of the Artivion E-xtra Design MultiBranch stent graft in the treatment of complex aortic aneurysms.

Methods:

We conducted a retrospective review of all implanted stent grafts containing a twin branch in 7 centers between March 2023 and March 2025. Outcomes of interest included baseline characteristics, technical success, twin branch–related events and short-term clinical and radiological outcomes.

Results:

Thirteen patients were identified and included. Mean age was 72.4 (±9.4) and mean aortic aneurysm diameter was 63.2 (±13.5). The indication for the twin branch was an early division of the celiac artery (CA) in 5 cases, a common ostium of the superior mesenteric artery (SMA) and CA in 3 cases, a large accessory renal artery in 3 cases, closely-originating chimneys in one and cannulation of the SMA and CA through an intimal entry tear in the last patient. Median follow-up was 4.4 (interquartile range: 2.3–7.4) months. Technical success was achieved in all cases; no mortality nor rupture occurred. There was 1 asymptomatic occlusion of an SMA stent graft incorporated into the twin branch at 11 weeks postoperatively. In this case, the twin branch bridging stents were inflated sequentially and not simultaneously. There was no twin branch–related endoleak.

Conclusion:

The twin branch is a feasible option in the treatment of complex aortic aneurysms with certain anatomic variations. Simultaneous inflation of both stent grafts should be performed to avoid compromising a previously-inflated stent graft.

Clinical Impact

The twin branch was developed as a component of the E-xtra Design MultiBranch stent graft system (Artivion, Hechingen, Germany). In this multicenter retrospective study, we demonstrate that the twin branch is a feasible option in the treatment of complex aortic aneurysms where a regular F/BEVAR is not possible because of the visceral vessels originating in close proximity to each other and where the aortic lumen is too narrow to allow for external branches. The short-term outcomes show a good technical success rate. Simultaneous insufflation of bridging stents might be beneficial to maintain target vessel patency..

Keywords

aortic aneurysm iBEVAR twin branch accessory renal artery common ostium

Get full access to this article

View all access options for this article.

References

Tenorio

Dias-Neto

Lima

GBB

, et al. Endovascular repair for thoracoabdominal aortic aneurysms: current status and future challenges. Ann Cardiothorac Surg. 2021;10(6):744–767. doi:10.21037/acs-2021-taes-24.

Wanhainen

Van Herzeele

Bastos Goncalves

, et al. Editor’s choice—European Society for Vascular Surgery (ESVS) 2024 clinical practice guidelines on the management of abdominal aorto-iliac artery aneurysms. Eur J Vasc Endovasc Surg. 2024;67(2):192–331. doi:10.1016/j.ejvs.2023.11.002.

Rocha

Lindsay

Friedrich

, et al. Systematic review of contemporary outcomes of endovascular and open thoracoabdominal aortic aneurysm repair. J Vasc Surg. 2020;71(4):1396–1412. doi:10.1016/j.jvs.2019.06.216.

Oderich

Ribeiro

Reis de Souza

, et al. Endovascular repair of thoracoabdominal aortic aneurysms using fenestrated and branched endografts. J Thorac Cardiovasc Surg. 2017;153:S32–S41. doi:10.1016/j.jtcvs.2016.10.008.

Almerey

Oldenburg

WA.

Preservation of internal iliac arteries during endovascular aneurysm repair using “eye of the tiger” technique. J Vasc Surg Cases Innov Tech. 2017;3(4):257–260. doi:10.1016/j.jvscit.2017.10.007.

Iwakoshi

Inagaki

Yoshiyama

, et al. Modifying the “Eye of the tiger” technique: preserving gluteal artery perfusion in the treatment of an aneurysm of the hypogastric artery. Vasc Endovascular Surg. 2021;55(3):277–281. doi:10.1177/1538574420966109.

Gomes

Parodi

Ohana

, et al. Case series on double-barrel stenting for the renal arteries associated with fenestrated repair (FEVAR) of complex anatomy aortic aneurysms. Vasc Endovascular Surg. 2024;58(4):399–404. doi:10.1177/15385744231215589.

Berczeli

Kölbel

Tsilimparis

, et al. Multicentre experience with novel bidirectional double cuffed inner branches for complex endovascular aortic repair. Eur J Vasc Endovasc Surg. 2024;68(2):218–225. doi:10.1016/j.ejvs.2024.04.040.

Oderich

Forbes

Chaer

, et al. Reporting standards for endovascular aortic repair of aneurysms involving the renal-mesenteric arteries. J Vasc Surg. 2021;73:4S–52S. doi:10.1016/j.jvs.2020.06.011.

10.

Lucatelli

Cini

Benvenuti

, et al. Custom-made endograft for endovascular repair of thoraco-abdominal aneurysm and type B dissection: single-centre experience. Cardiovasc Intervent Radiol. 2018;41(8):1174–1183. doi:10.1007/s00270-018-1975-3.

11.

Abisi

Zymvragoudakis

Gkoutzios

, et al. Early outcomes of Jotec inner-branched endografts in complex endovascular aortic aneurysm repair. J Vasc Surg. 2021;74(3):871–879. doi:10.1016/j.jvs.2021.01.067.

12.

Abisi

Zayed

Frigatti

, et al. Medium-term outcomes of EXTra-design engineering inner-branch ENdografts for the treatment of complex aortic aneurysms from a multicenter collaboration. J Vasc Surg. 2024;80(2):336–343. doi:10.1016/j.jvs.2024.03.013.

13.

Tinelli

Lescan

Sica

, et al. Inner branch off the shelf technology for chronic post-dissection thoracoabdominal aneurysm with narrow true lumen: results of a European multicentre study. Eur J Vasc Endovasc Surg. 2025;70(4):437–444. doi:10.1016/j.ejvs.2025.04.044.

14.

Squizzato

Piazza

Isernia

, et al. Use of an off the shelf inner branch thoraco-abdominal endograft for the treatment of juxtarenal and pararenal aortic aneurysms. Eur J Vasc Endovasc Surg. 2025;69(6):837–845. doi:10.1016/j.ejvs.2025.02.030.

15.

Torrealba

Panuccio

Nana

, et al. Midterm single-center results with the use of custom-made endografts with inner branches, a call for attention. J Vasc Surg. 2025;81(2):310–317. doi:10.1016/j.jvs.2024.09.039.

16.

Katsargyris

Marques de Marino

Mufty

, et al. Early experience with the use of inner branches in endovascular repair of complex abdominal and thoraco-abdominal aortic aneurysms. Eur J Vasc Endovasc Surg. 2018;55(5):640–646. doi:10.1016/j.ejvs.2018.01.024.

17.

Giordano

Nana

Panuccio

, et al. Use of the electrified wire technique for in situ fenestration creation within a branch bridging stent [published online ahead of print March 13, 2025. J Endovasc Ther. doi:10.1177/15266028251324074.

18.

Liao

Rossi

Fatima

Renal preservation in immediate bifurcation of the renal artery in a solitary kidney using inner branch in a physician-modified, fenestrated-branched endovascular graft. J Vasc Surg Cases Innov Tech. 2024;10(6):101616. doi:10.1016/j.jvscit.2024.101616.

Early Experience With the Twin Branch in the Endovascular Treatment of Complex Aortic Aneurysms: A Multicenter Retrospective Study
