Measurement of glomerular filtration rate in cats

Abstract

Practical relevance:

Routinely used markers of renal function in clinical practice include urea and creatinine. However, these are insensitive markers, particularly in the early stages of kidney disease. Measurement of glomerular filtration rate (GFR) is regarded as the most sensitive index of functioning renal mass. It may be useful for feline patients in varying clinical scenarios; for example, where a more accurate measurement of renal function may aid diagnosis, to enable response to therapeutic interventions to be more closely monitored, or to evaluate renal function prior to the use of nephrotoxic or renally cleared drugs.

Clinical challenges:

Traditional methods of measuring GFR, such as renal clearance or multisample plasma clearance techniques, are generally impractical for clinical use. Limited sampling and single sample plasma clearance methods using the filtration marker iohexol have been validated in cats. These have the advantages of reduced stress to cats associated with repeated sampling and reduced costs of analysis, and therefore offer greater clinical utility. Attempts to develop an estimated GFR (eGFR) formula similar to that used in human patients have been made in cats, although currently an accurate and reliable formula is not available.

Audience:

This review presents the basis for the theoretical understanding and practical measurement of GFR for any veterinary practitioner wishing to obtain a more accurate and sensitive assessment of renal function than routinely used markers provide.

Evidence base:

The review draws evidence from peer-reviewed publications, the author’s PhD thesis and also clinical experience.

The nephron – functional unit of the kidney

The kidney can be differentiated into two major regions, the outer cortex and inner medulla. The functional unit of the kidney, the nephron, comprises the glomerulus within the Bowman’s capsule, the proximal tubule, loop of Henle, distal tubule and collecting duct (Figures 1 and 2). The glomerulus and Bowman’s capsule are located in the renal cortex and the tubules run between the cortex and medulla. Each human kidney contains approximately 1 million nephrons.¹ The feline kidney and canine kidney are reported to contain approximately 200,000 and 400,000 nephrons, respectively.²

Figure 1

Ultrafiltrate filtered from the glomerulus of the nephron enters the Bowman’s space within the Bowman’s capsule, then passes through the proximal tubule, loop of Henle, distal tubule and collecting duct to form urine

Figure 2

The glomerulus – a network of capillaries interposed between the afferent and efferent arterioles – is enclosed within an epithelial capsule (Bowman’s capsule) and separated by the Bowman’s space. Glomerular filtration is a pressure-driven process governed by hydrostatic and oncotic pressures in the glomerular capillaries and Bowman’s capsule, and by glomerular conductivity and the capillary surface area

The glomerulus consists of a tuft of glomerular capillaries interposed between the afferent and efferent arterioles, and is enclosed within an epithelial capsule (Bowman’s capsule) and separated from the capsule by the Bowman’s space. Fluid is filtered from plasma through the glomerulus and into the Bowman’s space. Glomerular capillary walls are composed layers: the endothelial cells, glomerular basement membrane and epithelial cells. Endothelial cells are fenestrated and epithelial cells are attached to the glomerular basement membrane by foot processes, between which are slit pores which allow passage of small solutes.

Physiology of glomerular filtration

Glomerular filtration is a selective pressure-driven filtration process across the glomerular capillary wall, determined by the size and molecular charge of a solute. Fluid that is filtered through the glomerular capillaries is known as ultrafiltrate. The filtration fraction, the proportion of plasma flowing through the capillaries forming the ultrafiltrate, has been reported to be between 27 and 31% in cats.^3,4 Ultrafiltrate enters the proximal tubule from the Bowman’s space and passes to the loop of Henle, which has both an ascending and descending limb, and the length of which varies between nephrons. The ultrafiltrate subsequently flows through the distal tubule and finally the collecting duct to form urine.

Measurement of GFR (see above) is regarded as the most sensitive index of functioning renal mass. Single nephron GFR (snGFR) is the product of the effective ultrafiltration pressure and ultrafiltration coefficient. The effective ultrafiltration pressure is governed by hydraulic and oncotic pressures in the glomerular capillaries and Bowman’s capsule. Therefore, marked hypotension may decrease GFR due to reduced hydraulic pressure in the glomerular capillaries, for which renal haemodynamic regulatory mechanisms cannot compensate. A lower urinary tract obstruction will increase hydraulic pressure in the Bowman’s space and decrease GFR. The ultrafiltration coefficient is determined by glomerular conductivity and capillary surface area.

A functional change that is recognised with reducing renal mass is an increase in snGFR, which is considered to be an adaptive response to maintain overall GFR. This adaptive response is beneficial in the short-term. However, in the long-term glomerular hyper-filtration and intraglomerular hypertension will lead to glomerulosclerosis and progressive nephron loss. The net effect of increases in snGFR is that significant loss of functioning renal mass can occur without an initial decline in whole kidney GFR. Studies in cats have shown GFR to increase following surgical reduction of renal mass, with histopathological evidence of hypertrophy.^3,5 Finding evidence of renal hypertrophy, suggesting hyperfiltration is occurring, would be difficult in clinical patients without the collection of renal biopsies for histopathological examination, which is generally not performed. Therefore, detection of decreasing GFR at the earliest possible point and implementation of appropriate management for chronic kidney disease (CKD) may help to slow disease progression and preserve functioning renal mass.

Why measure GFR?

Limitations of routinely used markers

In clinical practice, plasma or serum creatinine, urea concentration or urine specific gravity (USG) are routinely used markers of renal function.

USG is considered an insensitive marker of renal function. Cats that have undergone renal ablation have been shown to retain significant urine concentrating ability, and this capacity to concentrate urine appears to be greater than that of dogs or humans.⁵ Moreover, USG can vary in cats with CKD and it does not predict progression of disease.⁶ USG should not be considered a marker of GFR. Although GFR is important in formation of the ultrafiltrate, this will undergo selective reabsorption and secretion processes within the renal tubules through tubular transport mechanisms. The final USG reflects the ability of the renal tubules to concentrate or dilute urine according to the body’s needs to balance water intake and excretion. While renal mass does influence maximal urine concentrating ability, non-renal factors such as certain drugs (diuretics, corticosteroids), diet or fluid intake are major influencers of USG. Both urea and creatinine concentrations can also be influenced by non-renal factors such as dehydration and a high protein diet. Urea is passively absorbed in the renal tubules. Therefore, plasma concentrations can increase at slow tubular flow rates such as may occur in a dehydrated or hypovolaemic patient.

Creatinine is perhaps the most widely used surrogate marker of renal function. The clinical utility of creatinine is based on its relationship to GFR. Creatinine is formed at a stable rate (directly related to muscle mass) in healthy individuals from non-enzymatic dehydration of creatine phosphate in skeletal muscle.⁷ As it is not protein bound, it is freely filtered by the glomerulus and, since creatinine is neither reabsorbed nor secreted to any significant extent in the tubules of cats, its plasma concentration correlates inversely with GFR. However, there are a number of factors affecting the sensitivity of creatinine as a marker of renal function that need to be considered:

Creatinine is not only a marker of GFR but also a marker of muscle mass, and plasma concentrations can therefore depend on muscle mass.

Creatinine concentrations can vary depending on the sample collected (plasma vs serum) and method of analysis (Jaffe’s reaction vs enzymatic). Jaffe chemistry detects non-creatinine chromogens, causing false elevations in creatinine. In addition, creatinine concentrations vary when measured in different veterinary practices, especially when using bench-top analysers.⁸

Analytical results are more consistent when samples are submitted to reference laboratories, but there is variation in reference intervals between laboratories. This can lead to cats and dogs being classified differently as normal or abnormal depending on the laboratory performing the analysis.⁹

In cats and dogs the first step of creatinine biosynthesis takes place in the kidneys;¹⁰ hence creatinine generation may be reduced in patients with kidney disease. Endogenous creatinine production per kg of body weight has been shown to be lower in dogs with reduced renal function.¹¹

Thus, the relationships between GFR, and urea and creatinine, are not strong (Figure 3). Urea and the reciprocal of creatinine explain only 25% and 43% of the variability in GFR, respectively. Combining the markers does improve the prediction of GFR but not to any significant degree (1/creatinine and urea combined explain 48% variability in GFR). due to the non-linear relationship between GFR and creatinine, a significant reduction in GFR is required before corresponding increases in creatinine concentration are seen. indeed, a reduction in GFR from 3.5 to 1.5 ml/min/kg resulted in a corresponding increase in plasma creatinine of only approximately 100 to 150 µmol/l (see Figure 3).

Figure 3

Relationship between creatinine and urea concentration and 1/creatinine with glomerular filtration rate (GFR). The relationships were determined by a process of curve fitting. The reciprocal of creatinine demonstrates a linear relationship with GFR, whereas the relationship between creatinine and GFR is non-linear (which explains the absence of an R² value). The relationships between GFR and urea and 1/creatinine are not strong. Figures from Finch¹²

Furthermore, the sensitivity and specificity of creatinine and urea are dependent on the GFR cut-off point that is used for determining abnormal renal function and this remains poorly defined. They will also be dependent on the reference interval used to determine whether a patient has increased creatinine or urea concentration. Table 1 presents the sensitivity and specificity of the markers alone and in combination. Urea has higher sensitivity than creatinine. This means there is less risk of false-negative results, but a greater risk of false-positive results. This probably reflects what is seen in the clinical situation, with this marker being affected frequently by non-renal factors including circulation, diet and gastro-intestinal haemorrhage. Creatinine has higher specificity than urea and, therefore, produces fewer false-positive results but more false-negative results. Again, this probably reflects what is seen in the clinical situation, with poorly muscled cats having creatinine concentrations within the laboratory reference interval despite a strong suspicion of CKD.

Table 1

Sensitivity and specificity of routinely used renal markers (urea and creatinine) alone and in combination for detection of decreased glomerular filtration rate (GFR)

	GFR <0.92 ml/min/kg		GFR <1.02 ml/min/kg		GFR <1.30 ml/min/kg

	Sensitivity	Specificity	Sensitivity	Specificity	Sensitivity	Specificity
Creatinine	82%	86%	71%	86%	61%	91%
Urea	91%	34%	95%	36%	91%	40%
Creatinine + urea	82%	87%	71%	87%	61%	93%

Elevated creatinine and urea were defined using the upper limit of the laboratory reference interval (177 µmol/l and 9.9 mmol/l, respectively). Urea has higher sensitivity than creatinine and conversely creatinine has higher specificity. Optimal sensitivity and specificity is probably achieved by using a combination of the two markers. Data from Finch¹³

Optimal sensitivity and specificity is probably achieved by using a combination of the two markers. in cases of discrepancy between urea and creatinine, creatinine is considered the more accurate given the higher likelihood of false positives with urea associated with non-renal factors.

The positive and negative predictive value should also be determined when considering the diagnostic use of markers. Figure 4 presents the positive and negative predictive value of urea and creatinine combined for three different GFR cut-off points. As can be seen from the graphs, the positive predictive value increases with the prevalence of the disease whereas the negative predictive value decreases. Therefore, a urea and creatinine concentration above the laboratory reference interval in an older cat in which there is suspicion of CKD will be more reliable than in a younger healthy cat.

Figure 4

Positive (blue, solid) and negative (green, dotted) predictive value of urea and creatinine combined for varying glomerular filtration rate (GFR) cut-off points. The positive and negative predictive value of the combination of markers for predicting low GFR will be affected by the prevalence of disease in a population. The positive predictive value increases with the prevalence of disease whereas the negative predictive value decreases. Data from Finch¹³

GFR – a more sensitive assessment of renal function

Recognition of the limitations of plasma creatinine, urea and USG as markers of functioning renal mass and their lack of sensitivity in detecting early kidney disease has led to demand for more precise methods. Measurement of GFR is considered to provide the most accurate and sensitive assessment of functioning renal mass, and is useful in a variety of clinical scenarios (see left).

GFR may additionally be determined in a research setting to provide an accurate measurement of renal function. It may also be beneficial for monitoring renal function following toxin exposure or recovery from acute kidney injury, although its use in these clinical settings remains to be fully evaluated.

Methods of measuring GFR

GFR can be measured based on plasma or renal clearance of an endogenous or exogenously administered filtration marker (see right). The terms clearance and GFR are, therefore, often used interchangeably.

Renal clearance methods

Renal (sometimes referred to as urinary) clearance is defined as the rate at which a filtration marker is completely removed from a hypothetical volume of plasma by the kidneys to provide the amount of marker appearing in urine per unit of time. The fructose polymer inulin is considered the gold standard filtration marker for this clearance method. Measurement of renal clearance requires infusion of a marker at a constant rate to achieve steady state concentration, as well as accurate timing and complete urine collection. This necessitates urinary catheterisation and bladder emptying. Consequently, these methods are impractical for clinical use and remain largely a research tool.

Plasma clearance methods

Plasma clearance methods are more commonly used since they involve administration of a bolus dose of filtration marker and collection of blood samples.

Radiolabelled markers Plasma clearance of radiolabelled markers such as ^99mTc-DTPA and ⁵¹Cr-EDTA offers the advantage of allowing assessment of each individual kidney through renal scintigraphy as well as GFR determination. The disadvantage of radiolabelled markers is the requirement for nuclear medicine facilities. Several studies in cats have used radiolabelled markers to determine GFR.^{14

–22}

Exogenous creatinine Exogenously administered creatinine has been used in cats as a filtration marker.^22

–26 The lack of a medical grade formulation is a disadvantage of this method. Also, due to the larger volume of distribution compared with other filtration markers, this is a much lengthier test to perform.^11,27 The increased sampling time required can additionally result in a much larger extrapolated component of the area under the plasma concentration vs time curve (AUC) than for other markers,²⁸ particularly in patients with reduced renal function, and this may lead to inaccuracies in GFR measurement. in dogs, extra-renal clearance of creatinine has been identified, which is important in patients with low GFR,²⁹ meaning GFR may be overestimated. Extrarenal clearance has not been explored in cats.

Iohexol Radiographic contrast agents, such as iohexol (see below), meet the requirements of a useful filtration marker. despite concerns regarding contrast-induced nephropathies in human patients, no adverse effects have been reported in plasma clearance studies using iohexol in cats.^{14,22

–25,28,30

–36}

Inulin GFR has been determined using plasma clearance of inulin in cats.^{17,26,30,37,38} Although renal clearance of inulin is considered the gold standard GFR measurement technique, plasma clearance of inulin is not recommended. in a canine study approximately 40% of administered inulin was unaccounted for.¹¹ This was considered to be the result of extra-renal biliary clearance. Extra-renal clearance of inulin has not been studied in cats.

Iohexol as a filtration marker

Iohexol is readily available for clinical use as the radiographic contrast marker omnipaque. iohexol demonstrates endo- and exo-isomerism.³⁹ Analysis of iohexol concentrations in samples using high performance liquid chromatography (HPLC) allows detection of endo- and exo-isomers. The predominant isomer quantitatively is known to be exo-iohexol. Some studies have reported a difference in clearance of the two isomers in cats,^22

–25 suggesting that measurement of total iohexol only may lead to inaccuracies when determining GFR. However, a more recent study demonstrated no difference in clearance between the two isomers and found that following administration there is no significant conversion of one isomer to the other.⁴⁰ This is supported by findings in dogs,^41,42 rats⁴¹ and human patients.^43,44 Biologically this seems more plausible than the glomerular filtration barrier reacting differently depending on the isomer presented to it.

The author recommends that the isomers are considered as one pharmacological entity (ie, measure total iohexol concentration) when calculating clearance. High performance capillary electrophoresis (HPCE) measures total iohexol only.

Pharmacokinetic models to calculate GFR using plasma clearance methods

Accurate plasma clearance methods rely on collection of blood samples at multiple time points to create a plasma concentration vs time curve. The clearance (Cl) is then calculated as: Cl = dose/AUC, where AUC is the area under the plasma concentration vs time curve. The concentration of the filtration marker must first be log transformed to create the plasma cconcentration vs time curve before calculating the AUC. despite the fact that the concentration of most filtration markers is determined in serum, the term plasma concentration vs time curve is used, as GFR is dependent on renal plasma flow. Filtration markers distribute throughout a number of compartments within the body. This allows a pharmacokinetic model to be constructed which can be used to calculate AUC. Such compartments can be considered more as mathematical tools than as defined physiological spaces.

One-compartment model A one-compartment model assumes that the body is a single compartment and that, following administration of the filtration marker, there is immediate mixing and distribution within the body and that the marker is excreted from that compartment only. A single linear slope is fitted to the plasma concentration vs time curve (Figure 5). in theory, a minimum of only two samples is required to generate a one-compartment model. However, the assumption of immediate mixing and distribution within the body does not occur for most filtration markers, which can lead to inaccuracies when using the model without correcting for the assumption.

Two-compartment model A two-compartment model is regarded as the most appropriate pharmacokinetic model for most filtration markers. This is because the majority of markers are considered to have a volume of distribution within the extracellular fluid volume (ECFV). This model is based on the concept that following distribution of marker from plasma (central compartment) to ECFV (peripheral compartment), equilibration is reached. The marker is eliminated by renal clearance which allows slow redistribution of marker back into the plasma from the interstitial fluid, from which it is cleared. Therefore, there is an initial distribution phase of the marker within the body followed by elimination from the body. By a process of curve stripping, the plasma concentration vs time curve can be resolved into two linear slopes. The first represents the initial distribution of marker (α) from plasma to ECFV and the second is the terminal elimination (renal clearance) phase (β) (Figure 6).

Non-compartmental models Non-compartmental models can also be applied to calculate AUC. A non-compartmental model is attractive as, unlike compartmental models, it is free of assumptions regarding redistribution and exchange.⁴⁵ AUC is determined by fitting multiple trapezoids to the curve (Figure 7). The sum of the trapezoids is used to calculate AUC. It is important that a non-compartmental model is only applied to data when sufficient samples have been collected.⁴⁰

Figure 5

One-compartment model In this example the circles represent the concentration of filtration marker determined from a plasma sample collected at different time points. By plotting the log concentration of marker, a plasma concentration vs time curve is created. The area under the curve (AUC) is determined by fitting a single slope (dashed line) representing a single compartment from which marker is cleared. AUC is calculated by dividing the zero time intercept (A) by the slope of the exponential (α). Clearance is determined by dividing the dose of marker administered by AUC

Figure 6

Two-compartment model In this example the circles represent the concentration of filtration marker determined from a plasma sample collected at different time points. By plotting the log concentration of marker, a plasma concentration vs time curve is created. AUC is determined by fitting two slopes (dashed lines) which represent the initial distribution phase of the filtration marker between plasma and extracellular fluid volume (ECFV) (α) and the terminal elimination phase which represents the renal clearance of filtration marker from plasma (β). AUC is determined as A/α + B/β, where A is the zero time intercept of the first (distribution) exponential, α is the slope of this exponential, B is the zero time intercept of the second (elimination) exponential and β is the slope of this exponential. Clearance is determined by dividing the dose of marker administered by AUC

Figure 7

Non-compartmental model This example uses the trapezoidal rule. The circles represent the concentration of filtration marker determined from a plasma sample collected at different time points. By plotting the log concentration of marker, a plasma concentration vs time curve is created. AUC is determined by fitting multiple trapezoids and calculating the sum of the trapezoids. Clearance is determined by dividing the dose of marker administered by AUC

The commercial pharmacokinetic programs utilised to create compartmental models may not be available to all clinicians and researchers measuring GFR. However, it has been demonstrated that clearance calculated by hand (using graphical plots of plasma concentration vs time curve) for both two-compartment and corrected one-compartment models gives results in agreement with multi-sample clearance calculated using a pharma-cokinetic computer program.⁴⁰ Graphical plots of the plasma concentration vs time can be created using standard computer software programs such as Excel or manually using graph paper. The log transformed filtration marker concentration must be used to create the graphical plot of the plasma concentration vs time curve. The two stage curve-stripping process to obtain the intercepts of the distribution and elimination exponentials (A and B) and slope (α and β) for multisample data are described in a previous study.⁴⁰ The slope-intercept method (see later), which would be of more use in the clinical setting, requires only a single line of best fit to be applied to the data and negates the need for the curve stripping process.

Limited sampling methods for clinical practice

From inspection of the two-compartment model it is clear that at least four samples are required to generate the biexponential curve. Techniques which require collection of only a limited number of samples have become an important goal for clinicians when measuring clearance; not only with respect to making GFR measurement more practical in the clinical situation, but also for reducing stress in a patient associated with repeated sampling and reducing costs associated with analysis.

Slope-intercept technique

Based on data in human medicine, it is assumed that the initial rate of the distribution phase of a marker is independent of renal clearance (GFR) and an estimate of GFR may, without significant loss of accuracy, be based on the second elimination exponential (collection of samples after 60 mins).⁴⁶ Exclusion of the distribution exponential leads to an overestimation of GFR as the AUC is underestimated (Figure 8).⁴⁷ The error becomes particularly important in patients with normal or near-normal renal function in which the initial rapid distribution exponential contributes to a relatively larger proportion of the AUC than in patients with a low GFR.

Figure 8

Plasma concentration vs time curve indicating the missing area under the curve associated with the slope-intercept method. The slope-intercept method of determining plasma clearance relies on the collection of a limited number of samples (generally three) during the elimination phase of the clearance curve (generally 60 mins following administration of the filtration marker). As the initial distribution exponential is ignored, this creates a ‘missing area under the curve’ (blue circle), leading to an underestimation in the calculated area under the curve (AUC) and hence overestimation in glomerular filtration rate (GFR) (as GFR is calculated as dose/AUC)

Clearance calculated from a limited number of samples collected during the elimination phase is referred to as the slope-intercept technique. The AUC, and subsequently clearance, are calculated as discussed above. A correction formula is applied to the result to obtain corrected slope-intercept clearance.

Formulae that correct for the missing area under the curve when using a slope-intercept method have been developed for human patients,^46,48,49 dogs⁵⁰ and more recently cats.⁴⁰ The cat correction formula⁴⁰ (Table 2) was developed using the filtration marker iohexol. Iohexol and nuclear medicine markers such as ⁵¹Cr-EDTA are considered to distribute through ECFV,⁵¹ and will require similar corrections for the missing area under the curve. Therefore, the cat correction formula, although unvalidated, may be accurate for use with nuclear medicine markers. It is unlikely that the formula will be appropriate for use with the clearance marker exogenous creatinine because of its much larger volume of distribution, which is considered to approximate total body water rather than ECFV,^11,27 therefore requiring a three-compartment model.

Table 2

Formulae for determining GFR using limited sampling plasma clearance methods in cats

	Correction/prediction formula
Slope-intercept GFR (ml/min/kg)	1.036 x GFR_uncorrected – 0.062 x GFR_uncorrected²
Single sample formula for GFR(ml/min/kg)	([1.027 x β1] x ECFV) / BW β1 = ([1/t] x ln[Vt/ECFV]) x 0.93
ECFV (ml)	313.68 + (119.81 x BW)

The slope-intercept formula corrects for the missing area under the curve when collecting only a limited number of samples (generally three samples) from the elimination phase of the clearance curve (samples collected at 120, 180 and 240 mins). The uncorrected clearance (GFR_uncorrected), which is standardised to body weight (BW), is inserted into the formula to obtain the corrected clearance, the unit of which is ml/min/kg

Single sample GFR is determined from a single sample collected at time t (180 mins) and the volume of distribution of iohexol at time t (Vt) which is calculated as dose of iohexol administered/serum concentration of iohexol at time t. An estimate of ECFV is also required which can be obtained from body weight (kg) using a second formula

GFR = glomerular filtration rate; ECFV = extracellular fluid volume

The slope-intercept method involves calculation of the the AUC using a one-compartment model. As discussed above this can be created using standard computer software programs such as Excel or manually using graph paper. The intercept (A) is determined by extrapolating the line back to the time 0 intercept and the slope (α) is determined using a standard mathematical approach (y₂ – y₁/x₂ – x₁). Clinicians and researchers can therefore calculate clearance accurately using the corrected slope-intercept technique without the need for expensive pharmacokinetic programs (see ‘Case Notes’ on page 745 for a worked example). This method is also considered acceptable by the British Nuclear Medicine Society for determining GFR using radiopharmaceutical markers.⁵²

Single sample method for cats

A further simplification of the limited sampling technique is to determine GFR from a single plasma sample. Previous approaches in dogs and cats have applied linear or non-linear regression analysis to derive equations for single sample methods from multisample methods and to select the best sampling time.^15,20,31,32 These empirical methods have limitations as both clearance determined from a single sample and clearance determined from multiple samples are not independent measurements. Theoretically, this approach would be valid in a patient where the distribution volume is equal to the average distribution volume of patients studied, and renal function is similar to that of the population used to generate the formula. In normal healthy patients this error may be small; however, in patients with abnormal renal function, the range of volume of distribution may be greater and, therefore, the error larger.

There are two prerequisites for single sample methods. The first is knowledge of the volume of distribution of the filtration marker. The volume of distribution of iohexol is considered to be approximately that of the ECFV.⁵³ The second is that the sample is collected at a time point when GFR is transiently independent of ECFV.⁵⁴ This is considered to be when there is complete mixing of marker through the ECFV (ie, the distribution phase can be considered to have reached completion). As renal function declines, this time point is further from the time of administration of the marker.^55,56 This is because of the influence of renal function on ECFV and clearance (elimination phase) of the marker at this time. This is in contrast to the initial phase of the distribution exponential which is relatively independent of clearance.

A single sample method of determining GFR based on these theoretical methods has been developed for cats.⁵⁷ The formula required for this is presented in Table 2. A measurement of ECFV is required and a formula based on body weight (BW) can be used for this (see Table 2).⁵⁷ Optimal sampling time to be 180 mins.⁵⁷ It is recommended that in patients with very low GFR, sampling time is delayed. Studies from human patients have suggested delays of up to 8–9 h⁵⁵ and up to 24 h.⁵⁶ If sampling is performed too early in patients with very low GFR, single sample clearance will overestimate true clearance. The single sample formula remains poorly validated for cats with very low GFR. However, given that the clinical indication for GFR determination is often in patients with normal or near-normal renal function, this method can be considered to be appropriate for most cats.

Standardisation of GFR measurements

The most commonly used method to standardise GFR measurements in cats and dogs is to scale to BW in kg. This assumes that the relationship between GFR and weight is linear. in human patients, GFR measurements are standardised to body surface area (BSA), which is considered to reflect basal metabolic rate and kidney size more closely than BW. A further method for standardising GFR measurements is scaling to ECFV.^58,59 it is a logical concept to scale GFR to ECFV since ECFV is closely related to regulation of GFR. Furthermore, the kidney has an important role in maintaining body fluid composition. To assess appropriateness of scaling, the parameter (eg, BW) should correlate with unscaled GFR and when the parameter is correlated with GFR standardised to the parameter (eg, GFR/kg) the correlations should not be significant.

As can be seen from Table 3, BW (kg), BSA (m2) and ECFV (ml) appear to be appropriate methods of standardising GFR in cats. A previous study reported all three methods to be satisfactory for cats; however, only BSA was appropriate in dogs.³⁶ A further canine paper reported discrepancies between estimated levels of renal function standardised to BW, BSA and ECFV based on ranked measurements of GFR.⁵⁰ Some authors have preferred to normalise measurements to BSA in cats.^30
–32 However, in obese patients, the increase in BSA will lead to a decrease in GFR/BSA, underestimating GFR. This may explain reports of obesity-related reduction in renal function in human patients. Furthermore, the use of formulae to determine BSA is of questionable accuracy.⁶⁰

Table 3

Standardisation of GFR measurements

	Relationship with GFR (R2)*	P value
BW (kg)	0.73	<0.001
ECFV (ml)	0.51	0.001
BSA (m2)	0.73	<0.001
GFR/kg	0.006	0.760
GFR/ml	0.001	0.885
GFR/m2	0.006	0.760

Relationship evaluated in 18 cats

There is a significant relationship between body weight (BW), extracellular fluid volume (ECFV), body surface area (BSA) and glomerular filtration rate (GFR), and a non-significant relationship between GFR standardised to the parameter and GFR, indicating all three methods of standardisation are appropriate in cats. Data from Finch¹²

The cat correction formula⁴⁰ for slope-intercept clearance requires standardisation to BW.

Reference intervals for GFR in cats

Despite several published studies determining GFR in cats, reference intervals remain poorly defined. Variations in filtration marker used, method followed and study population are likely to influence GFR measurement. Therefore, it is important that for each clearance protocol a separate reference interval is established. The derived reference interval for GFR determined using slope-intercept iohexol clearance in 25 healthy, non-azotaemic (plasma creatinine <140 µmol/l) cats was 0.92–2.88 ml/min/kg.¹² An earlier study reported a reference interval of 1.02–3.50 ml/min/kg²⁸ for iohexol clearance in cats. The reference interval that can be determined from the mean and standard deviation reported in a further study in healthy cats was 1.30–4.2 ml/min/kg.³⁶

Establishment of a single reference interval may be inappropriate as filtration rate may be affected by sex, breed and age. Kittens are reported to have a higher GFR than adult cats.⁶¹ Sex differences in GFR are reported in dogs⁶² and suggested in cats.¹² Breed effects on creatinine concentration have also been reported;^63,64 however, whether this related to GFR remains to be studied. Therefore, a decline in GFR over time in an individual patient may be important in detecting kidney disease. The decline must represent a clinically relevant change rather than physiological variation. The coefficient of variation in healthy cats is reported to be <20%⁶⁵ and, therefore, a decline >20% is likely to be clinically significant. However, studies to fully evaluate this are required.

Estimated GFR formulae

GFR is routinely estimated from creatinine concentrations in human patients using prediction equations which take account of factors such as age, gender, race and body size that are considered to influence muscle mass.^66
–68 Estimated GFR (eGFR) formulae offer the advantage of more accurately reflecting actual GFR than serum creatinine in human patients. it is now mandatory for eGFR to be reported with every creatinine measurement performed in human patients in several states in the USA, as well as in the UK and Australia,⁶⁹ highlighting the importance of such formulae. These eGFR formulae appear to offer some advantage over serum creatinine alone in assessment of renal function. Following introduction of reporting of eGFR alongside creatinine concentration, recognition of CKD by doctors increased from 27% to 85% of cases.⁷⁰

However, the precision and accuracy of the formulae is questionable, particularly in elderly patients or patients with extremes of muscle mass and in patients with unstable renal function. Furthermore, the earlier formulae^66,68 may underestimate true GFR, leading to misclassification of some patients as having CKD. Clinical concerns regarding accuracy of the formulae in all patient populations, sensitivity and specificity of the formulae and their use to adjust drug dosages have been expressed. Nevertheless, they appear to be a better screening test than plasma creatinine concentration.⁷¹

Attempts to validate an eGFR formula in cats have been made; however, it was not found to offer any improvement in predicting GFR than creatinine alone.⁷² As the formula does not provide a reliable estimate of GFR in cats, its routine use cannot be recommended. Further studies to validate an eGFR for cats are required.

Key Points

The inherent difficulties associated with performing renal clearance and multisample plasma clearance measurements, and also calculation of clearance using different pharmacokinetic analyses, may pose conceptual as well as practical difficulties for veterinary practitioners. Therefore, GFR measurement may typically only be considered by clinicians and researchers with specialist knowledge of the area.

This review, however, describes a single sample approach that accurately determines GFR. It involves the administration of a bolus dose of iohexol, collection of a single plasma sample at 180 mins and estimation of ECFV based on BW.

The technique offers a simple, attractive and cost-effective approach, which could feasibly be employed by veterinary practitioners for assessing renal function in cats.

In addition, the corrected slope-intercept method, although requiring the collection of three blood samples, can be achieved in practice without the use of pharmaco modelling programs.

Given the recognised limitations of urea and creatinine concentration and USG for evaluating renal function, determination of GFR will remain important in early identification and accurate assessment of stage of CKD in ca

Supplemental Material

Click here for Supplementary Material

Details of laboratories and methods of analysis for measuring iohexol employed by the laboratory

Footnotes

Acknowledgements

The author would like to thank Professor Jonathan Elliott and Professor Harriet Syme for their supervision during the studies which formed part of the author’s PhD at the Royal Veterinary College, London. The author would also like to thank Reidun Heiene and Professor AM Peters for advice regarding GFR measurement.

Funding

The author received no specific grant from any funding agency in the public, commercial or not-for-profit sectors for the preparation of this article.

Conflict of interest

The author declares that there is no conflict of interest.
